  • Page 1 Service Manual www.roxorgames.com www.inthegroove.com Read the manual before operating this machine. Keep this manual for your reference. ISSUE DATE : March 15, 2006...
  • Page 2 PRECAUTIONS FOR USE The following information describes safety precautions for installing your ITG dedicated cabinet. They must be strictly followed to protect those who install, use, or maintain this product as well as to prevent other peopleís injuries and property damages. Please read the following information *The following suggestions show the degree of danger and damage caused.
  • Page 3 PRECAUTIONS FOR USE Setting Up W A R N I N G C A U T I O N Please consult a technician before setting up, Be sure to only use wiring within the specified moving or transporting this product. voltage range.
  • Page 4 PRECAUTIONS FOR USE OPERATION W A R N I N G C A U T I O N If the machine exhibits any abnormal behavior, Do not use this product anywhere other than such as emitting smoke, fire, unusual noises, industrial areas.
  • Page 5 P R E C A U T I O N S This may result in fire, malfunction, or injury. In case of machine malfunction, contact your distributor for repair. ROXOR GAMES, INC. will not assume any responsibility for damage to the When assembling, maintaining, moving or...
  • Page 6 SAFETY INSTRUCTIONS POWER SUPPLY Use only a grounded outlet. Do not extend the power cord for use. Check the power requirements before attempting to install the product. Use only a power cord that meets the power requirements. Use the rating fuse. Do not touch the power plug with wet hands.
  • Page 7 TEST & CUSTOMIZE OPERATOR MENU Operator Menu Test Hardware and Set Options before gameplay begins. Entering the Operator Menu Press the Test button ( ) located in the service box at any time. The Operator Menu will appear. Insert Credit Options Bookkeeping Transfer Scores: Machine...
  • Page 8 TEST & CUSTOMIZE OPERATOR MENU Testing & Customizing Operator Menu Navigating the Operator Menu buttons to change the current row, then Press the Left and Right press Start ( ) to choose the selected option. Help As you change options, an explanation describing the current option appears near the bottom of the screen.
  • Page 9 TEST & CUSTOMIZE OPERATOR MENU View coin drop counts and other coin statistics. Entering the Bookkeeping Screen * Select Bookkeeping from the Service Menu. * Cycle through different Bookkeeping reports. All-time Total: 3626 Coin Data of Last 7 Days Today Yesterday Day2Ago Day3Ago...
  • Page 10 TEST & CUSTOMIZE OPERATOR MENU * Transfer Scores: Machine Memory Card Copy high scores from the internal memory to a USB memory card. Insert a USB memory card before choosing this option. *Transfer Scores: Memory Card Machine Copy high scores from a USB memory card to the internal memory. Insert a USB memory card containing previously saved machine score data before choosing this option.
  • Page 11 TEST & CUSTOMIZE OPERATOR MENU Test Input Check that pad sensors and cabinet buttons are functioning properly. * Entering the Test Input Screen Select Test Input from the service menu. * Testing Pad Sensors A message will appear on the screen indicating which inputs are detected as being held.
  • Page 12 TEST & CUSTOMIZE OPERATOR MENU * Stuck Sensors Stuck sensors severely impair gameplay. A stuck sensor will not recognize any change in applied pressure during gameplay. If the Input Test screen shows a sensor as being held when no pressure is applied to the panel, then the sensor ir stuck and maintenance is required.
  • Page 13 TEST & CUSTOMIZE OPERATOR MENU Test Lights Determines functionality of pad and cabinet lights. * Entering the Test Lights Screen Select Test Lights from the Service Menu. * Explanation This scren will cycle through the cabinet and pad lights one at a time. A message shows which lights are currently lit according to the software.
  • Page 14 TEST & CUSTOMIZE OPERATOR MENU Set Machine Time Set clock. The machine í s clock is used when saving high scores and all other bookkeeping data. SET MACHINE TIME YEAR : MONTH : DAY : HOUR : MINUTE : SECOND : Reset Menu Reset options, bookkeeping data, statistics, or edits.

  • Page 15: Table Of Contents

    CONTENTS 1. PART NAME 2. SPECIFICATION 3. HOW TO INSTALL IN THE GROOVE 3-1. MOUNTING THE MARQUEE TO THE MONITOR 3-2. CONNECTORS 3-3.CONNECTING THE FLOOR PADS TO EACH OTHER 3-4. CONNECTING THE FLOOR PADS TO THE MAIN ASSEMBLY 4. FLOOR PAD ASSEMBLY 4-1.

  • Page 16: Part Name

    PART NAMES MARQUEE BRAUN TUBE BUTTON PLATE FRAME PIPE FLEXIBLE TUBE FLOOR PADS...

  • Page 17: Specification

    SPECIFICATIONS POWER 400 W CONSUMPTION MAXIMUM POWER 600 W CONSUMPTION SCREEN SIZE 34" BODY 220 kg WEIGHT (Kg) FLOOR 182 kg POWER AC 110V / 60Hz REGUIREMENTS 1100 1780...

  • Page 18: How To Install In The Groove

    HOW TO INSTALL IN THE GROOVE Fasten 6 screws to mount the marquee baracket on the monitor. PART NAME SPEC. QUANTITY CODE NO. CABINET ASSíY APUG0WOO005 MARQUEE FIXING BRACKET SEMS...
  • Page 19 HOW TO INSTALL IN THE GROOVE Connect All Conectors PART NAME SPEC. QUANTITY CODE NO. BILLBORAD SEMS...
  • Page 20 FLOORPAD ASSEMBLY ATTACH FLOOR PADS PART NAME SPEC. QUANTITY CODE NO. CROSS STEP ASS'Y APUS0WOO003 FRAME PIPE A, B MPUS0MEP035 PIPE SHAFT FRAME JOINT BRACKET MPUS0MEP047 HEXAGON SOCKET HEAD CAP SCREW HEXAGON SOCKET HEAD CAP SCREW...
  • Page 21 CABINET ASSEMBLY CONNECTING FLOOR PADS TO THE MAIN CABINET PART NAME SPEC. QUANTITY CODE NO. CABINET ASSEMBLY APUG0WOO005 CONNECTOR BOX - CABINET MPUD0MEP008 CONNECTOR BOX - STEP MPUD0MEP009 FLEXIBLE TUBE ASS'EMBLY APUS0WOO012 CROSS STEP ASSEMBLY APUS0WOO003 HEXAGON SOCKET HEAD CAP SCREW...
  • Page 22 ASSEMBLING THE FLOOR PANEL THIS ASSEMBLY DRAWING IS BASED ON A SPECIFIC MODEL FLOOR PANEL DIAGRAM PART NAME SPEC. QUANTITY CODE NO. MPUS0000001 SENSOR BRACKET TAPE MPUS0MEP041 SENSOR COVER BRACKET MPUS0PLA018 BRACKET SUPPORT MPUS0MEP072 SWITCH FRAME MPUS0PLA017 STEP ACRYL STOPPER MPUS0PLA016 SENSOR RUBBER MPUD0PLA005...
  • Page 23 ASSEMBLING THE FLOOR PANEL ASSEMBLING THE FLOOR PANEL PART NAME SPEC. QUANTITY CODE NO. SWITCH FRAME ASSEMBLY CCFL COVER ASSEMBLY FOOT PCB ASSEMBLY APUS0PCB017 STEP FRAME MPUS0MEP045 HANDLE JOINT BRACKET MZZZ0MEP004 PIPE SHAFT SEMS SEMS SEMS...
  • Page 24 ASSEMBLING THE FLOOR PANEL ASSEMBLING THE FLOOR PANEL PART NAME SPEC. QUANTITY CODE NO. COVER PANEL MPUS0MEP013 FRAME SUPPORT PANEL MPUS0MEP022 STEP FRAME MPUS0MEP045 SEMS M6 16L...
  • Page 25 ASSEMBLING THE FLOOR PANEL ASSEMBLING THE FLOOR PANEL PART NAME SPEC. QUANTITY CODE NO. STEP ACRYL COVER MPUS0MEP044 STEP ACRYL MPUS0MEP044 FRAME FRONT COVER MPUS0MEP018 FRAME SIDE COVER MPUS0MEP021 FRAME REAR COVER MPUS0MEP019 HEXAGON SOCKET HEAD CAP SCREW M6 L16 SEMS M4 L16...
  • Page 26 ASSEMBLING THE MARQUEE DIAGRAM OF THE MARQUEE PART NAME SPEC. QUANTITY CODE NO. LIGHTING SUPPORT BRACKET MARQUEE ACRYL SUPPORT BRACKET MARQUEE ACRYL MPUS0ACR021 MARQUEE ACRYL LOWER SUPPORT BRACKET LAMP 3 WAVE LAMP MELEOLAM005 AC RECEPTACLE 3 WAVE SOCKET MELEOARE002 SEMS TAPPING SCREW...
  • Page 27 ASSEMBLING THE MARQUEE PICTURE A PART NAME SPEC. QUANTITY CODE NO. LIGHTING SUPPORT BRACKET MARQUEE SPEAKER COVER BOX SPEAKER HIGH-2.5 / MID 4.5 MARQUEE SPEAKER COVER HALOGEN LAMP BACK COVER HALOGEN LAMP MELE0LAM009 LAMP BOX MARQUEE LAMP ACRYL MARQUEE LAMP CAPSPEAK LAMP BOX SUPPORT SEMS SEMS...

  • Page 28: Speaker Assembly

    SPEAKER ASSEMBLY PART NAME SPEC. QUANTITY CODE NO. CABINET ASS'Y APUG0WOO005 SPEAKER ACRYL COVER BRACKET SPEAKER RING MPUD0PLA002 SPEAKER NET MPUS0MEP053 SPEAKER ACRYL MPUS1ACR009 NEON LAMP MELE0LAM010 NEON LAMP SUPPORT MPUS0WOO010 TAPPING SCREW SEMS...

  • Page 29: Button Plate Assembly

    BUTTON PLATE ASSEMBLY PICTURE A PART NAME SPEC. QUANTITY CODE NO. BUTTON PLATE MPUG0MEP002 USB HUB UPPER COVER BRACKET MPUG0MEP005 USB HUB LOWER COVER BRACKET MPUG0MEP006 HUB COVER ACRYL MPUG0ACR007 USB HUB 4 PORT BUTTON SWITCH BLUE MZZZ0BUT037 BUTTON SWITCH MZZZ0BUT036 BUTTON SWITCH MZZZ0BUT041...

  • Page 30: Coin Door & Control Panel Assembly

    COIN DOOR & CONTROL PANEL ASSEMBLY EXIT MENU DOWN DEGAUSSING SELECT SERVICE TEST WOOF COIN COUNTER MASTER PICTURE A PART NAME SPEC. QUANTITY CODE NO. AC POWER SWITCH BRACKET SSR PCB ASSEMBLY PUMP-PIU05 APUS1PCB004 VOLUME VR103(10K) PRES0VRZ003 COUNTER AMMC-712 (7D12V) MZZZ0COU002 PUSH BUTTON SWITCH 412R...
  • Page 31 MAIN BOX & AMPLIFIER ASSEMBLY POWER AC INPUT NEON PC INPUT LAMP INPUT POWER POWER WOOF INPUT INPUT INPUT PICTURE A PICTURE B PART NAME SPEC. QUANTITY CODE NO. FAN BRACKET AMP BOX ASSEMBLY APUS0WOO010 MAIN BOX ASSEMBLY MK6 895 TYPE APUS0000009 CASE BACK DOOR NOISE FILTER...

  • Page 32: In The Groove Cabinet

    IN THE GROOVE 2 CABINET...
  • Page 33 Wiring Diagram 1...
  • Page 34 Wiring Diagram 2...
  • Page 35 Wiring Diagram 3...
