Features:
Operate one or more boosters -with a single PS2012 supply.
Scale selectable for use with N, HO or large scale.
Design Coordinated for use with Digitrax products
Built-in unit over-current and over-temp protection
DC Output Current Ammeter
On/Off Switch
Integral Cooling fan
One 'Y' Cable (P/N YC52) Included for convenience with dual 5 amp
protected outputs
©2004 Digitrax, Inc
D
C
igitrax
ommand
Run Your Trains, Not Your Track!
www.digitrax.com
C
ontrol
20 Amp
All Scales
Regulated
Power Supply
Advertisement
Table of Contents
Related Manuals for Digitrax PS2012
Summary of Contents for Digitrax PS2012
- Page 1 All Scales Regulated Power Supply Features: Operate one or more boosters -with a single PS2012 supply. Scale selectable for use with N, HO or large scale. Design Coordinated for use with Digitrax products Built-in unit over-current and over-temp protection DC Output Current Ammeter...
- Page 2 In addition to the power on/off switch, the PS2012 has a selector switch for N scale, HO scale, and G (or large scale) operation. The unit also has a built-in output cur- rent meter for monitoring total layout current load.
- Page 3 All secondary devices need to be properly fused on their power input leads for their rated capacity. For example if you intend to use the PS2012 to drive a 5 and an 8 amp booster, you must input fuse these devices for 5 and 8 amps...
- Page 4 Run Your Trains, Not Your Track! Configuration To connect the PS2012 to boosters and other 5 amp rated devices, use the ‘Y’ cable shown below: Power outputs to boosters or other To PS2012 output bind- devices ing posts...
