USER MANUAL
Designed and developed by Sinevibes ©2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the Node and is the answer not in the manual?

Questions and answers

Summary of Contents for Sinevibes Node

  • Page 1 USER MANUAL Designed and developed by Sinevibes ©2020...
  • Page 2 INTRODUCTION 1/11 Node is a four-operator FM synthesis engine for KORG prologue, minilogue xd and NTS-1. It is based on a classic setup with four sine oscillators (operators), which are connected together via multiple different algorithms that let them apply frequency modulation onto one another. This plugin neatly packages a total of 24 such FM algorithms and allows to set operator frequency ratios within an extremely wide range, delivering nearly 90,000 possible combinations –...

  • Page 3: Before You Start

    BEFORE YOU START 2/11 Before you install third-party plugins, please make sure that you have the latest system update installed on your KORG synthesizer, and that you also perform the panel update and voice update procedures if they are required. Older system versions can have major issues with newer plugins. You should keep the Sound Librarian application updated as well.
  • Page 4 2. Launch the Sound Librarian application on your computer. 3. Switch to the USER OSCILLATORS tab. 4. Drag and drop the Node plugin file into any available oscillator slot. 5. Click the SEND ALL button in the USER OSC/FX toolbar section.
  • Page 5 2. Launch the Sound Librarian application on your computer. 3. Stay in the default PROGRAMS tab. 4. In the Node package, open the Presets folder, and then open the folder corresponding to the slot number into which you installed the plugin.
  • Page 6 5/11 To use Node for creating your own sounds, you need to load the plugin into the MULTI ENGINE oscillator. It is best to start from an initialized preset to make sure that there are no pre-existing sound adjustments that could prevent the plugin from sounding correctly.

  • Page 7: Editing Parameters

    EDITING PARAMETERS 6/11 Like all multi-engine plugins, Node includes additional parameters that enable deep customization. Below are the instructions for accessing and editing them depending on the device model. For the detailed description of what each parameter does, please see the PARAMETER GUIDE.

  • Page 8: Parameter Guide

    PARAMETER GUIDE 7/11 SHAPE / A SHIFT+SHAPE / B Algorithm Ratio 2:1 Simultaneously adjust the Adjust the amount of Select the FM operator Select the FM operator 2 amount of modulation frequency detune of configuration algorithm. frequency ratio in relation depth for all operators as operators 2, 3, 4 in relation Even algorithm numbers...
  • Page 9 1. oscillator shape, its spectrum contains frequency than operator 1 – which Node allows these to be set from 0.5 to just a single frequency partial. In Node, means the operator 2:1 ratio is 2.0.
  • Page 10 ALGORITHM CHART 9/11...
  • Page 11 MODULATOR MODES 10/11 Exponential decay-sustain EG Square LFO Exponential attack-sustain EG Square LFO, inverted Exponential attack-decay-sustain EG 80% pulse LFO Exponential attack-decay-sustain EG, 80% pulse LFO, inverted attack time 10x shorter than decay time Linear decay-sustain EG 20% pulse LFO Linear attack-sustain EG 20% pulse LFO, inverted Linear attack-decay-sustain EG...

  • Page 12: Tips And Tricks

    TIPS & TRICKS 11/11 – You can use the filter on your synthesizer to further sculpt the Node’s sound. This works especially well if Node is producing a harmonically rich waveform (with high FM modulation depth value). To create sounds with complicated motion, try adding both shape modulation via Node’s built-in modulation generator plus...
  • Page 13 SINEVIBES ROCKET FUEL FOR YOUR CREATIVITY www.sinevibes.com...
