- Page 1 SwingTracker User Guide Model: DKST02 User Guide ...
- Page 2 PACKAGE CONTENTS What comes in the Box USING YOUR SWINGTRACKER SENSOR Attach SwingTracker Sensor to your Bat Turn On Your Sensor Pair your Sensor Remove your Sensor from the Charging Mount Charge your Sensor Check Battery Life and Power SWINGTRACKER APP Download the Mobile App Create an Account Setting Load Position Start a Swing Session SWINGTRACKER SWING MEASURES SENSOR CARE INSTRUCTIONS Moisture Storage Temperature Sensitivity and Storage Technical Specifications SUPPORT ...
-
Page 3: Package Contents
● Your SwingTracker sensor contains sensitive electronic components. Do not attempt to modify or repair your SwingTracker sensor yourself. Disassembling your sensor will void the manufacturer’s warranty. ● The SwingTracker sensor contains small parts and is a choking hazard. It is not appropriate for children under the age of three. ● Your SwingTracker sensor is splash proof. However, do not use your sensor in rain or submerge under water. ● Do not overstretch the sensor strap. It is only intended for use with the SwingTracker sensor. ● Unplug the USB power cable and discontinue use if it has become damaged or has been exposed to rain, liquid or excessive moisture. PACKAGE CONTENTS What comes in the Box ● Sensor ● Sensor Mount ● Sensor Strap ● Charging Station ● Storage Pouch Works with the free SwingTracker iOS App ... - Page 4 Turn On Your Sensor With the sensor attached, tap the bottom of bat on the ground twice to turn on the sensor. The light will begin to flash quickly. When you pair your sensor under Settings on your device, the light will flash slowly. The sensor will also automatically turn off after a few minutes of inactivity. Pair your Sensor You will need to pair the SwingTracker sensor to your iOS device to collect data. ● Go to Settings > Bluetooth ● Enable Bluetooth in the Settings Menu, if it is not already on. ● Select the "SwingTracker” sensor. Once paired, your app will automatically connect with the sensor for future use when the sensor is charged and on. If you do not see SwingTracker in the device list ● Confirm that the sensor is charged. If it is not, go to the “Charging your Sensor” section ● Check that it is not connected to another nearby iOS device. ● Confirm SwingTracker is close to the iOS device and try again. Remove your Sensor from the Charging Mount To remove sensor from mount, pushdown and turn the sensor counterclockwise 1/8 turn to unlock. Remove internal sensor from sensor mount. Sensor light will change from a blinking red to a solid green light when fully charged. ...
- Page 5 Charge your Sensor Remove the sensor from the sensor mount. Plug the charging station into a powered USB port. Place the SwingTracker in the center of the charging station. The sensor light will change from a blinking red to a solid green light when fully charged. Never force a charge cable into the USB port of your SwingTracker charging station. If the charge contact does not easily fit, confirm that they are properly aligned before attempting to insert again. ONLY use the USB charging cable provided to charge your SwingTracker sensor. Diamond Kinetics is not responsible for the operation of thirdparty accessories. Check Battery Life and Power Turning The Sensor On : With the sensor attached, tap the bottom of bat on the ground twice to turn on the sensor. You will see a green light flash rapidly if not paired. The light will flash slowly when paired to an iOS device. Determine Battery Charge : A battery indicator is listed at the top of the SwingTracker app screen when you are paired with the app collecting swing data. The sensor will blink red and app will alert you when the battery is low. Sleep Mode : The sensor will go into sleep mode and the light will stop blinking if ...
- Page 6 Download and install the SwingTracker app from the iOS App Store. Create an Account Open the SwingTracker App. Select S IGN UP , choose C OACH o r PLAYER a nd your skill level. Once you select continue, you can enter your profile information to customize your SwingTracker experience. Setting Load Position We recommend that you set the load position of your sensor before taking swing data. To do so, pair your sensor and then select M Y LOAD POSITON f rom ...
- Page 7 Start a Swing Session To start your first swing session, select S wing Away on the bottom right of the screen. You will then be asked to provide the details of your current swing session. You must select a Bat and Load Position to take swings. The SwingTracker app will guide you to set your L oad Position. When selecting B at , you can select an existing bat or A dd A New Bat . Once ...
- Page 8 Select E nd Session t o stop collecting data for a swing session. You can view again it at any time under H istory o n the S ummary s creen. You will see a diamond that represents every swing in the Swing Session. DK Tip: Here are a few tips to capture the best data: ● Get to your natural load point ● Pause the bat for a second or two before taking a swing Do not move the bat excessively when capturing swings ● SWINGTRACKER SWING MEASURES Your SwingTracker system measures four key metrics related to your swing Speed, Power, Quickness and Control. These metrics are then ranked against the database of swings within your skill range. In addition, you are able to see your Potential Exit Velocity and Potential Hitting Distance. DK Tip: Click on the to see detailed summaries that explain each swing metric. Click on any blue flashing light to see a tip. ...
- Page 9 SwingTracker sensors that are damaged as a result of exposure to liquids are not serviceable and are not covered by the Manufacturer’s Warranty. Storage Store your SwingTracker sensor in a cool, dry place at room temperature using the provided Protective Case. Temperature Sensitivity and Storage Avoid exposing your SwingTracker sensor to extreme temperatures. Operate your sensor between 32° and 95° F (0° and 35° C). Avoid dramatic changes in temperature or humidity when using your SwingTracker sensor, as condensation may form within the sensitive electronic components of your sensor. Technical Specifications The SwingTracker App works on iPhone 4 or above or an iPod touch (Gen 3 or above). Works for PCs and Macs for viewing data on the following Supported Browsers: Internet Explorer (10 and above), Google Chrome, Firefox, Safari. SUPPORT Videos, FAQs, troubleshooting and other support is available at diamondkinetics.com/support and in the Settings section of your app. Customer Support You can contact Customer Support at s upport@diamondkinetics.com ...
- Page 10 Diamond Kinetics provides a 1year manufacturers warranty. For more information visit: w ww.diamondkinetics.com/support Compliance and Certifications Symbol Definitions Federal Communications Commission Model: DKST02 FCC ID: 2ABWR DKST02 Industry Canada Model: DKST02 IC: 12312ADKST02 Disposal and Recycling Information Your SwingTracker sensor should be disposed of separately from household waste. Take the sensor to a collection point designated by local authorities that accept batteries and other similar waste. Not all collection points accept products for free. The separate collection and recycling of your product at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and environment. Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio ...
- Page 11 frequency and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment to an outlet on a circuit difference from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician to help. U.S. Patents: 7,021,140 and 7,234,351 ...
