HSS Hire 41310 Operating & Safety Manual

10kVA Silenced Diesel Generator
Thermal
Cutout
115V
0000110
16A
PREHEAT
10A
Preheat
Button
115V 32A
230V
32A Ignition
Key
Earthing
Point
Connect up the equipment you want to power using
suitable cables and plugs, making sure their switches
are OFF.
Finally, select the voltage required by moving the
voltage selector switch to either 115V or 230V.
Power Limits
Never overload the generator. To calculate the
running load, add up the power ratings of
everything to be connected to it in kilowatts 1kW
(kilowatt) = 1000 W (Watts). Depending on the
equipment being powered this should be between
half and two - thirds the generator' s kVA rating but,
if in doubt, ask your local HSS Hire Shop for advice.
Never push the equipment beyond its design limits.
If it will not do what want you want with reasonable ease
230V 16A
assume you have the wrong size generator for the job. Ask
at your local HSS Hire Shop for advice.
Keep the equipment clean. You will find this less of a
Circuit chore if you clean up regularly rather than wait until the
end of the hire.
Breaker
When not in use, store the equipment somewhere
Voltage
230V 0 115V
clean, dry and safe from thieves.
h
Selector
Regularly check the fuel level and top up as
OFF
ON
Oil
START
necessary with clean, fresh diesel.
Warning
Regularly check the oil level - when the engine is cold
Lamp
and on level ground. Withdraw the dipstick, wipe it clean,
then replace it, remove it a second time and verify that the
Fuel
oil level is between the min and max lines, top up as
Warning
necessary.
Lamp
Suitable oils are available on sale or return from your local
HSS Hire Shop.
Lifting Etc.
Switch OFF all equipment powered by the generator.
Turn the ignition key to 'OFF' and wait for the
engine to stop then close the fuel tap.
Finally, disconnect all the plugs connected to it then
give the unit a final clean, ready for return to your local
HSS Hire Shop.
Forklift Slots
If you have any suggestions to enable us to improve
the information within this guide please fax your
comments or write to the Product Manager at the
©HSS Hire Service Group Plc 2003 No.375/01
Group Office: 25 Willow Lane, Mitcham, Surrey CR4 4TS

EQUIPMENT CARE

FINISHING OFF

...any comments?
address below
Fax: 020 8687 5001
Web Site: http://www.hss.com
Operating & Safety Guide 375
10kVA Silenced
Diesel Generator
A wheel mounted generator, delivering
10kVA of power in 230V or 115V.
Fitted with an electric start engine.
Code 41310
