JPI CUBE X Series Manual

Diagnostic x-ray system (portable x-ray)
Hide thumbs
Table of Contents

Advertisement

Quick Links

DOC. NO.: JDP-013-CUBEX
Issued Date: 2017.07.21
Revision: 2017.07.21(Rev.0)
CUBE X Series
Diagnostic X-ray System
(Portable X-ray)
JPI HEALTHCARE Co., Ltd
608-ho,28, Digital-ro 33gil, Guro-gu, Seoul, 08377 South Korea
Woolim e-Biz center
TEL: 82-2-2108-2580, FAX: 82-2-2108-1180
jpi.co.kr
Homepage:
www.
E-mail:
leejw@jpi.co.kr
1/54 Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUBE X Series and is the answer not in the manual?

Questions and answers

Summary of Contents for JPI CUBE X Series

  • Page 1 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) CUBE X Series Diagnostic X-ray System (Portable X-ray) JPI HEALTHCARE Co., Ltd 608-ho,28, Digital-ro 33gil, Guro-gu, Seoul, 08377 South Korea Woolim e-Biz center TEL: 82-2-2108-2580, FAX: 82-2-2108-1180 jpi.co.kr Homepage: www. E-mail: leejw@jpi.co.kr...

  • Page 2: Revision History

    DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) Revision History REV No. Date Reason for Change 2017.07.21 Preliminary edition 2017.10.10 Adding Images for Use 2/54 Page...

  • Page 3: Manufacturer Information

    All rights reserved. Reproduction or transmission in whole or in part, in any form or by a means, electronic, mechanical or otherwise, is prohibited without the prior written consent of JPI HEALTHCARE. The manual may be revised without prior notice for the improvement of the device.
  • Page 4 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) Symbols The following advisory symbols will be used throughout the manual. Their application and meaning are described below. Advice of conditions or situations that, if not heeded or avoided, will cause serious personal injury or death. Advice of conditions or situations that, if not heeded or avoided, could cause serious personal injury or catastrophic damage of equipment or data.
  • Page 5 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) This symbol indicates that the waste of electrical and electronic equipment must not be disposed as unsorted municipal waste and must be collected separately. This symbol indicates that user should read instructions for use. The following symbols will be used in the packing label.

  • Page 6: Accident Reporting

    In order to improve the quality of the system and prevent an additional accident, all users of this equipment, operators and service technicians, are required to provide JPI with the following information regarding all reportable events as soon as possible: 1) Identification of the model and serial number.
  • Page 7 It should be operated and maintained in strict compliance with the following safety precautions and operating instruments contained herein:. 1) The product should be installed, maintained and serviced according to JPI HEALTHCARE maintenance procedures and by JPI HEALTHCARE personal or other qualified maintenance personnel approved in writing by JPI HEALTHCARE.

  • Page 8: General Hazards

    DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 1.2 General Hazards 1.2.1 Radiation hazards This system can be used with interfaced to x-ray generating equipment. Be certain to follow the safety instructions and specifications for wearing proper lead shielding when in the presence of x-ray generating equipment 1.2.2 Electric shock hazard The internal circuit of the system uses high voltage that might cause electric shock or serious injury.

  • Page 9: Safety Precautions

    Do not try to use the system if system diagnostic is fail. The owner must run calibration software to diagnosis system every year. If the error has detected, report detailed error to JPI HEALTHCARE field service representative. 1.3.3 Calibration Verify the system is calibrated to ensure the optimal performances of the system.

  • Page 10: User Limitations

    The operator need to make it sure that hard disk has enough space for taking images. 1.3.5 User limitations For your safe installation and using, the Service Mode should be operated by JPI HEALTHCARE qualified person with password. 1.3.6 Cleaning the system Use only isopropyl alcohol to clean surfaces of the system.

  • Page 11: Electrical Fire

    1.3.10 Maintenance precaution Only person who qualified by JPI HEALTHCARE can do maintenance for system. 1.3.11 Disposal This product contains harmful materials such as lead. Improper disposal of this product may result in environmental contamination.

  • Page 12: Replace Fuse

    Only qualified service person, who have took training from JPI HEALTHCARE should perform this installation and trouble shooting Only person who qualified by JPI HEALTHCARE can do installation or trouble shooting and should do calibration after installing devices or changing generator, X-ray tube or detector.

  • Page 13: Emc Information

    1.4.1 Guidance and manufacturer’s declaration - electromagnetic emissions The CUBE X series is intended for use in the electromagnetic environment specified below. The customer or the user of the CUBE X series should assure that it is used in such an environment. Immunity test...

  • Page 14: Guidance And Manufacturer's Declaration - Electromagnetic Immunity

    1.4.2 Guidance and manufacturer’s declaration - electromagnetic immunity The CUBE X series is intended for use in the electromagnetic environment specified below. The customer or the user of the CUBE X series should assure that it is used in such an environment.
  • Page 15 1.4.3 Guidance and manufacturer’s declaration - electromagnetic immunity The DRE140/150 is intended for use in the electromagnetic environment specified below. The customer or the user of the CUBE X series should assure that it is used in such an environment.
  • Page 16 Over the frequency range 150kHz to 80MHz, field strengths should be less than 3 V/m. 1.4.4 Recommended separation distances between portable and mobile RF communications equipment and the CUBE X series The is intended for use in an electromagnetic environment in which radiated...

  • Page 17: Expected Service Life

    Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) RF disturbances are controlled. The customer or the user of the CUBE X series can help Prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the CUBE X series as recommended below, according to the maximum output power of the communications equipment.

  • Page 18: Intended Use

    DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 1.6 Intended Use The system is intended to be used for human in hospital environment under supervision of recommended medical practitioner. The purpose of the system is to acquire X-ray digital images of a patient and show the images to a doctor for diagnosis. 1.6.1 Intended patient profile a) Weight : under 150kg b) Height : under 2m...
  • Page 19 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 1.6.4 Intended conditions of use a) Environment : - General : - Hospital use only - Indoor use only - Physical : - System Storage/Transport Environmental Condition Temperature range: -15°C ~ 55°C Relative humidity range: 20% ~ 90% (non-condensing) Atmospheric Pressure range: 50kPa ~ 106kPa - System Operation Environmental Condition...
  • Page 20 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 1.6.5 Operating principle A radiograph is an X-ray image obtained by placing a part of the patient in front of an X-ray detector and then illuminating it with a short X-ray pulse. To take an X-ray image, the operator sets the patient in front of the detector and sets the parameter values of the high voltage generator to control the intensity of X-ray for each body part.
  • Page 21 Revision: 2017.07.21(Rev.0) 2. Product information Introduction The CUBE X series Innovation diagnostic X-ray system features excellent x-ray Image, quality, accuracy, reproducibility and long-term stability. Fast kV rising time minimize unnecessary patient dose and supply superior Image quality, fast Image response.
  • Page 22 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.2 Rating Labels 2.2.1 CUBEX-16 2.2.2 CUBEX-24 22/54 Page...
  • Page 23 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.2.3 CUBEX-50 23/54 Page...
  • Page 24 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.3 Specification 2.3.1 CUBE-16 Max Output Power 1.6 kW Voltage 200V-240V Input Power Phase & Frequency Single / 50/60 Hz Tube voltage current 40KV ~ 50KV 30mA 0.4 ~ 20 40KV ~ 50KV 25mA 25~32 51KV ~ 60KV...
  • Page 25 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.3.2 CUBE-24 Max Output Power 2.4 KW Input Power Voltage 200V-240V Phase & Frequency Single, 50/60 Hz Tube voltage current 40KV ~ 60KV 40mA 0.4 ~ 64 40KV ~ 60KV 35mA 80 ~ 100 61KV ~ 70KV 30mA 0.4 ~ 100...
  • Page 26 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.3.3 CUBE-50 Max Output Power 5.0 KW Voltage 200V-240V Input Power Phase & Frequency Single / 50/60 Hz Tube voltage current 50KV 100mA 0.4~10mAs 50KV 80mA 13~32mAs 50KV 70mA 40~100mAs 51KV ~ 60KV 80mA 0.4~10mAs 51KV ~ 60KV...
  • Page 27 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.3.4 Hand switch (common) Two step X-ray exposure hand switch Type Two stepping(ready and exposure) Working Voltage(AC/DC) 125V/30V Working Current(AC/DC) 1A/2A Wires and coil cord 3cores, 2.2m White Green Cores Ready Common Exposure Shell Material White, Engineering plastics...
  • Page 28 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.4 Table of mAs & sec 2.4.1 CUBE-14 2.4.2 CUBE-24 28/54 Page...
  • Page 29 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.4.3 CUBE-50 29/54 Page...
  • Page 30 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.5 Table of dosimetry data 2.5.1 CUBE-16 [unit : μGy*㎡] 11.1 21.8 34.1 47.2 60.7 75.4 70.7 218.2 302.8 392.4 2.5.2 CUBE-24 [unit : μGy*㎡] 11.1 21.8 34.1 47.2 60.7 75.4 90.8 70.7 218.2 302.8...
  • Page 31 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.6 Mechanical specification 2.6.1 Side view [unit : mm] 2.6.2 Front view [unit : mm] 31/54 Page...
  • Page 32 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 2.6.3 Hand switch [unit : mm] 32/54 Page...

  • Page 33: Working Environment

    DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 3. Working environment Avoid the following places for the normal operation and safe storage: where the equipment is exposed to water vapor. where the equipment is exposed to direct sunlight. where the equipment is exposed to dust. where the equipment is exposed to high humidity.
  • Page 34 Head Office Address : 608-ho,28, Digital-ro 33gil, Guro-gu, Seoul, 08377, Republic of Korea Telephone : +82-2-2108-2580 FAX : +82-2-2108-1180 Website : http://www.JPI.co.kr Factory Address : 265, Osongsaengmyeong 1-ro, Osong-eup, heungdeok-gu, Cheongju-si, Chungcheongbuk-do, 28161, Republic of Korea Telephone : +82-2-237-8606 FAX : +82-2-8630-5538-...

  • Page 35: System Configuration

    Revision: 2017.07.21(Rev.0) 5. System configuration The CUBE X series is a radiological device for professional radiologist uses. It should be applied for the radiographic diagnosis and operated by qualified practitioners. Users have to comply with safety and health regulations concerning the ionizing radiation protection and the electrical and mechanical safety of the veterinary medical devices.
  • Page 36 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) The operation of the machine should not be started unless all verifications and connections are fully checked. For the first time installation of the (machine) or operation after long period of non-use, it needs to be preheated to secure long service life of the tube.
  • Page 37 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 5.2 Connection of power code and hand switch Description Function Power Connector(inlet) Connect the power cable Power Switch Power on/off switch Hand Switch Connector Connect the hand switch cable Please check whether the voltage and frequency of the input power are in accordance with figures...
  • Page 38 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) To avoid the risk of electric shock, this equipment must only be connected to a supply main with protective earth. 38/54 Page...
  • Page 39 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 6. Operation mode Description Function KV indicator Display KV value mAs indicator Display mAs value mAs & sec indicator Display mAs & sec indicator KV up/down control switch Select KV value by up or down buttons mAs up/down control switch Select mAs value by up or down buttons Ready indicator...
  • Page 40 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 6.1. Normal Mode a. Connect power plug into the device. b. Turn on the power switch located on the back of the equipment. c. Select the KV values using the KV up/down switch. d.
  • Page 41 Push the button 3 for two seconds, there will be reset to zero. 6.4 Cooling Time Display Mode The CUBE X series have the cooling time function for protecting the device. The cooling time function is to stop the device when operator uses the device over standard. EPX-series will start automatically the cooling time procedure when operator shoots x-ray twice in a row.
  • Page 42 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) a. Set to the minimum kV and mAs value. b. Turn off the power switch. c. Unplug the power cable from the device. 6.6 Touch Main Screen of Operation Mode (Option) 6.6.1 Normal Mode of Touch Main Screen After Start-up Screen is successfully launched, the following Touch Main Screen will be displayed.
  • Page 43 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) Before any X-ray exposure, press this button for 3 seconds to complete filament Pre-heating. When the preheating is completed, Ready button this item (13) Ready indicator will light up. This is the same function as half-pressing the exposure hand-switch.
  • Page 44 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 6.7 Hand switch Name Description stage: The equipment gets ready when the button is half pressed with a thumb. Hand Switch stage: The equipment exposes X-ray when the button is fully pressed (Dead-man type) with a thumb.

  • Page 45: Maintenance Procedure

    DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 7. Maintenance procedure 7.1 General caution It is recommended to follow the maintenance procedure described below, for the reliable operation. The routine inspection should be committed by a trained expert There may cause serious injury by conducting unauthorized service or changing the instrument and manufacturer shall not be responsible for the resulting compensation.
  • Page 46 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 7.4 Trouble shooting These are the information about indicating a system malfunction to do not appear in the message window. If the device occurs a problem to except on the below troubleshooting table, consult manufacture or the agent.
  • Page 47 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 7.5 The equipment operation checklist for operator Verdict Check Item kV and mAs values display on the console when power on. kV and mAs up/down button operation. Collimator lamp on/off operation Laser pointer on/off operation Display reversal button operation Ready indicator light on when the hand switch push one time for preparation Exposure indicator light on during x-ray exposure...

  • Page 48: Appendix A : Technical Chart

    DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 8. Appendix A : Technical chart 8.1 Film screen : Lanex Reqular screen(400 speed) 40" SID 48/54 Page...
  • Page 49 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 49/54 Page...
  • Page 50 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 8.2 CR system : 40" SID 50/54 Page...
  • Page 51 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 51/54 Page...
  • Page 52 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 8.3 DR system : 40" SID 52/54 Page...
  • Page 53 DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 53/54 Page...

  • Page 54: Appendix B : Action To Correct The Error Of Cube X Series

    DOC. NO.: JDP-013-CUBEX Issued Date: 2017.07.21 Revision: 2017.07.21(Rev.0) 9. Appendix B : Action to correct the error of CUBE X series 54/54 Page...
