Summary of Contents for AIRSHIP DR350B
- Page 1 AIRSHIP Obstacle Avoidance Drone User’s Guide for Model DR350B v2354-01...
- Page 2 Warnings & Precautions Important Safety Instructions • Flying at night is not recommended. • Never try to retrieve the craft from areas you cannot • Read and follow all instructions. safely reach, such as rooftops or trees. • Keep these instructions for future reference. • Never leave the craft unattended while it is powered • Heed all Warnings. on or while the battery is charging. • Intended for children ages 14 and higher. Adult supervision is required. FCC Warnings • Only use attachments/accessories specified by the Warning: Changes or modifications to this unit not manufacturer. expressly approved by the party responsible for • Before flying, always check the body, rotors, and compliance could void the user’s authority to operate battery for any damage or obstructions. the equipment. • Battery should be free from cracks or swelling. NOTE: This equipment has been tested and found to • Keep the rotors clear of any obstructions and body comply with the limits for a Class B digital device, parts to avoid potential damage and injury.
- Page 3 Warnings & Precautions • Reorient or relocate the receiving antenna. incorrectly replaced. Replace only with the same or • Increase the separation between the equipment and equivalent type. receiver. • Lithium batteries, like all rechargeable batteries, are • Connect the equipment into an outlet on a circuit recyclable and should be recycled or disposed of different from that to which the receiver is connected. according to state and local guidelines. They should • Consult the dealer or an experienced radio/TV never be disposed of in normal household waste, technician for help. and they should never be incinerated, as they might This device complies with Part 15 of the FCC Rules. explode. Contact your local government for disposal Operation is subject to the following two conditions: or recycling practices in your area. 1.This device may not cause harmful interference, and • WARNING: Shock hazard - Do Not Open. 2.This device must accept any interference received, • Battery shall not be exposed to excessive heat such as including interference that my cause undesired sunshine, fire, or the like. operation. • WARNING: DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD. If you think batteries Additional Warnings & Precautions might have been swallowed or placed inside any part of the body, seek immediate medical attention.
-
Page 4: Table Of Contents
Table of Contents Airship Drone Troubleshooting Features–5 Guide–14 Includes–5 Customer Support Overview Contact Information–15 Features & Layout–6 International Support–15 Warranty–15 Charging the Battery Battery Charging Procedure–8 Flying Step 1–10 Step 2–11 Remote–12 Gyroscope Calibration–13 Tips for Safe Operation–13... -
Page 5: Airship Drone
Airship Drone Features Includes • Built-in obstacle avoidance sensors • Remote control with built-in CR2032 button cell battery • LED lights • USB cable for battery recharge • Built-in, rechargeable lithium-polymer battery power • User’s guide • Remote control distance: up to 16 ft. -
Page 6: Overview
Overview Features & Layout Protective Cage LED Lights Rotors Obstacle Avoidance Sensors... - Page 7 Obstacle Power Button Avoidance Sensors Charging Port Motors...
-
Page 8: Charging The Battery
Charging the Battery Battery Charging Procedure The craft’s battery must be charged before it can be flown. Before charging, be sure the craft is powered OFF to avoid the risk of injury or damage. Connect the charging cable (included) to the USB port of a powered ON computer or USB power adapter (not included), then connect the charging plug to the unit. - Page 9 REMINDER: Do not charge overnight. Do not leave unattended while charging.
-
Page 10: Flying
Flying Step 1 When the drone powers ON, it automatically enters Rotation Mode, indicated by a green light. In this mode, the craft will spin around its axis as it flies. To fly in Non-Rotation Mode, press the power button again after powering on. The indicator light will turn blue, and the craft will fly without spinning. - Page 11 Step 2 While the craft is in the air, it will spin in a circle and hover automatically. You can control it just by “pushing” with your hand. The sensors on the drone will detect your hand, and it will move in the opposite direction.
- Page 12 Flying Remote You can use the remote to make the drone take off and land. Be sure the drone is powered on and calibrated (see Step 1), then press the button on the remote to take off. Use the remote to land the drone automatically. Do not grab it out of the air, for risk of injury or damage.
-
Page 13: Gyroscope Calibration-13
Gyroscope Calibration Take the drone in your hand and shake it back and forth a few times to put it into Gyroscope Calibration Mode. When the LED lights start to blink, the sensors are ready to be calibrated. Place the drone on a flat level surface during the calibration period. When the LED lights have turned solid, the calibration is complete. -
Page 14: Troubleshooting
Troubleshooting Guide PROBLEM POSSIBLE CAUSES SOLUTION Craft flies erratically. • Gyroscopes may • Recalibrate the be misaligned. gyroscopes (see pg. 13). Craft suffers from • Obstruction in rotors or • Safely clear the protective frame. obstruction. mechanical trouble. LED lights ON but • ... -
Page 15: Customer Support
Customer Support Contact Information Warranty Website: www.gpx.com See included 30 Day Warranty for warranty information. Warranty and the most up-to- Email Support: prodinfo@dpiinc.com date version of this User’s Guide can also be found at: www.gpx.com Email Parts: partsinfo@dpiinc.com Phone Support: 1-888-999-4215 International Support To download this User’s Guide in English, Spanish, and French, or to get answers to frequently asked questions, visit the support section at: www.gpx.com... - Page 16 Made Green Protect for Today Sustain for Tomorrow Copyright © 2019 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners. Specifications are subject to change without notice.
