ZEVAC® OPERATOR'S MANUAL

1/22/2018

THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,

OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ

CAREFULLY AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND

PRODUCT LABELS, FAILURE TO DO SO COULD RESULT IN SERIOUS PERSONAL INJURY

AND/OR PROPERTY DAMAGE. THIS EQUIPMENT SHOULD ONLY BE OPERATED BY

TRAINED PERSONNEL

Table of Contents

Need help?

Do you have a question about the ZEVAC and is the answer not in the manual?

Questions and answers

Summary of Contents for TPE ZEVAC

Page 1 [BM1] ZEVAC® OPERATOR’S MANUAL 1/22/2018 THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, FAILURE TO DO SO COULD RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.
Page 2: Table Of Contents
Thank you for choosing to ZEVAC® instead of venting or flaring. This manual covers the operation and maintenance of ZEVAC® equipment. The information and specifications included in this publication were in effect at the time of approval for printing. No part of this publication may be reproduced without written permission.
Page 3: Safety
This includes any modification to the equipment or use of parts not provided by TPE MIDSTREAM. If there is a question regarding the intended use of the equipment, please contact a TPE representative before proceeding.
Page 4: Components & Control Locations
USER SAFETY These safety rules always apply: • Always keep the work area clean. • Pay attention to the risks presented by gas and vapors in the work area. • Always bear in mind the risk of unplanned depressurization and release of energy. Use safety equipment according to the company regulations.
Page 5: Controls
Control Form Function Air On/Off Manual Valve In the closed position, air supply is shut off to the ZEVAC – shutting down the machine. Air Pressure Regulator Manual Adjustment Raise or lower the maximum air pressure delivered to the ZEVAC.
Page 6 Discharge Pressure Automatic Interlock In the event that the discharge Shutoff pressure exceeds the set point, this control valve will prevent the ZEVAC from continuing to actuate. Suction Pressure Automatic Interlock In the event that the gas suction Shutoff...
Page 7: Check Before Operation
Air supply is connected to ZEVAC in a secure fashion Air supply connection piping / hoses have been verified to be leak-free Air regulator is set to deliver adequate pressure to ZEVAC (100 – 250 psi) VERIFY Hose halters are in place on all hose connections...
Page 8: Startup
STARTUP Pre-Startup Purge (First Startup) In order to avoid the mixture of air and flammable gases, it is required to purge the ZEVAC® of air before introducing other gasses. Purging can be accomplished with inert nitrogen. The procedure for performing this purge is listed here: Step Check Description Connect an inert gas such as Nitrogen to the Gas Intake piping (“Tree”)
Page 9: Operation
ZEVAC® low-pressure shutoff switch should automatically stop ZEVAC function Close Air Control Valve Close Gas Discharge Isolation Valve Open Gas Discharge Vent valve to depressurize ZEVAC® and discharge piping TRANSPORTATION AND STORAGE DANGER Disconnect and Follow Lock-out / Tag-out (LOTO) procedures for all process and energy connections.
Page 10 The equipment must always be lifted using safe working practices and in accordance with any local and national guidelines or statutes. 1. Check that the site where the ZEVAC® is placed has a clean and level surface. Stones and other debris damage the bottom structure of the unit.
Page 11: Cold Weather Operation
2. If the unit was secured to a pallet, flatbed or other surface, cut the transportation straps. 3. Align the forklift prongs with the forklift holes in the bottom of the ZEVAC® base. 4. Insert the forklift prongs into the forklift holes.
Page 12: Warranty
• All service and repair work that is done by TPE authorized personnel. • Genuine TPE parts are used. • Only Ex-approved spare parts and accessories that are authorized by an Ex-approved TPE representative are used in Ex-approved products. Limitations - The warranty does NOT cover defects that are caused by these situations: •...
Page 13: Troubleshooting
• Verify the drawdown system is isolated. If the drawdown system is open to any source of flow, the ZEVAC will not be able to reduce the system pressure. This can occur in the case of a valve leaking past its seats while in the closed position. As the ZEVAC is evacuating gas, the valve is allowing gas to enter the drawdown system and the pressure may not drop or may reduce more slowly than normal.
Page 14 • It is common for air compressors to introduce moisture to the air supply. There is equipment on the ZEVAC® that is designed to eliminate as much of this water as possible, but it is common in certain operating conditions such as high humidity for water vapor, mist, and liquids to be present in the air system.
Page 15 4. Always maintain clear access to the air compressor supply air to the device. In the event that the ZEVAC unit cannot be accessed and needs to be shut down, turn off the air supply. 5. Always turn off the unit when making adjustments or changing connections.
