BM 500/15 / BM 600/15
S/N 101 882 00 ....> S/N 101 882 01 .... / S/N 101 882 10 ....> S/N 101 882 11 ....
Cold Milling Machine
Catalogue No.
008 919 77
Levelling system
Original operating instructions
01/2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the Bomag BM 500/15 and is the answer not in the manual?

Questions and answers

Related Manuals for Fayat Bomag BM 500/15

Summary of Contents for Fayat Bomag BM 500/15

  • Page 1 Levelling system Original operating instructions BM 500/15 / BM 600/15 S/N 101 882 00 ..> S/N 101 882 01 ../ S/N 101 882 10 ..> S/N 101 882 11 ..Cold Milling Machine Catalogue No. 01/2012 008 919 77...
  • Page 3 Nivellieranzeige Anzeige Höhen- verstellung Neigungssensor K162 Umschaltrelais MOBA Controller Arbeitsventilblock Heckrahmen Sensor rechts Sensor links Seilzugsensor links Seilzugsensor rechts...
  • Page 6 $EVWUHLIHU KLQWHQ PLW $QGUFNIXQNWLRQ           Leveling 1LYHOOLHUXQJ 1LYHOOLHUXQJ NXU]HV %DQG ODQJHV %DQG OLQNV UHFKWV KHEHQ  VHQNHQ KHEHQ  VHQNHQ %DQG VFKZHQNHQ                         ...
  • Page 7 5 Description of indicators and operating elements 5 Description of indicators and operating elements 5.1 The controller’s LED elements Function blinking permanently on Voltage supply Leveling controller Program error Valve controller Program error Valve controller Error Communication error Left Lower Permanent valve control Left Raise Permanent valve control...
  • Page 8 5 Description of indicators and operating elements 5.2 The indicators and operating functions of the control panel The control panel of the MLS 508 contains all the keys necessary for the expanded handling of the system, several indicator lights and a graphic display which indicates the current status of the system at any time.
  • Page 9 5 Description of indicators and operating elements The control loops “left” and “right”: Presently, the MLS 508 offers three separate control loops for valve actuation. Depending on the individual application, the control loops can be operated with different sensors and be enabled or disabled independently. The control loops “left”...

  • Page 10: First Steps

    6 First steps 6 First steps This chapter will provide you with information on the start-up of the system, on the setting of contrast and on sensor selection. In addition, you will find a description of the symbols and displays used in the working window as well as instructions on how to navigate within the configuration menu and set parameters.

  • Page 11: Setting The Contrast

    6 First steps After 3 seconds or after pressing any key within this period, depending on the settings the MLS 508 switches to the working window. Working window with selected grade and slope sensor: Working window with two selected grade sensors and connected slope sensor: 6.3 Setting the contrast The contrast of the graphic display can be adjusted at the control panel to achieve easy viewing, also in poor lighting conditions.
  • Page 12 6 First steps 6.4 Symbols and displays in the working window Designation of the sensor selected from the sensor selection menu for the corresponding control loop (also see “6.6 Sensor selection”) The actual values; i.e. the current values measured by the two active sensors of the left and right control loop are displayed with signs as well as their physical measuring unit.
  • Page 13 6 First steps 6.5 Navigation within the menus Navigation among the menu levels is done exclusively with the function keys F1 to F4. For selecting items within menus or submenus and for setting parameters, the UP/DOWN keys of the left and the right control loop are needed in addition. As mentioned above, the assignment of the function keys depends on the selected menu.
  • Page 14 6 First steps 6.5.1 Example of navigation Setting the size of the wire rope sensor’s control window: 1) Press the function key F4 in the working window to access the Configuration menu. 2) Select the line User settings by using the UP/DOWN keys on the left (the selected line flashes).
  • Page 15 6 First steps 7) Press the function key F3 to call up the parameter Individual sensor settings. 8) First, select the line Wire rope sensor by using the left UP/DOWN keys (the selected line is highlighted) and then use the right UP/DOWN keys to set the size of the control window for this type of sensor.
  • Page 16 6 First steps In this manual, instructions like the ones overleaf are summarized in a condensed version: Setting the size of the wire rope sensor’s control window: 1) From the working window switch to the menu item Individual sensor settings via the menu items Configuration menu, User settings and Change sensor control window.

  • Page 17: Sensor Selection

    6 First steps 6.6 Sensor selection If several sensors are connected to the MLS 508 CAN-bus network at the same time, the desired sensor can be selected by using the sensor selection menu. Please note that the sensor has to be connected to and mounted on the side of the machine corresponding to the respective control loop.
  • Page 18 6 First steps 3) Press the function key F3 (Enter) to save the selection or press the function key F4 (Exit) to exit without making any changes. After either key is pressed, the software returns to the working window. Saving the selection and returning to the working window Proceed in analogy with the above explanations when changing the sensor for the right machine side.
  • Page 19 7 Working with the MLS 508 7 Working with the MLS 508 7.1 Safety instructions WARNING Risks caused by inappropriate operation! Inappropriate operation can lead to severe personal injuries or material damages. Therefore: Carry out all operation steps in compliance with this instruction manual.
  • Page 20 7 Working with the MLS 508 The valve lights indicate the status of the actuated valve output. Meaning of the valve lights’ indications: Both LOWER arrows on = High control deviation – LOWER output active Inner LOWER arrow on = Low control deviation –...
  • Page 21 7 Working with the MLS 508 7.3 Working with the Cross Slope sensor 7.3.1 Mounting and setting up The Cross Slope sensor measures the cross slope of the milling drum and therefore, depending on the machine, is mounted on a part of the machine which carries out all slope changes in the same way as the milling drum.
  • Page 22 7 Working with the MLS 508 7.3.2 Operating with the Cross Slope sensor The Cross Slope sensor has been selected for one of the two sides with the help of the sensor change key (also see “6.6 Sensor selection”). The other side is controlled manually or by means of a grade sensor.
  • Page 23 7 Working with the MLS 508 3) Now switch the controller to automatic mode (automatic = automatic light on) by pressing the corresponding A/M key. The “RAISE” or “LOWER” valve lights first indicate that an existing deviation is being controlled out. The controller of the MLS 508 then automatically holds the milling drum at the set slope, even if it is moved in height (manually or by the other side’s...
  • Page 24 7 Working with the MLS 508 7.3.3 Relative adjustment of the Cross Slope sensor Via the relative adjustment the Cross Slope sensor’s actual value can be re- adjusted. It is of no importance whether this is done in manual or automatic mode. 1) Press and hold the function key F2 in the standard working menu.
  • Page 25 7 Working with the MLS 508 7.4 Zero adjustment Before describing operations with the various grade sensors, the term “zero adjustment” has to be defined. For every new application or after mounting or remounting a grade sensor, the current value measured by the sensor has to be adjusted to zero. In doing so, the current mounting level of the grade sensor above the reference is saved in the system and a clear reference value is provided for all future target values at the same time.
  • Page 26 7 Working with the MLS 508 The current value measured by the grade sensor (actual value) is taken over as target value and both values are assigned the value 0.0. There is no deviation. All measurements after the zero adjustment refer to this height. Alternatively the zero adjustment can be carried simultaneously...
  • Page 27 7 Working with the MLS 508 7.6.2 Controlling with the Wire Rope sensor 1) If the automatic light of the side selected wire rope operation lights up, switch the respective control loop to manual mode by pressing corresponding (manual = automatic light off). 2) The Wire Rope sensor has been mounted in consideration of the moving direction and the ideal working range.
  • Page 28 7 Working with the MLS 508 5) Carry out a zero adjustment: Press the UP key and the DOWN key of the relevant control loop simultaneously until the display first reads “Set” and, after another two seconds, “0.0”. Now release both keys and the system will take over the actual value measured by the sensor as target value and will assign both measurements the value 0.0.
  • Page 29 7 Working with the MLS 508 After the zero adjustment two further adjustment options are available, which can be additionally used according to the respective application. • Press the UP key and the DOWN key of the relevant control loop simultaneously until the display reads “Set”.
  • Page 30 7 Working with the MLS 508 6) Now switch the controller to automatic mode by pressing the corresponding A/M key (automatic = automatic light on). Since there is no deviation up to this moment (actual value = target value), the hydraulic cylinders are not activated.

  • Page 31: The Configuration Menu

    8 The configuration menu 8 The configuration menu The configuration menu of the MLS 508 summarizes important parameters and settings for the control system in general and for operating the individual sensor types in particular. In addition, you will find information on the different calibration procedures for all sensors used in the system and the machine hydraulics.
  • Page 32 8 The configuration menu 8.1 Sensitivity settings The most varied influences (e.g. the machine size and motorization, the size of the hydraulics, the subsoil condition or the sensing reference or, simply, just the selection of a different type of sensor) may require adjusting the sensitivity settings of the MLS 508 control system in manual and automatic mode.
  • Page 33 8 The configuration menu Setting the sensor sensitivity: 1) From the working window switch to the menu item Configuration menu and then to the parameter Sensitivity. 2) Call up the parameter Sensitivity and set the desired values for the active sensors. 3) Save the set value(s) and return to the working window.
  • Page 34 8 The configuration menu 8.2.3 Changing the dead band In this menu item the operator can adjust the dead band individually for each sensor type. Definition: The dead band which is arranged symmetrically around the working point is the area in which no valve actuation takes place. It serves to ensure a stable behaviour of the milling drum in the working point.
  • Page 35 8 The configuration menu Any change in the dead band’s size is automatically saved, along with the sensor type the adjustment was made for (e.g. Wire Rope sensor). If another sensor type is chosen during operation, the dead band saved for that sensor will be loaded automatically.
  • Page 36 10 Leads on trouble-shooting Warning notices: Cause: The value measured by the prop. Laser Receiver LS 3000 has reached the limit of its permissible measuring range. Control outputs: The outputs are still activated in automatic mode until the measurement is out of range see next error message.
  • Page 37 10 Leads on trouble-shooting Cause: Because of reflection in its vicinity, the prop. Laser Receiver LS 3000 receives several signals of the laser transmitter. Control outputs: The control outputs are disabled in automatic mode. Correction: Shield off the laser transmitter from all but the circular sectional view really needed;...
  • Page 38 10 Leads on trouble-shooting Specific errors: Connection error: The control panel is incorrectly connected. Possible cause: The connecting cable between the controller and the control panel is damaged or there is an open circuit. The display cable has been connected to the wrong plug.
  • Page 39 Adjustments The configuration menu The configuration menu of the MLS 508 summarizes important parameters and settings for the control system in general and for operating the individual sensor types in particular. In addition, you will find information on the different calibration procedures for all sensors used in the system and the machine hydraulics.
  • Page 40 Automatic min-pulse calibration of the two control loops left and right: 1) From the working window switch to the parameter Automatic calibration via the menu items Configuration menu, Hydraulic calibration and Min. pulse calibration. 2) Call up the parameter Automatic calibration and follow the instructions displayed. 3) Finish the min-pulse calibration and return to the working window or carry out a maxpulse calibration.
  • Page 41 Manual min-pulse calibration of the control loops of the MLS 508: From the working window switch to the parameter Manual calibration via the menu items Configuration menu, Hydraulic calibration and Min. pulse calibration. 2) Call up the parameter Manual calibration and follow the instructions displayed. Pressing the function key F3 completes the min-pulse calibration of the selected channel.
  • Page 42 8.4.3 Max-pulse calibration The maximum cylinder speed of each machine depends on the physical conditions. In most cases, a tool moves much faster in the “lowering” direction as the weight of the tool exerts an additional “pull” on the hydraulic cylinder. In this menu item the operator can synchronize the cylinder’s movement at full impulse in the raising or lowering direction by setting the emitted max-pulse.
  • Page 43 Automatic max-pulse calibration of the two control loops left and right: 1) From the working window switch to the parameter Automatic calibration via the menu items Configuration menu, Hydraulic calibration and Max. pulse calibration. 2) Call up the parameter Automatic calibration and follow the instructions displayed.
  • Page 44 Manual max-pulse calibration of the control loops of the MLS 508: 1) From the working window switch to the parameter Manual calibration via the menu items Configuration menu, Hydraulic calibration and Max. pulse calibration. 2) Call up the parameter Manual calibration and follow the instructions displayed. Pressing the function key F3 completes the max-pulse calibration of the selected channel.
  • Page 45 8.5.3 Power-on information lines When the system is powered up, 3 information lines are displayed, along with the system designation and the manufacturer’s logo. These information lines can be edited by the user in this menu item (e.g. company name, machine model, driver’s name, etc.). Each line may contain a maximum of 20 characters.

  • Page 46: Default Values

    Summary for the hydraulic calibration Info: if the machine software is V1.03, it is necessary to turn the driving level switch to “Milling” and turn on the milling drum. Otherwise the leveling columns will not be accessed. Attention!!! The machine hast to be in the half way of the lifting columns and must be free from the ground.
