Aervoe Sierra Wave Spirit Operating Instructions

IMPORTANT SAFEGUARDS
Read all instructions before operating
Warning: (to reduce the risk of electric shock, injury, or damage to this product)
• Check voltage of your device for compatibility
• Do Not submerge the unit or its accessories in any liquid
• Do Not drop, crush, or puncture
• Do Not disassemble due to risk of injury
• Do Not use in flammable or explosive areas
• Operating at temperatures above 140ºF (60Cº) may cause damage
• Discontinue use if electronic components or accessories are damaged
• Store in a clean dry place when not in use
• Recharge every 3 months when not in use
• Administer close supervision when using around children
IMPORTANT:
Before use, please charge via the USB port for 8 hours.
CHARGING
There are 2 ways to charge the Spirit:
USB Charging
This feature uses any USB output such as from a computer, AC wall charging adapter, or
other power supply. Using the included USB CHARGING CABLE, plug the MICRO USB TIP
into the end of the charging cable and into the INPUT PORT on the Spirit. Plug the other
end into the USB port of the device you are charging from. After connection, the CHARGING
LED INDICATORS will flash showing that it is being charged. The blue LEDs will flash when
charging as shown:
• Right blue LED flashing: 10%-30% battery capacity
• Center blue LED flashing: 31%-70% battery capacity
• Left blue LED flashing: 71%-100% battery capacity
• When it is finished charging, all LED indicators will stop flashing and remain lit.
Solar Charging
Charge from the built-in SOLAR PANEL under direct sunlight. The RED LED CHARGE
INDICATOR will be ON when it is charging from the solar panel, but no blue LED lights will
be lit or flashing. Repositioning will be required throughout the charging cycle to keep the
solar panel in direct sun.
Check Battery Capacity Level: To check battery capacity level when not charging, press
POWER/TEST BUTTON. The blue LED indicators will light indicating battery capacity level
according to the instructions in the USB Charging section.
CHARGING YOUR DEVICE
WARNING:
Only charge a 5V compatible device.
1. Insert the USB CHARGING CABLE into the OUTPUT PORT.
2. Attach the appropriate TIP into the end of the cable and then into the charge port of
your portable electronic device.
3. Blue LED indicator should turn ON for 5 seconds confirming that your device is being
charged. After 5 seconds, the blue LED indicator will turn off as your device continues
to be charged .
4. When your device is fully charged there is no need to disconnect the Spirit.
PARTS IDENTIFICATION / IDENTIFICATION DES PIÈCES / IDENTIFICACIÓN DE PARTES
1
2
3
5
4
1 - Solar Panel / PANNEAU SOLAIRE / PANEL SOLAR
2 - Output Port / PORT DE SORTIE / PUERTO DE SALIDA
3 - Input Port / PORT D'ENTRÉE / PUERTO DE ENTRADA
4 - Charging Indicator LEDs / VOYANTS DE CHARGE DEL / INDICADORES LED DE CARGA
5 - Red Solar Charge LED / VOYANT DE CHARGE DEL ROUGE / INDICADOR LED ROJO
6 - Power/Test Button / ALIMENTATION/BOUTON DE TEST / BOTÓN ENERGÍA/PRUEBA
Includes: Inclut :
1-USB charging cable 1-Câble de recharge USB
1-Micro USB tip 1-Embout USB Micro
1-Embout iPhone Lightning
1-iPhone Lightning tip
1-iPhone 30 pin tip 1-iPhone embout à 30 Pin
TECHNICAL INFORMATION
INTERNAL RECHARGEABLE BATTERY
BATTERY CAPACITY
SOLAR PANEL
RATED INPUT
RATED OUTPUT
OPERATING TEMPERATURE
WEIGHT
DIMENSIONS
CHARGING TIME
6
Solar Panel
With bright sunlight. Clouds and other obstructions will
affect the charging time.
USB - 5V power supply/1A
DEVICE CHARGE TIME ESTIMATES
Only charge 5V USB compatible devices (check your device's
owner's manual). Times vary depending on device charge rate and
battery capacity.
Samsung Galaxy (2800mAh battery)
Apple iPhone 4 or 5 series (1440mAh or 1570mAh battery)
Tablets
Incluye:
1-Cable de carga USB
1-Punta Micro USB iPod, MP3/MP4, Camera, GPS
1-Punta iPhone Lightning
1-iPhone punta 30 pin
SPECIFICATIONS
Lithium-Polymer
3.7V 2800mAh (10Wh)
Monocrystalline Silicone, 5.5V, 120mA, 0.66W
USB 5.0V, 500mAh
USB 5.0V, 2A max
23º - 113ºF (-5º - 45ºC)
3.4 oz. (96g)
4.125" L x 2.5" W x 0.4" H (106 x 63 x 11mm)
20 hours
4-5 hours
Time and capacity based
on a fully charged Spirit
Power Bank.
3-4 hours
75% capacity max
3-4 hours
Charge 1½ times
3-4 hours
30% capacity max
Charge up to 2 times
depending on device bat-
tery size
