Spitz
(GL-X750)
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spitz and is the answer not in the manual?

Questions and answers

Marquitta
April 3, 2025

I'm trying to set up the Spitz 750v2 and need the IMEI number. I've accessed (on my computer) the internet via my ATT phone.

0
1 comments:
Mr. Anderson
April 3, 2025

To find the IMEI number for the GL-INET Spitz 750v2, open a web browser and go to 192.168.1.1. Log in using the username "admin." Once logged in, the interface will display the IMEI number along with other information like IP address.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for GL-INET Spitz

Summary of Contents for GL-INET Spitz

  • Page 1 Spitz (GL-X750) USER MANUAL...

  • Page 2: Table Of Contents

    Table of Contents Getting Started with GL.iNet Spitz ..................1 Power on ..........................1 1.1. Connect ........................... 2 1.2. Connect via LAN ......................2 Connect via Wi-Fi ......................3 Access the Web Admin Panel ..................3 1.3. 1) Language Setting ........................3 2) Admin Password Setting .....................
  • Page 3 VPN ..............................21 OpenVPN ..........................21 7.1. OpenVPN Client ..................... 21 7.1.1. OpenVPN Server ....................26 7.1.2. WireGuard ........................... 29 7.2. WireGuard Client ........................29 WireGuard Providers ........................ 32 WireGuard Server ........................33 Wireguard App Support ....................... 36 Visit Client’s LAN Subnet ......................36 VPN Policies ........................
  • Page 4 Setup ............................... 79 Manage your devices ....................... 87 Site to Site ............................. 93 Batch Setting ..........................102 Template Management ......................105 Task List ............................107 BLE MQTT Bridge ........................108 GoodCloud and VPN ......................108 Disable ............................109 Tor ............................112 8.5.
  • Page 5 Access Web Panel ......................160 10.7 Check connection/router's IP address ................160 Your IP address is incorrect ....................160 Your IP address is correct....................160 Extensible Authentication Protocol (EAP) ............161 10.8 Introduction ..........................161 Connect via web panel ......................162 Connect via Luci ........................

  • Page 6: Getting Started With Gl.inet Spitz

    1. Getting Started with GL.iNet Spitz Model: GL-X750 1.1. Power on Plug the power cable into the power port of the router. Make sure you are using a standard 12V/1.5A power adapter. Otherwise it may cause malfunction. Page 1 | 168...

  • Page 7: Connect

    Note: Hot plug for SIM card and TF card is not supported. If you want to use, please insert before powering on the router. 1.2. Connect You can connect to the router via Ethernet cable or Wi-Fi. Note: This step only connects your devices to the local area network (LAN) of the router.

  • Page 8: Connect Via Wi-Fi

    (2) Connect via Wi-Fi Search for the SSID of the router in your device and input the default password: goodlife. Note: The SSID was printed on the bottom label of the router with the following formats: • GL-X750-XXX-5G • GL-X750-XXX 1.3.

  • Page 9: Admin Password Setting

    Note: If your browser always redirects to Luci (http://192.168.8.1/cgi-bin/luci), you can visit: http://192.168.8.1/index.html instead of http://192.168.8.1. 2) Admin Password Setting There is no default password for the Admin Panel. You have to set your own password, which must be at least 5 characters long. Then, click Submit proceed.

  • Page 10: Admin Panel

    Note: This password is for this web Admin Panel and the embedded Linux system. It will not change your Wi-Fi password. 3) Admin Panel After the initial setup, you will enter the web Admin Panel of the router. It allows you to check the status and manage the settings of the router.

  • Page 11: Internet

    2. INTERNET There are total 4 types of connection method that you can use to access the Internet: Cable, Repeater, 3G/4G Modem and Tethering. Click to create an Internet connection. INTERNET Page 6 | 168...

  • Page 12: Cable

    2.1. Cable Connect the router to the modem or main router via Ethernet cable to access the Internet. Before plugging the Ethernet cable into the WAN port of the router, you can click to set the WAN port as a LAN port. That is useful when you are using Use as LAN the router as a repeater.

  • Page 13: Dhcp

    Plug the Ethernet cable into the WAN port of the router. The information of your connection will be shown on the Cable section. DHCP is the default protocol. You can click to change the protocol. Modify (1) DHCP DHCP is the default and most common protocol. It doesn't require any manual configuration.

  • Page 14: Pppoe

    (3) PPPoE PPPoE is required by many Internet Service Providers (ISP). Generally, your ISP will give you a modem and provide you a username & password that you needed when you are creating the Internet connection. Under PPPoE protocol, enter your username and password, then click Apply 2.2.

  • Page 15: 4G Modem

    Finally, click Join 2.3. 3G/4G Modem Spitz has a built-in 3G/4G modem which you can insert your SIM card directly. Please insert the SIM card before powering on the router. Then, you should find the name of your carrier, click to create the connection.
  • Page 16 You can also click to set up manually. Manual Setup In General, you can set up by the three basic parameters below. Click Apply connect. • Device: Please choose /dev/cdc-wdm0 (qmi) or /dev/ttyUSB3. • Service Type: indicate the service of your SIM card. •...

  • Page 17: At Command

    It is connected when the IP address of your SIM card shows up. AT Command The built-in modem supports AT command for the management and configuration of the modem. In 3G/4G Modem section, Click AT Command Page 12 | 168...

  • Page 18: Tethering

    • Shortcut: There are several pre-configured AT commands that you can use directly. If you want to run your own AT command, choose Manual command. • AT Command: The place where you can input AT command. For the list of AT command, please refer to the AT command manual of the built-in modem.

  • Page 19: Easytether

    Connection your smartphone to the USB port of the router and click Trust to continue when the message pops up on your smartphone. After plugging in your device, the Tethering section will update and your device will be shown on the device list. The device name will begin with eth or usb such as eth2, usb0.
  • Page 20 TX Power (dBm): It specifies the signal strength. The default value is 20 (Strongest). Click to change the settings of the wireless network. Modify Page 15 | 168...

  • Page 21: Clients

    4. CLIENTS You can manage all connected clients in CLIENTS You can see their name, IP, MAC address and connection type. Click the button on the right to block any unwanted client. 5. UPGRADE Click to check any available update and upgrade the firmware. UPGRADE Page 16 | 168...

  • Page 22: Online Upgrade

    5.1. Online Upgrade You can find the current firmware version here. If your router is connected to the Internet, it will check for the newer firmware version available for download. Note: It is suggested to uncheck Keep setting. If you keep the settings and encounter problems after the upgrade, please reset the router.

  • Page 23: Official Openwrt/Lede Firmware

    (1) Official OpenWrt/LEDE firmware You can download the official firmware from our website. • Spitz: http://download.gl-inet.com/firmware/x750/ Find the available firmwares from the folder according to your device model, and they are located in different sub-folders: release: Official GL.iNet OpenWrt/LEDE firmware.

  • Page 24: Firewall

    6. FIREWALL , you can set up firewall rules like port forwarding, open port and FIREWALL DMZ. 6.1. Port Forwards Port Forwarding allows remote computers to connect to a specific computer or service behind the firewall in the local LAN (such as web servers, FTP servers, etc).

  • Page 25: Open Ports On Router

    Internal Ports: The internal port number of the device. You can enter a specific port number. Leave it blank if it is same as the external port. Protocol: The protocol used, you can choose TCP, UDP, or both TCP and UDP. Status: Activate of Deactivate the rule.

  • Page 26: Vpn

    7. VPN GL.iNet routers have pre-installed VPN server and client in OpenVPN and WireGuard. Shadowsocks is not a default function and you need to install packages in Plug- ins. 7.1. OpenVPN GL.iNet routers have pre-installed OpenVPN server and client. 7.1.1. OpenVPN Client OpenVPN client requires OpenVPN configuration file (.ovpn) to create the OpenVPN connection.
  • Page 27 (1) Upload your OpenVPN configuration file Simply drag and drop your file to the pop up windows. It can be a single .ovpn file or a zip/tar.gz file which contains multiple .ovpn files. Be careful that some .ovpn files use separated ca, cert, crl files. These files must be zipped together with the .ovpn file before upload.
  • Page 28 (2) Enter Description, Username and Password Enter a description for your OpenVPN configuration file and then click Submit finish the upload process. In some cases, it will ask you to enter your username and password. Page 23 | 168...
  • Page 29 (3) Connect to the OpenVPN server You can now click to start the OpenVPN connection. Connect Once connected, you should find your IP address, data received/sent. Page 24 | 168...
  • Page 30 (4) Manage configuration files Click to check the list of configuration files. You can modify the Management Description, User name or Password of each configuration file. You can also add, delete a configuration file or even purge all your uploaded configuration files.

  • Page 31: Openvpn Server

    Get your configuration file We have tested different VPN service providers. Therefore, if you don't know how to get the configuration file, you can follow the instruction below. However, you have to contact your service provider for the configuration file if they are not listed below.
  • Page 32 (1) Server configuration There are preset OpenVPN server configurations. You can also click Modify change them manually. Click when you finish. Apply (2) Export OpenVPN configuration file Click to download the OpenVPN configuration file which you need Export Config to upload when you are configuring your OpenVPN client. Page 27 | 168...
  • Page 33 (3) Start the OpenVPN server Click to start your OpenVPN server. Otherwise, you will not be able to Start connect to the OpenVPN server by using its configuration file. Page 28 | 168...

  • Page 34: Wireguard

    7.2. WireGuard WireGuard is an extremely simple yet fast and modern VPN that utilizes state-of- the-art cryptography. It aims to be faster, simpler, leaner, and more useful than IPSec, while avoiding the massive headache. It intends to be considerably more performant than OpenVPN.
  • Page 35 (2) Input the configurations There are different methods to input the configurations. You can copy the configurations from your server JSON Plain Text or input the settings manually. Configuration Page 30 | 168...
  • Page 36 After copy the from your server, you can paste it in JSON Plain Text and then click Add to finish the WireGuard Client setup. Configuration Page 31 | 168...

  • Page 37: Wireguard Providers

    WireGuard Providers If you are using Azirevpn or Mullvad, you can click and use your Others AzireVPN or Mullvad account to set up WireGuard client directly. AzireVPN: Select AzireVPN as the provider, enter your User Name and Password and then click "Add"...

  • Page 38: Wireguard Server

    WireGuard Server You can set up a WireGuard server on GL.iNet router with firmware 3.0. Click Create a New User (1) Start a WireGuard server You can simply use the default parameters of Local IP and Local Port, or you can set your own value.
  • Page 39 (2) Add a new client You have to add a new user and apply the configurations when you are connecting to this WireGuard server. Click tab and then Management Create a New User Specify the Name of the new client and then click Page 34 | 168...
  • Page 40 (3) Get the configuration details for your client You can now check the list of the clients you added. You can Delete unwanted client. Please click to find the configuration details which Configurations you need to use when you are setting up WireGuard client. We provide QRcode, Plain Text and JSON configurations currently.

  • Page 41: Wireguard App Support

    Wireguard App Support You can also use WireGuard App on other devices with various OS • Please refer to WireGuard Official Website ： https://www.wireguard.com/install/ Visit Client’s LAN Subnet Visit Client’s LAN Subnet from WireGuard Server LAN Subnet 1) Change WireGuard clients LAN IP to avoid IP confliction with Server 2) Modify Wireguard_Server Configuration Page 36 | 168...

  • Page 42: Vpn Policies

    WinSCP or SSH into your the WireGuard Server (router) find and modify the file /etc/config/wireguard_server Add a line to the end of the config file of clients you want to visit. list subnet '192.168.xxx.0/24' Save and Exit 7.3. VPN Policies Starting from firmware version 3.022, users can define VPN routing policies.

  • Page 43: Add Vpn Policy

    As a result, they will not use VPN. Please Choose Policy: The item can be either Domain/IP (e.g. gl-inet.com / 192.168.1.1 / 192.168.1.0/24) or Mac address (24:F0:94:5C:8E:F9). 7.3.2.
  • Page 44 However, if we want to route all traffic through VPN except , we need gl-inet.com to add gl-inet.com under Do not use VPN for. Page 39 | 168...

  • Page 45: Clear Dns Cache

    7.3.3. Clear DNS cache If you are using domain-based policy, it may not work unless you clear your DNS cache. Please follow the instructions below to clear your DNS cache. Windows: Press Win + R and run cmd. Execute command ipconfig /flushdns MacOS: Open Terminal and execute command sudo killall -HUP mDNSResponder...

  • Page 46: Internet Kill Switch

    8.2. Internet Kill Switch Internet Kill Switch feature is built-in from firmware version 3.100, please upgrade. Note: With this option enabled, you need to set up the router as a VPN client for any of the router's clients to be able to connect to the internet. After this setting is on, the router needs to run the VPN client all the time, if the VPN client is not running, the clients are Not Allowed to access the Internet.

  • Page 47: Setup

    Setup 1) Choose "Internet Kill Switch". Choose "Internet Kill Switch" from "VPN". 2) Enable "Internet Kill Switch". Switch on the "Enable" button in the middle of the page. Page 42 | 168...
  • Page 48 3) Apply "Internet Kill Switch". Click "Apply" in the upper right corner. 4) Wait for the "Success" notice The “SUCCESS!” Message will pop-up if the Internet Kill Switch turn on correctly. Page 43 | 168...

  • Page 49: File Sharing

    8.3. File Sharing You can use GL.iNet routers with external storage device such as USB stick, MicroSD card, etc, thus the contents can be shared among all your connected clients. You can easily read or modify its contents. 8.3.1. Router settings The contents of the external storage device are shared to LAN but not WAN and they are unwritable by default.

  • Page 50: Access The Storage Device

    Router Model USB Stick USB Hard Drive MicroSD Card GL-X750(Spitz) √ √ √ Note: The power consumption of USB hard drive is quite high. You should use it with an external power supply. Otherwise, it may cause malfunction. 8.3.2. Access the storage device You can access the contents of the external storage device from your computer or smart phone.
  • Page 51 1). SSH into your router, you can gain control of both the router and the network that the rotuer is controlling. You can refer to the following link: https://docs.gl- inet.com/en/3/app/ssh/ 2). Modify the Samba configuration file, type the following command: sed -i 's/security = share/security = user/' /etc/samba/smb.conf.template 3).
  • Page 52 4). Open 'This PC' and type , such as \\your router IP Address \\192.168.8.1 5). You can view files in your USB flash drive through GL.iNet router now. Method 2: Samba 1.0 (SMB1.0) Support: 1) Your network must be Home/Private. Otherwise you may not be able to see your router in Network.
  • Page 53 3.0 firmware supports SMB2, and if you need SMB3, use WinSCP to router, edit /etc/samba/smb.conf.template Change the "max protocol = SMB2" to "min protocol = SMB1" "max protocol = SMB3", then save and exit WinSCP. Page 48 | 168...
  • Page 54 If you are using Windows 10, you also need to enable SMB 1.0. • Windows 7 Go to Control panel -> Network and Internet -> Network and Sharing Center. Find if your active network is Home network. If not, click it and change it to Home network.

  • Page 55: Mac Os

    2) Open a Windows explorer, you can find Network in the folder directory. Double click your router to access its contents. Mac OS Method 1 1) Open Finder, Menu -> Go -> Connect to Server... Page 50 | 168...
  • Page 56 2) Input , you need to change this if your router IP address is not smb://192.168.8.1 192.168.8.1 Page 51 | 168...
  • Page 57 3) Click Connect. 4) Input username and password, they are the same when you login Web Admin Panel. 5) Then Finder will display files of USB disk. Page 52 | 168...

  • Page 58: Ios

    Method 2 1) Go to System Preferences -> Sharing -> File sharing. Click and then Options enable SMB. 2) Open Finder. You should be able to find your router under Shared. You have to use file manage app to access the contents of your external storage device.
  • Page 59 Page 54 | 168...
  • Page 60 2) Enter the IP address of your router (192.168.8.1). The User Name is root and the Password is the one that you use to login the web Admin Panel. Finally, click Save Page 55 | 168...
  • Page 61 3) Click your newly created connection to access the contents. Page 56 | 168...

  • Page 62: Linux

    Linux If you are using Linux you are probably comfortable with connecting to servers, and how to do this can vary greatly from distribution to distribution and largely depends on your window manager/display environment. Most systems come with Gnome and it is the default on the very popular Ubuntu distribution, so we'll give an example using the Files tool (also called Nautilus).

  • Page 63: Android

    Once you have installed the app you can launch it from that page, and if you want to access it again in the future, in the Files app if you go to the 3 dot menu at the top right and "Add new service" you then select "File System for Windows" from the list and it will give you the dialog to fill out with the server name and some other details, but only the server name/IP and share name are required.
  • Page 64 2) Click to find your network storage device. Scan Page 59 | 168...
  • Page 65 Page 60 | 168...
  • Page 66 Page 61 | 168...

  • Page 67: Dlna Server

    8.2. DLNA Server Some of GL.iNet routers support DLNA Server, but this is not a default function. You need to install a little plug-ins to make it workable. Supporting List: GL-AR750S-Ext, GL-AR750, GL-MT300N-V2, GL-AR300M series, GL-AR150 series, GL-MiFi and GL-X750 8.3.1.

  • Page 68: Use The Dlna Server In Gl.inet Routers

    8.3.2. Use the DLNA server in GL.iNet Routers After Installation of two applications, you can now use your GL.iNet router as as DLNA server. 1. Make suer you already has a TF card inserted into the card slot before you power up your router.
  • Page 69 In Windows File Explorer -> Network IOS: Install VLC or UPNP Extreme in App Store: Page 64 | 168...
  • Page 70 You can easily find the OpenWrt DLNA Sever in UPNP: UPNP Extreme and VLC Installation | UPNP Setup - | - Page 65 | 168...
  • Page 71 Page 66 | 168...
  • Page 72 Page 67 | 168...
  • Page 73 VLC Setup: Step 1： Click the Traffic Cones Logo on the left top, select Local Network Step 2: You can find the OpenWrt DLNA Server easily in Local Network. Step 1 | Step 2 - | - Page 68 | 168...
  • Page 74 Page 69 | 168...
  • Page 75 Page 70 | 168...

  • Page 76: Ddns

    Also other devices can easily find the OpenWrt DLNA Server easily. Enjoy your media DLNA Server by GL.iNET routers. 8.3. DDNS Dynamic Domain Name Service (DDNS) is a service used to map a domain name to the dynamic IP address of a network device. Setup DDNS requires firmware v3.010 or higher.
  • Page 77 The DDNS domain printed on the back label of router has changed. If your DDNS url is on the back of router, new DDNS url will xxxxxxx.gl-inet.com xxxxxxx.glddns.com 3) Check if DDNS is enabled command to check if your DDNS is enabled. You need to...
  • Page 78 nslookup xx5007c.glddns.com 8.8.8.8 The output above means the DDNS url has maped to a IP address. 4) HTTP Remote Access This function requires a public network IP. If your router is behind NAT, you may need to set up port forward in higher level router.
  • Page 79 After you enable HTTP Remote Access, you can access Admin Panel anywhere by your DDNS url of http, e.g. . If you use port forward, you http://xxxxxxx.glddns.com should be access like http://xxxxxxx.glddns.com:YourExternalPort 5) HTTPS Remote Access This function requires a public network IP. If your router is behind NAT, you may need to set up port forward in higher level router.
  • Page 80 Page 75 | 168...
  • Page 81 As show above, click "Advanced Page 76 | 168...
  • Page 82 As show above, click "Processed to xxxxxxx.glddns.com (unsafe)". After you enable HTTPS Remote Access, you can access Admin Panel anywhere by your DDNS url of https, e.g. . If you use port https://xxxxxxx.glddns.com forward, you should be access like https://xxxxxxx.glddns.com:YourExternalPort 6) SSH Remote Access This function requires a public network IP.

  • Page 83: Cloud

    After disable DDNS, the interface is like above. 8.4. Cloud Introduction GL.iNet GoodCloud cloud management service provide an easy and simple way to remotely access and manage routers. Check live router status • Live online offline status check • Live RAM and Load Average check Page 78 | 168...

  • Page 84: Setup

    • LTE Signal • Email alarm about online offline status update Set up routers remotely • Set up routers (e.g. SSID and Key) remotely Monitoring clients on routers remotely • Check who is on your network • Realtime traffic monitoring and block clients •...
  • Page 85 Local upgrade Open a web browser (we recommend Chrome) and to access router Web Admin Panel (default url is http://192.168.8.1). At the left side, UPGRADE -> Local Upgrade, select the firmware file you download, you can turn off "Keep Settings" for more stable, click "Install" button. It takes several minutes to install.
  • Page 86 Follow the steps above, to enable cloud management feature, choose the Data Server which is nearest your devices located. There are three Data Server, 'Global', 'America' and 'Europe'. If your devices are neither in America nor in Europe, just select 'Global'. Global Data Server is at Japan. Create GoodCloud account Visit https://www.goodcloud.xyz...
  • Page 87 Add a new group On the left side -> Groups List -> Add group. Follow the steps below to add a new group. Set the group name, company, description and location. Each device must belong to a group. Page 82 | 168...
  • Page 88 Add device On the left side -> Devices List -> Add Device. There are three methods to bind device to GoodCloud, "Auto discover", "Manually add" and "Bulk import". Auto discover Follow the steps below to add your device. If the router and PC(which opened goodcloud.xyz page) are at the same public IP，it will be automatically discovered, and can be found when click "Device"...
  • Page 89 Manually add If it can't discover automatically, try "Manually add". All information that need to input can be found on the back of the router. PS: Input "MAC", "SN" and "DDNS" / "Device ID" here just to verify that the router is really original and valid.
  • Page 90 For some new models, DDNS has been changed to Device ID on the back of router. Bulk import "Bulk import" is for user who have a great number of devices to add. By "Bulk import" you can import many devices by a Microsoft excel file. Page 85 | 168...
  • Page 91 Binded info on router Web Admin Panel After you seccessfully add router to GoodCloud, go back to router Web Admin Panel, APPLICATION -> Remote Access -> Cloud Management, press 'F5' to refresh this page, It will display the binded GoodCloud username, hover the username it will show the corresponding GoodCloud email account.

  • Page 92: Manage Your Devices

    Unbind router If you want to unbind router, click Unbind button. If you have any difficulties, please send email to admin@goodcloud.xyz for help. Manage your devices devices info and status Sign in Goodcloud, check at left side -> Device List Page 87 | 168...
  • Page 93 there is icon at the first column of this table, means this device is online. means this device is offline. means this device is deactivated, it has never connected to GoodCloud before. Page 88 | 168...
  • Page 94 Select the column you want to display. "Online time" is the latest time when device connected GoodCloud. "Offline time" is the latest time when device disconnected GoodCloud. "Update time" is the latest time when device connected or disconnected GoodCloud. IP, if your router run VPN client, this IP will be your VPN IP by default. Learn More LTE Signal...
  • Page 95 It will show Signal strength, Type, and relavant parameters. Device detail info At left side -> Device List, click the name of a online device, it will open a page to manage this device of WiFi, Clients and view router info, memory usage, up time, load average and log.
  • Page 96 Device info WiFi Modify all WiFi settings. Page 91 | 168...
  • Page 97 Router status Client list Timeline Timeline tab display the activities of router, and messages uploaded by the router's associated IoT device. Set email alarm You can set email alarm when a device is online, offline, and new client connected. At left side -> Setting -> Alarm Setting, create alarm rules Page 92 | 168...

  • Page 98: Site To Site

    Then set the email you want to receive notification. To ensure you get email successful, please add admin@goodcloud.xyz to your email address book. Site to Site Site to Site only support firmware v3.026 and above. Page 93 | 168...
  • Page 99 Site allows to remote access the IP camera. What conditions do I need to create Site to Site? One of the loations has a public static(or dynamic) ip, and two or more GL-iNet devices with latest testing firmware. Steps to build a Site to Site network.
  • Page 100 Defaul port is 51830, if you want to use another port, find the Advanced option at the lower left corner. Due to device's performance, each Site to Site network can have up to 10 devices. After you had chosen the devices, click Continue. Then, it will test each device if it can be set as the Main Node of Site to Site.
  • Page 101 We suggest that the router with strong performance and best network speed to be the Main Node. If none of the devices can be used as the Main Node, make sure that: • One of routers has a public IP, either static public IP or dynamic public IP. •...
  • Page 102 If there are more than one device can be set as the Main Node, you need to choose one to continue. Page 97 | 168...
  • Page 103 If there is only one device can be set as the Main Node, it will go to the Site to Site detail page directly. The network is stopped by default, check the LAN IP, if it is OK then you need to click Start button, otherwise click Setting to change LAN IP.
  • Page 104 Wait a few minutes, the node's connect status will display as lines. Solid line means connected, dashed line means disconnected. Page 99 | 168...
  • Page 105 Testing the Site to Site connection Now the Site to Site network is created and started, let's test the connection. Use your PC or Phone to connect to one of the Node of this Site to Site, and use browser to access another Node's LAN ip, if you see the login page, the connection between these two nodes is worked.
  • Page 106 You can add node's parent routes too. Each sub Node build an encrypted tunnel netwrok to Main Node, if you want to change the IP of tunnel subnet. Click 'IP Address Range'. Page 101 | 168...

  • Page 107: Batch Setting

    Batch Setting You can use this feature to configure multiple parameters for a single device, or you can configure multiple parameters for multiple devices. PS: This feature is only available to business users. Batch Setting of Single Device To configure single device, as show below. The left side of image below is correct.
  • Page 108 Check the configuration that needs to be modified and input value. The checked configuration is required, and only the configuration that conforms to the rule can be filled out. After the configuration is delivered, it does not take effect immediately. The configuration takes effect and the device needs to be restarted.
  • Page 109 Unchecked Restart now option will prompt. Batch Setting of Mutiple Device Select the devices you want to configure. Page 104 | 168...

  • Page 110: Template Management

    Other operations are the same as when operating a single device. Other Batch Operations Other Batch Operations: Move to other group, upgrade, restart, delete. Template Management Save frequently used configurations as templates and quickly apply them when you modify configurations in batches. PS: This feature is only available to business users.
  • Page 111 Give the template a name and description. Page 106 | 168...

  • Page 112: Task List

    Task List At task list page, it shows the execution result of the configuration template. PS: This feature is only available to business users. You can view the execution result of each device and configuration. Page 107 | 168...

  • Page 113: Ble Mqtt Bridge

    BLE MQTT Bridge Bluetooth Low Energy (BLE) is widely used for smart home, wearable and IoT sensors. This feature is for GL.iNet BLE gateway, GL-X750 Spitz and GL-S1300 convexa S which has built-in BLE modules. Read this to learn how to use them forward your BLE data to the cloud based on MQTT protocol, including GL.iNet GoodCloud and AWS IoT.

  • Page 114: Disable

    Disable To stop GoodCloud service, turn it off on router Web Admin Panel. Please follow the steps below. No action needed on the GoodCloud website. Page 109 | 168...
  • Page 115 After disable Cloud, the interface is like above. Turn on Captive Portal Open a web browser (we recommend Chrome) and to access router Web Admin Panel(default url is http://192.168.8.1). At the left sidebar, APPLICATIONS -> Portal, follow the steps below to enable Captive Portal.
  • Page 116 3) Set free internet time. 4) Certification URL is the default page that clients will force redirect to when they are connected, e.g. https://www.gl-inet.com 5) Apply the configuration. For wired desktop client, please use browser to access a http(not https) website, e.g.

  • Page 117: Tor

    Change the default page The default page is located , use SSH or WinSCP to /etc/nodogsplash/htdocs/ change this page. For more information about how to use SSH and WinSCP, please access this. You may need basic HTML and CSS knowledge to change this page, please learn these from w3school or other sites.
  • Page 118 If you don't want to upgrade, please read below. Free Tor firmware for all !!! Note This Tor firmware is totally free and no warranty. Refer to the forum for help! To use the Tor firmware: 1. Download the correct firmware for your router. 2.
  • Page 119 If you have questions about versions, please ask here or in the forum. Download and Flashing the firmware to the device All the firmwares is available at https://dl.gl-inet.com/firmware/ Find your device name and then "tor" folder. Download the newest firmware.
  • Page 120 Model Tor firmware path Newest Note Version GL.iNet6416 https://dl.gl-inet.com/firmware/6416/tor/ AR150 https://dl.gl-inet.com/firmware/ar150/tor/ 2.264 AR300M https://dl.gl- 2.264 .rar is for web upgrade .img is inet.com/firmware/ar300m/nand/tor/ for uboot upgrade AR300M- https://dl.gl- 2.264 inet.com/firmware/ar300m/tor/ MT300N https://dl.gl- 2.264 inet.com/firmware/mt300n/tor/ MT300A https://dl.gl- 2.264 inet.com/firmware/mt300a/tor/ GL-MiFi https://dl.gl-inet.com/firmware/ar150/tor/ MiFi don't have a Tor firmware itself.
  • Page 121 Login You will be asked to login using your password now. Homepage The UI is based on Domino Pi. It is quite simple. In your homepage you will be displayed with: 1. Your network status 2. Tor status. Please note if your tor reconnects this information may not be accurate.
  • Page 122 System and firmware upgrade You can click the button from the left sidebar to view the system SYSTEM information, including: 1. Your router's name 2. Change your password 3. Change your timezone 4. Check your firmware version and upgrade it, from online or mannually. Page 117 | 168...
  • Page 123 If the firmware on our website is newer, you can click and follow the Download instructions to upgrade the firmware. Network Settings Click the button on the left sidebar to view and change the network NETWORK settings, including: Page 118 | 168...
  • Page 124 1. Internet protocol: . Tethering only dhcp static pppoe tethering repeater works in Android phones. 2. Wireless parameters: ssid encryption passsword 3. LAN IP 3G 4G settings If you connect a 3G or 4G USB modem, you can set the internet to the modem. You need to choose as protocol, choose modem device, usually /dev/ttyUSBx...
  • Page 125 Repeater settings. It will search for available ssid automatically. You need to choose ssid and type your password. !!! NOTE This firmware don't have repeater manager as our stock firmware. If you move to another location, your wifi maybe not work and you need to re-setup. Refer to the button action section in this page.
  • Page 126 Reset button and hardware switch usage Reset button and switch is assigned special functions. Page 121 | 168...

  • Page 127: Ble Mqtt Bridge

    Reset 1. When you press down the reset button, the middle LED will start to flash once per second. Release your finger if the LED just flashed once (1 seconds), the Tor will try to change a new Exit node. 2.

  • Page 128: Introduction

    IoT solution. In this guide we will introduce two GL.iNet BLE gateway, GL-X750 which has built-in BLE modules and Spitz GL-S1300 convexa S how to use them to forward your BLE data to the cloud based on MQTT protocol, including GL.iNet...

  • Page 129: Ble Tools

    UI. But we are further developing this and you need to use the new BLE tool. root@GL-S1300:~# opkg remove gl-ble-daemon gl-ble-api root@GL-S1300:~# opkg install bletool Installing bletool (1-2) to root... Downloading http://download.gl-inet.com/releases/packages- 3.x/ipq40xx/glinet/bletool_1-2_ipq806x.ipk. Page 124 | 168...

  • Page 130: Mqtt

    You can find a detailed documentation about https://github.com/gl-inet/ble2mqtt. bletool MQTT MQTT is a machine-to-machine (M2M)/"Internet of Things" connectivity protocol. You can find official document in mqtt.org. This guide will give you a step to step guide of how to send message to GL.iNet GoodCloud and AWS.
  • Page 131 config service 'cloud' option enable '1' option check_status '1' option serverzone 'gslb-jp.goodcloud.xyz' option username 'your name' option email 'your@email.address' option bindtime '1558928701947' Forward data to GoodCloud To forward data to GoodCloud, you can use simple shell script. After your device is connected to your cloud account, you to the router, try the following command.
  • Page 132 Send Data to AWS IoT Amazon AWS IoT is a good choice for business applications. AWS seems to have good security and privacy protection. Here we will give an example of how to send your data to AWS IoT platform. It is a little complicated but still OK for IT specialist.
  • Page 133 2) On the Creating AWS IoT things page, choose Create a single thing. Page 128 | 168...
  • Page 134 3) On the Create a thing page, in the Name field, type a name for your thing, such as x750. Choose Next. 4) On the Add a certificate for your thing page, choose Create certificate. This generates an X.509 certificate and key pair. Page 129 | 168...
  • Page 135 5) On the Certificate created! page, download your public and private keys, certificate, and root certificate authority (CA): Choose Download for your certificate. • Choose Download for your private key. • Choose Download for the Amazon root CA. This will display a •...
  • Page 136 The RSA 2048 bit key: Amazon Root CA1 download web page: 6) Active your thing Back to the previous site, click "Activate", then click "Done". Page 131 | 168...
  • Page 137 2. Attach Policy 1) After you register your thing, you will need to create and attach a new policy to the certificate. Page 132 | 168...
  • Page 138 2) Enter a Name for the policy,such as x750_policy, then Advance mode 3) Delete the automatically created policy code, then paste the policy below. "Version": "2012-10-17", "Statement": [ "Action": [ "iot:Publish", "iot:Subscribe", "iot:Connect", "iot:Receive" "Effect": "Allow", "Resource": [ "*" 4) Create Policy after you pasted policy code. Page 133 | 168...
  • Page 139 5) On the left side, Secure --> Certificates, Select the certificate you just created, Actions --> Attach policy Page 134 | 168...
  • Page 140 6) Chose the policy you created(x750_policy) and choose Attach. 3. Config GL.iNet devices to connect to AWS IoT 1) Upload your certificate to the router Rename the downloaded certificate files : AmazonRootCA1.pem --> root_CA.crt xxxxxxxxxx.private.pem.key --> client.key xxxxxxxxxx. certificate.pem.crt --> client.crt Windows User use SSH and WinScp to transfer these three...
  • Page 141 Download the updated mqtt package, file name is 'gl-mqtt_3.0.37- 1_mips_24kc.ipk‘ Use WinSCP/SSH to transfer the package to /tmp/ , then delete the old package. opkg remove gl-mqtt --force-depends Then install the package: opkg install gl-mqtt_3.0.37-1_mips_24kc.ipk 3) Setup config file for your router Edit /etc/config/glconfig Add the following code to your glconfig file.
  • Page 142 option log '1' must be contained in the config file. Note** The topic ARN follows this format: arn:aws:iot:*your-region*:*your-aws-account*:topic/*<your/topic>* For example: arn:aws:iot:us-east-1:123456789012:topic/my/topic Topics The message broker uses topics to route messages from publishing clients to subscribing clients. The forward slash (/) is used to separate topic hierarchy.
  • Page 143 Wildcard Description , but not the messages published to Sensor/ Sensor/temp Sensor/temp/room1 Sensor Matches exactly one item in the topic hierarchy. For example, a subscription to Sensor/+/roo messages published to , and so on. Sensor/temp/room1 Sensor/moisture/room1 4) HTTP: API Endpoints add to router config file The message broker supports clients connecting with the HTTP protocol using a REST API.
  • Page 144 5) Connect your devices to AWS IoT Cloud Start connect to AWS Cloud /etc/init.d/gl_mqtt start Restart the mqtt services if its process is running. /etc/init.d/gl_mqtt restart Check mqtt process status ps | grep gl_mqtt 4. MQTT Communication Testing Test->Subscribe to a topic The subscription and publish topics in glconfig file: option sub_topic '/a1rLNyG2VK5/mqtt_demo/user/get' option pub_topic '/sys/a1rLNyG2VK5/mqtt_demo/thing/event/property/post'...
  • Page 145 Subscription Topic: '/sys/a1rLNyG2VK5/mqtt_demo/thing/event/property/post' Publish topic: '/a1rLNyG2VK5/mqtt_demo/user/get' Try Subscribe to topic, a message published by your router will be received in few seconds. Or Publish topic to your router a message: Page 140 | 168...

  • Page 146: Application And Demo

    A message published by AWS IoT Cloud will be received on your router in few seconds. logread Application and Demo Read BLE Thermal Sensor The following demo show how to read data from a thermal sensor, pack the data in JSON format and send to the GoodCloud. #!/usr/bin/sh .

  • Page 147: More Settings

    /tmp/blesniffer.log bletool end_procedure adv_data=`awk '{print $1}' /tmp/blesniffer.log` date=`date +"%Y%m%d%H%M%S"` json_init json_add_string "api" "/user/data" json_add_object "data" json_add_string "date" "$date" json_add_string "advertising data" "$adv_data" json_close_object json_close_object data=`json_dump` ubus call mqtt pub "$data" rm /tmp/blesniffer.log done 9. MORE SETTINGS 9.1. Admin Password Change the password of the web Admin Panel, which must be at least 5 characters long.

  • Page 148: Lan Ip

    9.2. LAN IP LAN IP is the IP address that you use to connect to this router. The default IP address of GL.iNet router is 192.168.8.1. If it conflicts with the IP address of your main router, you can change it. 9.3.

  • Page 149: Mac Clone

    9.4. MAC Clone Clone the MAC address of your current client to the router. It is used especially in hotel when the network checks your MAC address. For example, if you got your smartphone registered on the network, you can clone the MAC address of your smartphone to the router so that the router can also connect to the network.

  • Page 150: Custom Dns Server

    9.5. Custom DNS Server You can configure the DNS server of the router in order to prevent DNS leak or other purposes. DNS Rebinding Attack Protection: Some network may require authentication in captive portal. Disable this option if the captive portal of your network cannot be resolved.

  • Page 151: Revert Firmware

    mode. If you want to access the web Admin Panel in this case, you have to use the IP address assigned by the main router to the GL.iNet router. Router: Create your own private network. The router will act as NAT, firewall and DHCP server.

  • Page 152: Advanced

    9.8. Advanced Click to direct to Luci which is the default web interface of OpenWrt. Advanced You can check the detailed system log or conduct more advanced configurations there. Note: The username is root. The password is same as the one that you use to access the web Admin Panel.

  • Page 153: Troubleshooting

    10. Troubleshooting 10.1 LED Indicators LED Status Indication • Power: Solid green LED that indicates the router is powered up. Page 148 | 168...

  • Page 154: Led Customization

    • WAN: This router is connected to the Internet via Ethernet port. It will blink when the device has data transmission from Ethernet port • 2G Wi-Fi: Solid white LED that indicates the router is broadcasting 2G Wi-Fi. It will flash when there is wireless data transfer •...

  • Page 155: Repair Or Reset

    Then please choose System > LED Configuration. 10.2 Repair or Reset How to Repair / Reset All GL.iNet Routers have reset buttons, you can use them to repair your network or reset your routers to factory defult. If you can neither access the web-based setup page nor the router, you can press the button: reset...

  • Page 156: Debrick Via Uboot

    Reset Button 10.3 Debrick via Uboot Using Uboot to Debrick Your Router You may have bricked your router if you were doing some DIY projects or flashed a wrong firmware. You may not be able to access your router but you can re- install the firmware by using Uboot failsafe.
  • Page 157 • 6 times for GL-MiFi, and then the LTE light will faintly flash twice. • 5 times for GL-AR150, GL-AR300M, GL-USB150, GL-AR750, GL- AR750S-Ext (Slate), GL-X750-Ext (Spitz), GL-MT300N-V2, GL-E750 (Mudi). • 4 times for GL-S1300, GL-B1300. The leftmost LED may stay on the whole time while the rightmost LED flashes 4 times, then the middle LED turns on and stays on.
  • Page 158 7. Use Firefox or Chrome to visit http://192.168.1.1. 8. Click Choose File to find the firmware file. Then click Update firmware. For GL-AR300M, GL-AR300M-Ext, GL-AR750S-Ext, please download the .img firmware file and upload to the NAND Page 153 | 168...

  • Page 159: Change Wan To Lan

    flash. 9. Wait for around 3 minutes. Don’t power off your device when updating. The router is ready when both power and Wi-Fi LED are on or you can find its SSID on your device. 10. Revert the IP setting you did in step 6 and connect your device to the LAN or Wi-Fi of the router.
  • Page 160 1. Leave the WAN port of the router unconnected. 2. Connect your device to the router and access the web Admin Panel. 3. Go to Internet, click Use as LAN under the Cable section. 4. Click Yes to confirm. Page 155 | 168...

  • Page 161: Captive Portal

    You can simply revert the setting by repeating the above procedures. This time, it will show Use as WAN in step 3. 10.5 Captive Portal Connect to a Hotspot with Captive Portal Some public hotspots especially those in hotel, cafe or airport, require you to input your authentication information or agree the terms and conditions through a web page (Captive Portal) before you can connect to it or access the Internet.
  • Page 162 2. Go to Admin Panel -> MORE SETTINGS -> Custom DNS Server. Then, disable DNS Rebinding Attack Protection. Page 157 | 168...

  • Page 163: Gl.inet App

    3. Use your web browser to visit a webpage, it will be redirected to the captive portal of the hotspot automatically. If you are using smartphone but your web browser doesn't redirect to the captive portal. Please turn off the Wi-Fi of your smartphone and then turn it on and reconnect to the Wi-Fi of your router again.
  • Page 164 Then click the Upgrade on the left side. Some models don't have V3.100 release firmware yet, please try testing(pre- release) firmware. Please find the download info at Firmware Release page. Page 159 | 168...

  • Page 165: Access Web Panel

    10.7 Access Web Panel Sometimes you may be unable to access 192.168.8.1 to login web admin panel, please follow the guide below to solve this problem. Check connection/router's IP address Make sure your WAN/LAN port connection is correct. WAN port is connected to an internet source and LAN port is connected to devices.

  • Page 166: Extensible Authentication Protocol (Eap)

    10.8 Extensible Authentication Protocol (EAP) Introduction You can connect to EAP (Extensible Authentication Protocol) Wi-Fi network which requires username and password authentication on GL.iNet routers. This guide is how to connect an EAP Wi-Fi network via GL admin panel. • All models are supported EAP EXCEPT GL-MT300N-V2, Microuter N300 Page 161 | 168...

  • Page 167: Connect Via Web Panel

    Connect via web panel 1. Visit the Admin Panel Visit the Admin Panel and click “Scan” in the Internet -> Repeater. You can find and connect to the EAP SSID to connect directly. Page 162 | 168...
  • Page 168 2. SSID Or choose “Other” in the drop-down list of SSID, then select EAP type in Wi-Fi Security drop-down list. 3. Wi-Fi Security Currently, we only support two types: 802.1X EAP/WAP and 802.1X EAP/WAP2. Page 163 | 168...
  • Page 169 4. Type Choose 2.4G or 5G. 5. User Name and Password Enter your User Name and Password and then click join. Page 164 | 168...

  • Page 170: Connect Via Luci

    Connect via Luci Our web page only supports few EAP types for now so you may need to connect via Luci page in most situations. 1. Visit the Luci page Go to MORE SETTINGS->Advanced. Input your web password. Then you will enter luci page. Page 165 | 168...
  • Page 171 2. Connect to EAP wifi Go to Network->Wifi(or Wireless). Click 'Scan' on 2.4G section or 5G section. Page 166 | 168...

  • Page 172: Goodcloud Issues

    Join the network you want. 10.9 GoodCloud issues How to fix if my device show "Deactivated" The "Deactivated" mean the device never been connected to the server before. Page 167 | 168...
  • Page 173 1. Make sure the router has connected to the Internet. 2. And try to disable and re-enable the GoodCloud on router's Admin Panel. Don't forget to click "Apply" button. 3. Make sure to access to the right region of GoodCloud. Page 168 | 168...
