- Page 1 KPW-10024-DF KPW-10048-D/DF Industrial DIN-Rail AC-DC 100W/150W Power Supply 24V / 150W 48V / 100W 48V / 150W User , s Guide DOC.190110...
- Page 3 The information contained in this document is subject to change without prior notice. Copyright (C) All Rights Reserved. FCC NOTICE This device complies with Class A Part 15 the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received including the interference that may cause.
- Page 4 Introduction This guide describes the specifications and installation information of the following AC-DC power supply: Model AC Input DC Output Watts KPW-10024-DF 100 ~ 240V, 50/60Hz 150W KPW-10048-D 100 ~ 240V, 50/60Hz 100W KPW-10048-DF 100 ~ 240V, 50/60Hz 150W Features ...
- Page 5 Panels...
-
Page 6: Specifications
DC OUT (DC Power Output) Interfaces 6P European Terminal Block Contacts DC＋/DC－, DC＋/DC－, DC＋/DC－ Output Power Model DC Output Output Current Efficiency KPW-10024-DF 24V (+/- 2%) 6.25A max. KPW-10048-D 48V (+/- 2%) 2.1A max. KPW-10048-DF 48V (+/- 2%) 3.125A max. Power Wires 12AWG ~ 22 AWG (1 meter max.) - Page 7 KPW-10048-DF 100% @ -30°C ~ 50°C, 66% @ 60°C, 50% @ 70°C Fan Cooling Model KPW-10024-DF KPW-10048-D KPW-10048-DF Mechanical Dimension (base) 42 x 106 x 140 mm (WxDxH) Housing Enclosed metal Mounting Din-Rail, Panel Internal Power Module Approvals UL60601-1, IEC60601-1, TUV EN60601-1 Certified...
-
Page 8: Safety Cautions
Safety Cautions To reduce the risk of bodily injury, electrical shock, fire and damage to the product, observe the following precautions. Do not service any product except as explained in your system documentation. Opening or removing covers may expose you to electrical shock. ... -
Page 9: Mounting Support
Mounting Support Din-Rail Mounting Install the Din-Rail bracket on the rear panel as shown below: Mount the device on a Din-Rail as shown below:... -
Page 10: Panel Mounting
Final Dimension after Installation Panel Mounting An optional panel mounting bracket supports mounting the power supply on a plane surface securely. -10-... - Page 11 Install the bracket onto the device unit as shown below and use two screw holes to fix the unit on a plane surface: Final Dimension after Installation -11-...
-
Page 12: Ac Power Input
AC Power Input The power supply provides 3P terminal block for receiving AC power input. Using Terminal Block Use 3P terminal plug for AC power wires. Install the wires into the plug securely. The colors of the power wires are: Contacts Europe (IEC) L (Life) -
Page 13: Dc Power Output
DC Power Output The power supply provides three pairs of industrial terminal block connectors for installations. Using Terminal Blocks DC OUT ( 2P x 3 Contacts) DC＋ / DC－ DC＋ / DC－ DC＋ / DC－ Use the supplied 2P plug for DC power wires. Insert and screw the wires securely as shown below: Power wire specification: 24~12AWG (IEC 0.5~2.5mm -13-...
