TRIATEK FMS-2000M Lite Installation Manual

Critical environment monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FMS-2000M Lite
Critical Environment Monitor
LIT-12013692
Installation Guide
December 2020
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FMS-2000M Lite and is the answer not in the manual?

Questions and answers

Related Manuals for TRIATEK FMS-2000M Lite

Summary of Contents for TRIATEK FMS-2000M Lite

  • Page 1 FMS-2000M Lite Critical Environment Monitor LIT-12013692 Installation Guide December 2020...
  • Page 2 Risk of Property Damage. Do not connect the 24 VAC power supply directly to the FMS-2000M Lite display four-position terminal block. You must terminate the power at the remote sensor's nine-position terminal block on the +Vin and -Vin terminals. Failure to follow the wiring instructions may cause permanent damage to the FMS-2000M Lite monitor and void your warranty.
  • Page 3 IMPORTANT: Only qualified personnel should install or service Johnson Controls® products. These instructions are a guide for such personnel. Carefully follow all instructions in this document and all instructions for the FMS-2000M Lite Critical Environment Monitor. IMPORTANT: Use copper conductors only. Make all wiring connections in accordance with local, national, and regional regulations. Do not exceed the FMS-2000M Lite Critical Environment Monitor’s electrical ratings.
  • Page 4 Risque de dégâts matériels. Ne pas brancher le bloc d’alimentation de 24 V CA directement au bornier à quatre positions de l’écran du FMS-2000M Lite. Vous devez raccorder l’alimentation aux bornes +Vin et -Vin du bornier à neuf positions du capteur à distance. Ne pas respecter les instructions de câblage peut causer des dommages permanents au moniteur FMS-2000M Lite et annuler votre garantie.
  • Page 5 IMPORTANT : Seul le personnel qualifié peut installer et entretenir les produits Johnson Controls. Ces instructions constituent un guide pour ce type de personnel. Suivez attentivement toutes les instructions de ce document et toutes les instructions du FMS-2000M Lite Critical Environment Monitor.

  • Page 6: Table Of Contents

    Introduction ....................................7 Location considerations ................................8 Installing the FMS-2000M Lite Thin Mount display for a retrofit application ................. 9 Installing the FMS-2000M Lite Thin Mount display for a new application ................11 Mounting the remote pressure sensor ............................ 15 Wiring the system and BACnet MS/TP communications ......................

  • Page 7: Introduction

    360° Safety Halo™ illuminated edge which allows staff to easily monitor spaces down long corridors. You can mute the audible alarm with one tap to the screen to reduce audible alarm fatigue. The FMS-2000M Lite features two password-protected access levels, one for administrators and one for restricted level users, such as nurses.

  • Page 8: Location Considerations

    Location considerations Install the FMS-2000M Lite monitor directly outside the monitored space, at the nurses’ station, in the engineering office, or at any other location that you need. Place the sensors away from any moving air source like ceiling air registers, because this can cause unstable sensor behavior.

  • Page 9: Installing The Fms-2000M Lite Thin Mount Display For A Retrofit Application

    • a 1/16 in. hex wrench Note: If you are want to install the FMS-2000M Lite in a space where the walls are already installed, use the retrofit ring to attach the display to the wall. Choose the location where you want to place the FMS-2000M Lite monitor.
  • Page 10 FMS-2000M Lite Item Component FMS-2000M Lite Critical Environment Monitor Monitor bracket Wall Retrofit ring Mounting screw Set screw LIT-12013692...

  • Page 11: Installing The Fms-2000M Lite Thin Mount Display For A New Application

    1/16 in. hex wrench Note: If you want to install the FMS-2000M Lite in a new construction application, attach the rough-in box before the walls are installed. You can then attach the display once the walls are in place.
  • Page 12 FMS-2000M Lite Item Component FMS-2000M Lite Critical Environment Monitor Mounting bracket Wall Stud Rough-in box Mounting screw Set screw LIT-12013692...
  • Page 13 FMS-2000M Lite LIT-12013692...
  • Page 14 FMS-2000M Lite Number Description Surface mount display Existing wall box Mounting plate LIT-12013692...

  • Page 15: Mounting The Remote Pressure Sensor

    Mounting the remote pressure sensor The FMS-2000M Lite Critical Environment Monitor includes one remote pressure sensor to measure the differential pressure of the monitored spaces. Install the remote pressure sensor module in the wall facing the monitored space such as an isolation room. Install the flow tube mounting plate facing the adjoining reference space such as the corridor or anteroom.
  • Page 16 FMS-2000M Lite Reference space Monitored space Number Description Gasket Stainless steel flow tube mounting plate Wall section in cut away view Flow tube Stainless steel mounting plate Gasket Louvered cover plate Remote pressure sensor Mounting bracket Terminal block Thin silicone caulking...

  • Page 17: Wiring The System And Bacnet Ms/Tp Communications

    Wiring one remote pressure sensor to the monitor Note: The figure shows a 120 VAC to 24 VAC step down isolation transformer as an example. For information about correct power supply termination, see the following wiring information: Supervisory device FMS-2000M Lite Critical Environment Monitor LIT-12013692...

  • Page 18: Wiring One Remote Pressure Sensor To The Monitor

    120 VAC/240 VAC 60/50Hz input Callout Component FMS-2000M Lite monitor Remote pressure sensor DIP switch, SW1 Supplied remote pressure sensor Io terminal Note: A 4mA to 20mA signal is present at the sensor’s Io terminal which represents the monitored room pressure. You can use it to remotely monitor room pressure when you connect the terminal to a third party controller on the BMS network.
  • Page 19 FMS-2000M Lite Switch Description Sensor 1 Sensor address Sensor mode: Set the switch to On for normal or Off for inverted. After you change the sensor mode with switch 5, cycle On or off power to the sensor for the mode change to take effect.

  • Page 20: Configuring The Display Module Settings

    FMS-2000M Lite Configuring the display module settings FMS-2000M Lite DIP switch position Demo mode Run mode Position 1 Position 2 Position 3 Position 4 BMS integration Objects Analog inputs Read/Write Availability of analog input objects FMS2ML–BxR AI-1 Analog input 1, differential pressure...

  • Page 21: Ordering Information

    FMS-2000M Lite Ordering information Feature Code letter or number and description Product code number example: FMS2ML–BTR Unit FMS = Flow Monitor Station (FMS) Series 2 = 2000 M = Monitor L = Lite Network B = BACnet Mounting style T = Thin mount for shallow wall cavities...

  • Page 22: Technical Specifications

    FMS-2000M Lite Technical specifications Specification Description Intended use Indoor use Overvoltage category Altitude Up to 2000 m (6,561.67 ft) Pressure range ± 0.2500 in. W.C. (± 62.27 Pa) Alarm range ± 0.2500 in. W.C. (± 62.27 Pa) Display range ± 0.2500 in. W.C. (± 62.27 Pa) Accuracy ±...

  • Page 23: Repair Information

    FMS-2000M Lite Repair information If you purchased a service agreement, contact your Triatek® representative for a replacement unit. If you do not have a service agreement, contact service@triatek.com. Patents Patents: https://jcipat.com Software terms Use of the software that is in (or constitutes) this product, or access to the cloud, or hosted services applicable to this product, if any, is subject to applicable end-user license, open-source software information and other terms set forth at www.johnsoncontrols.com/techterms.
