Summary of Contents for Schleifenbauer V2.62

  • Page 1         V2.62 Schleifenbauer PDU User manual        ...
  • Page 2: Table Of Contents

    How to check the load balance, the temperature / humidity or the status of the NO/NC contact? 15  How to get back to the first page? 16  How to check an outlet status locally? 16  How to check input and/or outlet measurements? 16      Page 2 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 3 How to change the Ethernet link settings? 42  Network configurations 43  DHCP and default address 43  How to change the hostname? 43  How to configure the IP settings manually? 43  How to setup IPv6? 44      Page 3 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 4 Schleifenbauer databus: what is it? 52  How to prevent data losses because of cable cuts? Ring redundancy 53  How to create a databus using Schleifenbauer Gateway? 54  How to connect the databus to LAN without a Gateway? Using a PDU! 55 ...
  • Page 5: Overview

      V ERVIEW The Schleifenbauer Power Distribution Unit (PDU) is fully configurable and allows customers to connect a variety of power  appliances. Furthermore, the PDU allows remote management through a number of protocols which allow users to  monitor metered sockets and receive alarms on custom thresholds. This manual is split in four sections: ...
  • Page 6: Introduction

    The Schleifenbauer Intelligent Power Distribution Unit (PDU) is designed to distribute power for many years and without  problems. The PDU is equipped with a specially developed Schleifenbauer databus which makes it possible to read and  manage many PDUs with a single IP address. An ethernet port is added to each PDU so that next to the advantages of a ...
  • Page 7: Colored Housing

    C​   ​ LORED​ H OUSING   The default enclosure color of the Schleifenbauer PDUs is black. It is also possible to anodize the enclosure in five other  colors.   01. black  02. green    03. orange  04. blue  05. red ...
  • Page 8: Part I - Installation Of Hardware

    RT​ STALLATION​ F​ H ARDWARE Please use the information in this chapter to inspect, install and connect the Schleifenbauer Intelligent PDU and all  optional mentioned accessories.    The PDU must be installed in a restricted access location  Socket-outlet must be installed near the equipment  ...
  • Page 9: Testing

      T​   E STING Each Schleifenbauer PDU is individually tested according to the NEN 3140 standard. Test reports are available on request.        For measurement of insulation resistance, the measuring voltage used must be lower than or equal to the ...
  • Page 10: How To Mount A Pdu Vertically (= 0U)

    PDU housing. There is a wide range of cabinet brackets available, all in  which you can hang the PDU without using tools.   Toolless Mounting can be done as single PDU or double PDUs (see image).     Mounting brackets can be custom made by Schleifenbauer.       ...
  • Page 11: Cabling The Pdu: Ethernet, Databus And Sensors

    “incoming” databus port. The right databus port is “outgoing”. This is a  MUST HAVE for devices in bridge mode. For devices in hybrid mode it is a  NICE TO HAVE. The serial databus in the Schleifenbauer PDU uses CAT5  patch cables. ...
  • Page 12: How To Connect A No/Nc Contact On Classic Pdu And Ethernet Pdu

    How to connect NO/NC contact on a G3 PDU?  3rd generation PDUs and DPMs are equipped with a USB-port and are able to operate two NO/NC dry switch contacts:            Page 12 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 13: Part Ii - User Manual

       A Schleifenbauer Intelligent PDU ​ m ay not be opened by unauthorized personnel​ . In the event of malfunction or faults in  the PDU, please refer to the warranty conditions. Schleifenbauer Products BV will not accept warranty claims if the PDU ...
  • Page 14: Part Iia - Locally Monitoring: Device Display

    Changing settings locally via the PDU itself is ​ n ot​ possible! You have to use one of the interfaces.       See the ​ A dministrator part​ of this manual how to changes the settings                Page 14 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 15: How To Stop A Blinking Display? Local Alert Reset

    DS =  status of NO/NC contact  [ O = open; C = closed ]    Te = temperature  [degrees C] *  RH =  relative humidity [%] *  *only visible when the corresponding sensor has been connected.      Page 15 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 16: How To Get Back To The First Page

    [V]  Pf =  power factor  (= real power ÷ apparent power)  Et = energy total  [kW]    Es = subtotal energy  [kW]  Example: outlet page            Page 16 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 17: How To Read Measurements Of Optional Sensors And What Options Are Possible

      error status      Example: sensor page 2 of 2 Y =  activity        For all optional sensors see ​ ww.schleifenbauer.eu          Page 17 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 18: How To Read Branch Residual Current Measurements

    RC-sensors and monitor them  permanently. RC-monitoring can take place in many forms. The Schleifenbauer RC-sensor offers Class B metering, thus  enabling our customers to set-up an RC-monitoring system that prevents dangerous situations inside the datacenter. ...
  • Page 19: How To View Pdu Connection Information

    Text is white and the background is blue.    When the interface is used, the text becomes blue and the  background white.            Page 19 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 20: How To Check The Installed Firmware Version

    ● = serial number (also found on the PDU housing)  ● = product identification (also found on the PDU housing)  ● = order number for internal Schleifenbauer uses  ●   = number of phases of this device  ● = total number of outlets on this device ...
  • Page 21: Part Iib - Remote Operating And Monitoring: Web Interface

    B​ I NTERFACE Introduction  Schleifenbauer PDUs allow remote administration which enables users to switch on or off selected outlets, monitor usage  data and set/receive alerts on configured thresholds. In addition various connection parameters can also be configured  through various protocols. ...
  • Page 22: User Interface

    To open protected cells, you first have to click the “Locked” sign and the    status will change to “Editable”.    When ready, click “Editable” or click the “Save changes” icon if shown, and the sign  will turn into “Locked”.      Page 22 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 23: D Ashboardt Ab

          Looking for the reason why an alert occured? In the <System  Status> box the PDU gives you a possible cause of the alert.    9        Page 23 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 24 When multiple outlets are in alert state, the highest outlet will be indicated   0 = OK , “Detected at outlet 9” means that there was a current drop at outlet “9”             Page 24 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 25 Input overcurrent thresholds can be changed at the < Inputs > tab  Outlet overcurrent thresholds can be changed at the < Outlets > tab    General alert setting can be changed at the < System > tab            Page 25 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 26: Load

    Data shown is read-only and gives an  overview of the statuses of the  interfaces.    This block is only shown for devices in    BRIDGE mode               Page 26 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 27: S Ensorst Ab

    G3 devices - equipped with an USB port - can handle two dry switch contacts (see example image above)  value  Shows the actual sensor value.              Page 27 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 28: Inputs - Tab

    Field in which the maximum current [A] is configured for this line, what the actual current is  at  allowed to reach. Exceeding this limit will cause an alert.    ➢ See also chapter: System tab > ​ R eset ​ & ​ S ettings     Page 28 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 29: Outlets - Tab

    Highest current per line since the last “reset peaks and dips”.    ➢ See also chapter: ​ S ystem tab > Reset voltage  Actual voltage [V] per outlet.            Page 29 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 30 After you have made a choice, the state of the outlet is changing ​ ( ​ S ee “state” in this table)  While the given command is processed, a status bar shows the progression of the action.                   Page 30 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 31: S Ystemt Ab

      S​ –   ​ STEM​ T AB       On the next pages the different sections of the system tab are described.              Page 31 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 32: Identification

    Current firmware version installed on the PDU.  Please check the website for the latest version: ​ ww.schleifenbauer.eu   ➢   SPDM version  The actual version of the Schleifenbauer Products Data Model.    sales order  Reference of initial Schleifenbauer sales order number.  number   ...
  • Page 33: Configuration

    Provides the ability to clear alerts on the PDU by pressing both “Page up” and “Page down”  allowed  buttons (next to the display) at the same time.      Page 33 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 34: Settings

    Actual current = 0.4A, drops to 0A -> no alert  ● Actual current = 1A, drops to 0.6A -> no alert  ● Actual current = 1A, drops to 0.4A -> alert occurs  ●         Page 34 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 35     Auto shut down is factory default on Schleifenbauer PDUs. When power distribution to the PDU  fails, all outlets will shut down; which of course leads to shut down of connected servers and  other equipment. The function of the auto shut down is to prevent peak currents damaging ...
  • Page 36: Locate

    Stop blinking  Stops blinking of the PDU display. Blinking can also be stopped by pressing one of the buttons on  the PDU.   Note: Firmware 2.62 or newer required.        Page 36 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 37: Interfaces - Tab

    I​ –   ​ TERFACES​ T AB     The sections of this screen are described in specific manuals. These can be downloaded from our website:  www.schleifenbauer.eu          Page 37 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 38: Part Iii - Administrator Manual

    SPBUS_protocol  Provides a concrete and clear description for developers who intend to  integrate the SPBUS (Schleifenbauer Products BUS) protocol into their  (custom) software solutions.  SPAPI   Describe a high-level API for SPBUS devices such that users using the API ...
  • Page 39: How To Change Snmpv3 Settings

    Not working using SNMP on a Classic PDU:  - input subtotal reset per phase  - outlet reboot  - Power (W) and Power (VA), invalid value (0.0)                      Page 39 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 40: How To Use The 'Device List' Section In The Web Interface

    So start with [4] which is the device on    top in the list that was found first.      Page 40 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 41: How To Configure Login Profiles, Usernames And Passwords

    SNMPv3. In the web interface the user accounts are in decreasing order of access rights: super, admin, power, user and  viewer. It should be noted that super is only intended for use by Schleifenbauer personnel. The access rights of the ...
  • Page 42: How To Change Factory Passwords

    PDU to be able to access the PDU again. If this doesn’t solve the  problem: Try a ​ f actory reset​ .       Page 42 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 43: Network Configurations

    How to change the hostname?  It’s possible for users to change the hostname of their devices. A hostname consists of a Schleifenbauer prefix and the  serial number by default. There are three options: custom hostname, Schleifenbauer prefix combined with a sysname, or ...
  • Page 44: How To Setup Ipv6

      How to setup IPv6?  Since firmware version FW2.44, IPv6 support has been introduced in the Schleifenbauer PDU. This feature is disabled by  default.     An IPv6 address consists of 8 blocks of 4 hexadecimal digits separated by columns ( : ). Consecutive blocks of zeroes can ...
  • Page 45: How To Configure Ipv6

    Enabling IPv6 adds an additional page to the PDU  display named "IPv6 LINK" (see image). The current  IP Mode is also visible if the user navigates to the "IP  INTERFACES" display.      ​ h ttps://en.wikipedia.org/wiki/Link-local_address#IPv6     Page 45 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 46: How To Set Up Ipv6 Address Filtering

    IPv6 subnetting . Please note that filtering requires a complete and valid IP address to function properly. IPv6 filtering ranges  PDUs current IPv6 addresses.        ​ h ttps://en.wikipedia.org/wiki/IPv6_subnetting_reference     Page 46 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 47: Configure Ssl Certificates

    Encryption etc) are selected from what the client lists as supported in the "Client Hello". The following cipher suites are  supported:      Static Key with RSA:      MBEDTLS_TLS_RSA_WITH_AES_128_GCM_SHA256  ● MBEDTLS_TLS_RSA_WITH_AES_128_CBC_SHA256  ● MBEDTLS_TLS_RSA_WITH_AES_256_CBC_SHA256  ● MBEDTLS_TLS_RSA_WITH_AES_128_CBC_SHA  ● MBEDTLS_TLS_RSA_WITH_AES_256_CBC_SHA  ●           Page 47 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 48: Note On Self-Signed Certificates

    Select or add HTTPS to the webserver section “HTTP/HTTPS”  Select the port (default: 443) you want to use for communication with HTTPS  Click “Save Changes”                Page 48 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 49: How To Send Snmp Traps With Ipv6

    IPv4 addresses if IPv4 is enabled and IPv6 addresses if IPv6 is enabled, or both when dual-stack is enabled at IP  Protocol select.  Using IPv6 traps     Page 49 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 50: How To Stop Alert Signaling? (Auto Reset Alert)

      When a Schleifenbauer Gateway is present in the databus make sure the Gateway firmware is upgraded first. This firmware  is listed on the documentation page of the Schleifenbauer website. The latest firmware, manual and updater tool is listed ...
  • Page 51: How To Upgrade The Firmware? Using Usb

    USB interface with the Modbus or SNMP interface.    Download the latest firmware from ​ h ttps://docs.schleifenbauer.eu/?dir=Firmware​ .   The firmware is provided as a single ZIP-archive. Please extract the ​ e ntire contents​ of this archive onto a ​ b lank ...
  • Page 52: Schleifenbauer Databus: What Is It

    Databus and power distribution are separated in the  all “daisy chained” devices must be in  ● Schleifenbauer PDU. All operations on the databus do  “​ YBRID​ ” mode; these are the BRIDGED  NOT interfere with the distribution of power to the ...
  • Page 53: How To Prevent Data Losses Because Of Cable Cuts? Ring Redundancy

    However, Schleifenbauer has made their bus redundant. A single cable cut will not affect the readout or control of the PDUs; it will try to get access through the alternative route on the ring. A cable cut is detected by our firmware and an error message will be submitted to the database.
  • Page 54: How To Create A Databus Using Schleifenbauer Gateway

    The Classic PDU has NO ethernet port, so a  Schleifenbauer-devices (not only PDUs but also the  (Schleifenbauer) Gateway is needed in order to get PDUs  Schleifenbauer DPM-range (=energy meters).  connected to your LAN. The sequence of devices does ...
  • Page 55: How To Connect The Databus To Lan Without A Gateway? Using A Pdu

    The image shows that different  50 devices which means that querying each  Schleifenbauer devices can be connected in a ring which  device once will take approximately ten  makes the system easily scalable to customer needs. It is ...
  • Page 56: Part Iv - Problem Solving

    Please note that because the power is removed, outlets will also be out of power. Hence, during this process there won’t  be any measuring.     Please keep in mind that kWh totals will ​ N OT​ be reset during this process.           Page 56 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 57: How To Reset Peak Current? And Other Dips Or Peaks

    Clear the alert locally or by the reset button in the <Reset> section in the System-tab, the peak current will not be cleared.  This is done manually by clicking the <reset peaks and dips> button in the <Reset> section of the System-tab:            Page 57 of 58  V262_User manual   Schleifenbauer PDU   ...
  • Page 58: Recycling

    Schleifenbauer Products aims to be a socially responsible corporation. Therefore, it makes great effort to minimise the  impact of our products to our planet during production as well as during operation. Packaging consists of recyclable  materials and Schleifenbauer asks their customers to save them for future use or to dispose of them with applicable  regulations. ...
