  • Page 1 PANDA HEADPHONES USER MANUAL...
  • Page 3 The world’s first headphones to combine THX ’s acclaimed AAA™ linear amplifier technology with premium planar ribbon drivers, the Drop + THX Panda lets you experience sound just as the way it was intended.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS WARNINGS SPECIFICATIONS Included in Kit PRECAUTIONS General Specs FEATURES Power HOW TO USE Battery Wearing Audio Turn On/Off Microphone Pair Bluetooth Physical Media Controls Optional Accessories Calling Controls TRADEMARKS Charging Wired Use WARRANTY Cleaning ADDITIONAL LANGUAGES LED Meanings Reset Procedure Troubleshooting...

  • Page 5: Warnings

    WARNINGS BATTERIES Please read and keep all safety and use instructions. Do not attempt to remove the battery from the headphones or make any This set contains small parts which ■ unauthorized alterations. Use this may be a choking hazard and not product only with an agency approved suitable for children under age 3.

  • Page 6: Precautions

    Accessing Bluetooth may not always interference by increasing the be possible and it may drop in or out distance between the headphones in various circumstances. Due to this, and any receivers, or power down there might be audio delays or other and move to a new location.

  • Page 7: Features

    FEATURES Adjustable Headband RIGHT EAR Directional Button LED Indicator LEFT EAR USB-C Port Analog 3.5mm Headphone Jack Microphones FEATURES...

  • Page 8: How To Use

    HOW TO USE WEARING The directional button should be on right side. The headband is adjustable. Adjust so the earpieces are comfortably covering the ears. TURN ON/OFF Locate the directional button on the bottom of the right earpiece. To turn on, press and hold for two seconds until the LED indicator turns white.

  • Page 9: Media Controls

    MEDIA CONTROLS FUNCTION DIRECTION ACTION Play/Pause Press button once Next Track Push button right Previous Track Push button left Volume Up Push button up Volume Down Pull button down Media functions use the directional button. CALLING CONTROLS FUNCTION ACTION Answer Call Press button once End Current Call Press button once...

  • Page 10: Charging

    CHARGING Attach the USB-C cable to the USB-C port on the right earpiece. Connect the USB-C cable to a power source. The headphones can be charged with any 5V/1A or higher DC charger, powered hub, or USB port (not included). ADDITIONAL BATTERY NOTES: As headphones charge, the red LED indicator will fade in and out.

  • Page 11: Wired Use

    WIRED USE The headphone has a 3.5mm TRS jack on the bottom of the left earcup which allows the headset to work as a wired passive headphone. The headphone will automatically turn off when a plug is inserted. The directional button will be unresponsive while the plug is inserted.

  • Page 12: Reset Procedure

    RESET PROCEDURE Locate the directional button on the bottom of the right earpiece. To reset ,connect the headphone to a power source using the included USB cable. Press and hold the button for six seconds until the white LED fades. Then turn on by pressing and holding the button for two seconds until the LED indicator turns white.

  • Page 13: Troubleshooting

    TROUBLESHOOTING PROBLEM WHAT TO DO If sound skips frequently Try turning the bluetooth connection off and ■ on again. Make sure the headphone is proper- during playback ly paired with the headset. The situation may be improved by setting the ■...
  • Page 14 PROBLEM WHAT TO DO Battery won’t charge Check that the USB-C cable is securely con- ■ nected to the headphones and the charger. Try another charging source and/or outlet. ■ If your headphones have been exposed to ■ extreme cold or hot temperatures, let the headphones return to room temperature.

  • Page 15: Specifications

    SPECIFICATIONS INCLUDED IN KIT Headphones USB Type-C Cable Neoprene Carry Pouch Drop Sticker Auxiliary 3.5mm TRS Cable Drop 2-Year Warranty SPECIFICATIONS...

  • Page 16: General Specs

    GENERAL SPECS Headphone Type Closed, Planar Magnetic Driver Unit 55m, Ribbon Planar Magnetic Amplification THX AAA-0™ Microphones Dual Wearing Style Circumaural Impedance 26 ohms Frequency Response 10–50,000 Hz THD @ 1kHz / 100dB SPL THD: 94 dB SPL @ 300Hz < 0.1% Sensitivity (dB /Mw) 102 dB/ 1 Mw (1 Khz) Isolation...

  • Page 17: Power

    POWER Cable Type USB-C cable Recommended Power Source Can be charged with any 5V/1A or higher DC charger, powered hub, or USB port (not included) Stand by Mode Headphone will automatically enter standby mode after 15 minutes when nothing is playing.

  • Page 18: Audio

    AUDIO Bluetooth Effective Range Line of sight, approximately 30 feet (10 meters) Frequency Range 2.4 Ghz Band (2.4–2.4835 Ghz) Profile A2DP, AVRCP, HFP, HSP Supported Audio Formats SBC, AAC, APTX, APTX HD, APTX Adaptive, Sony LDAC Pairing Memory Up to 8 devices MICROPHONE Type Dual microphone...

  • Page 19: Physical

    PHYSICAL USB Type-C Cable 48 inches Auxiliary Cable 3.5mm TRS 3.5mm TRS to straight 3.5mm TRS, Cable Single-Sided (Detachable), 48 inches Weight (Headphone Only) 374 grams OPTIONAL ACCESSORIES Boom Microphone Cable 3.5mm TRRS to 3.5mm TRS, 4 feet Y-Splitter Adapter 3.5mm TRRS to split dual 3.5mm TRS, 6 feet SPECIFICATIONS...

  • Page 20: Trademarks

    TRADEMARKS THX and the THX Logos are the property of THX Ltd., registered in the U.S. and other countries. 18 TRADEMARKS...

  • Page 21: Warranty

    WARRANTY This product includes the Drop 2-year Warranty. For more information on terms, limitations, and how to contact Drop, scan the QR code below, or visit https://docs.drop.com/drop-panda-warranty.pdf WARRANTY...

  • Page 22: Additional Languages

    ADDITIONAL LANGUAGES This guide may be available in additional languages. To check for different language, scan the QR code or visit https://docs.drop.com/drop-panda- manual-languages.pdf 20 ADDITIONAL LANGUAGES...
  • Page 24 FOLLOW DROP Visit drop.com to find out the latest information on this product and more. facebook.com/drop twitter.com/drop instagram.com/drop...
  • Page 25 PANDA HEADPHONES QUICK START GUIDE...
  • Page 26 This guide may be available To access the user manual in additional languages. To online, or find additional check for your language, scan languages, scan the QR code the QR code below or visit below, or visit https://docs. https://docs.drop.com/drop- drop.com/drop-panda- panda-qsg.pdf manual.pdf...
  • Page 27 SPECIFICATIONS Headphone Type Closed, Planar Magnetic Bluetooth® Wireless Technology Effective Range Line of sight, approximately 30 ft (10 m) Battery Life (Continuous Playback Time) Maximum of 30 hours Impedance (Passive Mode) 26 ohm Sensitivity (Passive Mode) 102 dB in 1 mW THD @ 1kHz / 100dB SPL THD: 94 dB SPL @ 300Hz <...
  • Page 29 INCLUDED IN KIT: Headphones USB Type-C Cable Neoprene Carry Pouch Drop Sticker Auxiliary 3.5mm TRS Cable Drop 2-Year Warranty...
  • Page 30 Directional Button Press 2 sec Off Press 3 sec USB-C Port Analog 3.5mm Headphone Jack...
  • Page 31 CHARGING Attach the USB-C cable to the USB-C port on the right earpiece. Connect the USB-C cable to a power source. The headphones can be charged with any 5V/1A or higher DC charger, powered hub, or USB port (not included). TURN ON/OFF Locate the directional button on the bottom of the right earpiece.
  • Page 32 FOLLOW DROP Visit drop.com to find out the latest information on this product and more. facebook.com/drop twitter.com/drop instagram.com/drop...
  • Page 33 LED Status Pairing Paired...
  • Page 34 PAIR BLUETOOTH Locate the directional button on the bottom of the right earpiece. While power is off, press and hold for four seconds. While pairing, the LED indicator will blink blue and red. Pairing is successful once the LED illuminates white.
  • Page 35 Directional Button...
  • Page 36 MEDIA CONTROLS FUNCTION DIRECTION ACTION Play/Pause Press button once Next Track Push button right Previous Track Push button left Volume Up Push button up Volume Down Pull button down Media functions use the directional button.
  • Page 37 Directional Button...
  • Page 38 CALLING CONTROLS FUNCTION ACTION Answer Call Press button once End Current Call Press button once Reject Incoming Call Press and hold button Voice Assistant Quickly press button twice Calling functions use the directional button. Functionality may vary based on phone model.
