Sealey SA397 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual

1. SAFETY

Disconnect the gauge from the air supply before changing accessories, servicing or performing any maintenance.
9
Maintain the gauge in good condition (use an authorised service agent), and keep the gauge clean for best and safest performance.
9
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Locate gauge in a suitable work area, keep area clean and tidy and free from unrelated materials and ensure there is adequate lighting.
9
Keep children and unauthorised persons away from the work area.
9
DO NOT direct gauge outlet at yourself or at other persons or animals.
8
DO NOT carry by the hose, or yank the hose from the air supply.
8
DO NOT use the gauge for a task which it is not designed to perform.
8
DO NOT operate the gauge when you are tired, under the influence of alcohol, drugs or intoxicating medication.
8
DO NOT operate the gauge if any parts are missing or the gauge is damaged, as this may cause failure and/or personal injury.
8

2. INTRODUCTION

Die cast aluminium body with large rubber bumper, backlit LCD digital display and battery level indicator. Auto power off after eight seconds and
auto power on once pressure is sensed, or air inflation starts. 350mm flexible hose fitted with 240mm, twin push-on air connector. Supplied with
a serial numbered calibration certificate.

3. SPECIFICATION

Model no: ................................................................... SA397
Range: ............................................................ 12bar (174psi)
Pressure units: ................................................... bar, psi, kPa
Air supply minimum: ....................................... 6.9bar (100psi)
Air supply maximum: .................................... 13.8bar (200psi)
Inlet size: ...................................................................1/4"BSP
Battery: ..................................................... 2 x AAA (supplied)
Battery life: ............................................................... 80 hours
Accuracy: ........................................................25-75psi ±2psi

4. CALIBRATION CERTIFICATE

This tyre inflator Model number SA397, has been calibrated in its normal working
position on test equipment with an accuracy that is traceable to International
Standards according to 86/217/EEC.
Serial number:
Date:
ALLOWABLE TOLERANCE
± 1.2 Up to and including 58 p.s.i.
P.S.I.
± 2.3 Between 58 and 145 p.s.i. inclusive
± 3.6 Greater than 145 p.s.i.
TEST RESULTS
REFERENCE PRESSURE
DISPLAY PRESSURE P.S.I.
© Jack Sealey Limited
INSTRUCTIONS FOR
PROFESSIONAL DIGITAL TYRE INFLATOR WITH
TWIN PUSH-ON CONNECTOR
MODEL NO:
29.0 58.0 87.0 116.0
Original Language Version
SA397
SA397 | Issue 1 20/11/15
