Summary of Contents for Parker 10MFP
- Page 1 Portable Filter Carts 10MFP with Moduflow™...
- Page 2 Applications for Portable Filter Carts Parker portable filter carts are the Once water comes into contact ideal way to prefilter and transfer with this material, it is removed fluids into reservoirs or to clean up from the system. existing systems.
- Page 3 Features...
-
Page 4: Specifications
EPDM (high temp option) Visual differential type Wands – PVC (Std.) 3-band (clean, change, bypass) Electrical Motor: Steel tube (high temp option) 10MFP – ¾ hp @ 3450 rpm, Weight: Filter Bypass Valve Settings O.D.P. 110 lbs. (45.4kg) (Integral to Element): Thermal overload protection Inlet –... - Page 5 The results in the chart are based on the following assumption: Performance Initial contamination level is 500,000 particles greater than 10 micrometers per 100 ml of fluid (10MFP cart). Inlet filter fitted with 40SA element; outlet with 20Q element. Media...
-
Page 6: Troubleshooting
Assembly The condition of the filter Maintenance Instructions element should be monitored Install hoses to inlet and outlet Turn switch to OFF position by observing the cleanliness filters by threading the hose and unplug cord from electri- indicator on the outlet filter. end with the straight thread cal outlet. -
Page 7: Ordering Information
Ordering Information 940971Q... - Page 9 ® Guardian Portable Filtration System...
- Page 10 Ground Support Hydraulic Service The Guardian portable fi ltration system is a unique pump/motor/ fi lter combination designed for conditioning and transferring petroleum-based and water emulsion fl uids. It protects your system from contamination added with new fl uid because new fl uid is not necessarily clean fl uid.
- Page 11 Features Advantages Benefi ts Lightweight, hand held, Easy to carry and fi ts One person compact design (less easily on top of 55 operation, capable of than 24 Ibs 16” X 8” ap- gallon drums. getting to hard to reach proximate foot print).
- Page 12 Guardian Series Installation and Specifi cation Data Maximum Allowable Operating Operating Temperatures: Electrical Motor: ¼ hp@2500 rpm. Pressure (MAOP): 50 psi (3.4 Unit: -15°F to 180°F (-26°C to 24 VDC; 10A max. bar) 82°C) 110-120 VAC; 50/60 Hz; 3A max. Wand/Hose: 25°F to 120°F 220-240 VAC;...
- Page 13 * Not applicable Estimated Guardian Element Life and Cleanliness Levels The following chart shows typical element life achieved by standard Parker elements available with the (in gallons of oil passed) and cleanliness levels Guardian. Some assumptions have been made.* Media...
-
Page 14: Troubleshooting Guide
Guardian Operation Guardian Element Servicing A. Remove all shipping plugs from the hoses and fi ttings. A. Flip the switch on the end of the unit to the “off” position B. Connect the inlet and outlet hose assemblies to the unit. and disconnect the electrical plug. - Page 15 Guardian Replacement Parts Replacement Elements Media Part No. Box Qty. 933467Q 932018Q 932017Q 933468Q 932016 932020 922627 922628 922626 932019 Parts List 1. Label ....Consult Factory 12.
-
Page 16: How To Order
Please note the bolded options refl ect standard options with a reduced lead- time. Consult factory on all other lead- time options. Global products as identifi ed are offered worldwide through all Parker locations and utilize a common ordering code.
