Maxkin SP-R01 User Manual

SP-R01 (PLUS)
Wireless RF Repeater
User Manual
Description
SP-R01(PLUS) is a wireless repeater that extends the range of RF
devices. It is in elegant design and easy to install. It eliminates
the needs to upgrade to a larger alarm control panel that supports
two receivers. Its for installation that requires extended RF range
with good stability, high receiving sensitivity, longer transmitting
distance and anti-interference. The replaceable plugs is more
flexible to meet different customers' needs.
Features
Extends the range of wireless devices
Receives alarm, status and control messages from accessories,
and repeats these messages to the control panel
LED circle in 3 different colors indicate the alarm current status
for arming/disarming...
One single touch to turn on/off the LED indicator
Replaceable plug, more flexible to change
Back up battery for 12 hours when power lost
General View/LED Indication
1
rinted in China
P
2016 V 1.0
3
2
4
1.LED Indicator
Red LED Flashes Once：Enrolling
Green LED On：System disarmed
Green LED Flashes Once: Transmitting wireless signal
Blue LED On: System armed in away mode.
Blue LED Flashes: System armed in stay mode.
2.Enroll/Testing Button
3.Plug Handle
4. Interchangeable Plugs
Specification
Voltage: DC100-240V 50/60HZ
Max Current: 20mA/220V
Power Rating: ≤5W(220V)
Back-up Battery: 3.7V/600mA
Receiving Distance: 100M
Transmitting Distance: 500M
Housing Material: ABS plastic
Plus Type: EU/US/UK/AU
Operation Condition: -10°C~55°C
Size:Φ80 x 41.7mm
