Page 1 FLF 15000/1800/500 Panther 8x8 CA-7 OPERATION MANUAL FLF 15000/1800/500 PANTHER FLF 15000/1800/500 PANTHER Air Crash Tender Air Crash Tender © 2014 Page - 1 - 27.02.2014 / Rev. 00 / CSD-TPas...
Page 2: Table Of Contents
Table of Contents FLF 15000/1800/500 Panther 8x8 CA-7 Table of Contents Table of Contents ..............2 Introduction ................3 Manufacturer and After-Sales-Service Address ....... 3 List of Conventional Signs ............4 Technical Data ................. 6 Technical Description ............17 Bracket for Breathing Apparatus ........... 23 Switches and Controls in the Drivers Cabin ......
Page 3: Introduction
Rosenbauer is not liable for any injury or damage caused by personnel unfamiliar with the operational procedures described in this manual, failing to comply with the operation manual and/or failing to comply with regulations, subsequent procedures, safety and accident prevention.
Page 4: List Of Conventional Signs
Signs and Symbols FLF 15000/1800/500 Panther 8x8 CA-7 List of Conventional Signs This sign indicates optional equipment that means: The described position may not be installed on your unit, but it is a customer specific installation. CAUTION ! This warning indicates possible danger to life and health of persons. ATTENTION ! This warning indicates other dangers.
Page 5 Signs and Symbols FLF 15000/1800/500 Panther 8x8 CA-7 Prohibition Signs - No smoking - Handling of open flames is prohibited. - Keep your distance! Be extremely careful! Mandatory Signs - Use ear protection. - Wear helmet. - Wear protective eye glasses. - Wear protective work boots.
Page 6: Technical Data
Permissible weight: Front axle I ....... 13000 kg When changing the tyre type call for Front axle II......13000 kg written approval from Rosenbauer. Rear axle I ......13000 kg Rear axle II ....... 13000 kg Gross vehicle weight ..52000 kg Angle of approach .....
Page 7 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Water tank Manufacturer: ROSENBAUER Capacity: 15000 l Maximum tank pressure: 0.2 bar Material: polypropylene plastic Manhole: removable ø 450 mm cover Overflow: 2 x with over- and under pressure diaphragm Tank level indicator:...
Page 8 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Foam compound tank Manufacturer: ROSENBAUER Capacity: 1800 l + 5% reserve Maximum tank pressure: 0.2 bar Material: polypropylene plastic Location: integrated into the rear part of the water tank Manhole: removable ø 450 mm cover...
Page 9 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Pump Manufacturer and type: ROSENBAUER N 100 Performance at tank suction operation: 9000 l/min at 11 bar Closing pressure: 13.5 bar Design: single stage Pump speed: max. 1800 rpm Pump shaft seal: mechanical seal...
Page 10 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Pump gearbox for N 100 Manufacturer and type: ROSENBAUER gearbox N 100 Ratio with reversal of rotation: Z1=64 : Z2=79 -> i=0,81 * from counterclockwise to clockwise without reversal of rotation: Z1=53 : Z2=64 : Z3=79 -> i =0.67...
Page 11 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Foam proportioning system Manufacturer and type: ROSENBAUER RVME 600 MID Material: light alloy Measuring range water flow: 200 - 10000 l/min foam compound flow: 10 - 600 l/min Performance: up to 600 l/min foam compound with...
Page 12 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Roof turret Manufacturer and type: ROSENBAUER RM 60 C Location: mounted on the roof of the cabin Material: light alloy Nozzle: HSD 6000 CFD Performance with full output: 6000 l/min at 10 bar...
Page 13 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Bumper turret Manufacturer and type: ROSENBAUER RM 15 C Location: mounted on the front bumper Material: light alloy Nozzle: HSD 1500 CFD Performance: 1500 l/min at 10 bar Throwing range: approx. 65 m with full output...
Page 14 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Rapid intervention system Manufacturer and type: ROSENBAUER low pressure hose reel 06 Material: ABS/PE plastic Brake: friction brake Rewinding device: manually by crank and electrically Location: in the right locker compartment swivelable by 45 ° and 90 ° in driving...
Page 15 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Dry powder unit Manufacturer: MINIMAX Type: P-BCsv 500 (2x250) epn Dry powder: 2 x 250 kg Combi Troxin BC compatible to foam compound Control: electro-pneumatically Propellant gas bottle: 25 ltr Propellant gas: nitrogen Filling pressure: 200 bar Number:...
Page 16 Technical Data FLF 15000/1800/500 Panther 8x8 CA-7 Deluge system Manufacturer: ROSENBAUER Capacity: connected to the water tank Drawing connection: DN 25 ball valve on the front lowest partition of the water tank Deluge pump: 24 VDC Nozzle: 4 nozzles above the windscreen...
Page 17: Technical Description
Disengage the pump if no water is discharged for a long period! ATTENTION ! It is strictly prohibited to make any modifications on pump without approval of ROSENBAUER. © 2014 Page - 17 -...
Page 18 Pump impeller suction cover The Rosenbauer pump N 100 is a single-stage high volume pump with spiral casing and diffusor. Because of the low nominal pump speed, the pump is best suited for direct connection (without a pump gearbox) to a low rpm engine, therefore a dramatic reduction of noise and harmful emission is achieved.
Page 19 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Computing maximum lift Priming system KAP 600 Lift is measured from the surface of the Since a centrifugal pump is not a self suction pump, a priming pump static source to the centerline of the system is installed, which removes air from the pump allowing the pump.
Page 20 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Cutaway view of piston priming pump Saugventilplatte Suction Valve Plate Ventildeckel Valve Cover Druckventilplatte Pressure Valve Ventildeckel Valve Cover Exzenter Eccentric Absaugleitung Absaugleitung Priming Line Priming Line Ausstoßöffnung Exhaust Line Pumpengehäuse Pump Housing Ausstoßöffnung Saugventilplatte Exhaust Line...
Page 21 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Schedule with magnetic inductive flow meter in the water Electronic controlled foam-proportioning system RVME 600 and foam compound pipe - optional equipment The RVME 600 is mainly composed of a foam induction pipe with pressure outlets pressure outlets injector, foam proportioning system and control.
Page 22 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Overheating protection system The pump case is equipped with a temperature sensor which controls the overheating protection system. The pump drain valve opens and the pilot lamp (H62) illuminates on the external pump control panel and a warning is displayed on the pump control screen in the cabin, when 60 °...
Page 23: Bracket For Breathing Apparatus
Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Bracket for Breathing Apparatus Bostrom brackets Opening the bracket for breathing apparatus - Stop the vehicle and apply parking brake. - Fasten the belts of breathing apparatus. - Pull the "release-lever" of the breathing apparatus bracket. - Take out the breathing apparatus.
Page 24 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Comfort 2002 brackets - Opening the bracket for breathing apparatus: ◊ Stop the vehicle and apply parking brake. ◊ Fasten the belts of breathing apparatus. ◊ Lift lever (Z250). The headrest with lock system swivels upwards and releases the breathing apparatus.
Page 25: Switches And Controls In The Drivers Cabin
Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and Controls in the Drivers Cabin Switches and pilot lamps of fire fighting superstructure in the cabin on the right hand side reading lamp with integrated switch * display for front camera */*** air conditioning temperature regulator ** heating temperature regulator ** switch: fog lights "1...
Page 26 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin S395 on the right hand side S1/3 switch: two-tone acoustical alarm activation - active if switch (S1/1) is ON only - please see page 28 * switch: hazard warning lights ** steering column switch ** switch: adjustment of rear view mirrors...
Page 27 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin on the right hand side panther driver's display ** after engaging the ignition the driver's screen will be displayed Note: By using switch (S383) or (S384) the next/previous screen (pump operation screen) will be displayed;...
Page 28 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin E50 AN on the left hand side cover and lock for the emergency control elements * reading lamp with integrated switch display for camera on the roof turret */*** switch: emergency water pump engagement - only active with the drive engines are engaged * switch: manual throttle control during emergency operation *...
Page 29 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin on the centre console joystick for control the bumper turret - for detailed information please refer to the "Bumper Turret Operation" chapter control handle for control the roof turret- for detailed information please refer to the "Roof Turret Operation"...
Page 30 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin S385 S330 N9 S152 on the centre control panel fire fighting display After engaging the ignition the pump operation screen will be displayed. By using switch (S383) or (S384) the next/previous screen will be displayed.
Page 31 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Installations in the rear partition of the cabin microphone of public address system (U18) microphone of radio system (U21a) microphone of radio system (U21b) * public address system *** U21a radio *** U21b radio 2 */*** X120 socket for speaker system * Note: * A second socket is placed on the roof turret's control panel.*...
Page 32 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin - vehicles electrics main control box with fuses (FB) - electrics of fire fighting system - placed behind the left codrivers seat; accessible after removing the cover The description of the fuses please find on the sticker affixed on the cover.
Page 33 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin B9/1 B9/2 on the left hand side B9/1 speaker - not in use * B9/2 speaker - not in use * switch: left cabin door control * optional equipment Switches and pilot lamps of fire fighting superstructure in the cabin B9/3 B9/4...
Page 34 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin H186 A2CP A2CP cabin pump control panel warning lamp: indicates low battery charging of pump engine warning lamp: indicates low oil pressure of pump engine H186 multiple warning lamp: it is blinking together with an active warning lamp switch: manual control of the priming pump...
Page 35 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin Panther operator's display - after engaging the ignition the pump operation screen will be displayed. The following descriptions describe the state of the display in the respective situations.
Page 36 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin PDD panther driver's display - for further information please refer to the chassis operation manual pilot lamp: indicates engaged rotating beacons pilot lamp: indicates open roller shutter or compartment door If the parking brake is released while a locker compartment is open, the (H6) indicator light changes from yellow to red, starts blinking together with (H186) warning triangle and...
Page 37 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps of fire fighting superstructure in the cabin pump drain valve J10hl left bottom regulated handline discharge valve * J10hr right bottom regulated handline discharge valve * J10l left handline discharge valve J10r right handline discharge valve water drafting valve water tank suction valve...
Page 38: Operation Elements On The External Control Stations
Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Operation Elements on the Left and Right External H108 J164 Control Stations S116 Indications, controls and connections on the left hand side A4LP left external pump control panel - for detailed information please see next pages pilot lamp: indicates water tank content less than one third H108 pilot lamp: indicates foam compound tank content less than one third...
Page 39 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Controls and connections on the left hand side X104 J10 Y115 emergency tool for control the pneumatic actuators - not shown - for further information please refer to the "Emergency Control of Pneumatic Actuators" chapter DPU control panel for the dry powder unit - for further informa- tion please refer to the manufacturer's operation manual handline discharge valve...
Page 40 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Switches and pilot lamps on the left pump control panel H186 H17 S9- A4LP A4LP left external pump control panel - detailed information pilot lamp: indicates engaged pump pressure governor and cavitation * warning lamp: indicates low battery charging of pump engine warning lamp: indicates low compressed air supply for fire...
Page 41 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Controls and connections on the right hand side J106 Y115 S168 emergency tool - for further information please refer to the "Emergency Control of Pneumatic Actuators" chapter EFP electric powered foam compound pump discharge valve J10h regulated discharge valve * discharge connection...
Page 42 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Further installations in the pump compartment oil fill plug of the priming pump J61r revision valve of the foam compound tank Note: valve open -> this is the normal operation position Close the revision valve only during maintenance or service work.
Page 43 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 External water tank content indicators placed behind the cabin on the left and right hand sides visual tank level indicator - tank content 100% visual tank level indicator - tank content 80% visual tank level indicator - tank content 60% visual tank level indicator - tank content 40% visual tank level indicator - tank empty <20% Note: When tank is full, the indicators (E60 - E63) illuminates.
Page 44 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Power supply X101 230 Volt AC terminal Components powered via supply socket (X101) - description of the fuses in succession from rear to front: Q1 - FI-safety cutout Q2 - right engine coolant heating Q3 - left engine coolant heating Q4 - battery charging units Q5 - compressor...
Page 45 Technical Description FLF 15000/1800/500 Panther 8x8 CA-7 Power supply X121 X122 battery isolating switch - press -> ON, pull -> OFF - for further information please refer to the chassis operation manual S463 switch: emergency stop for the left drive engine -> S464 switch: emergency stop for the right drive engine ->...
Page 46: Preparation For Use
Preparation for Use FLF 15000/1800/500 Panther 8x8 CA-7 Preparation for Use CAUTION ! Before operating the vehicle pay attention to the following: - Have the safety and support of the fixing devices been checked? - Is the hinged ladder locked ? - Are the supply cables (power supply, compressed air) discon- nected ? - Have the wheels and their air pressure been checked ?
Page 47: Locker Compartment Doors
Doors FLF 15000/1800/500 Panther 8x8 CA-7 Locker Compartment Doors The left and right locker compartment doors are pneumatically powered. The door control functions when - the ignition is engaged and - the appropriate door is unlocked (if locked the integrated pilot lamp in switch (S355) blinks) and - the pneumatic supply pressure is more than 6.5 bar.
Page 48: Starting The Drive Engines
Driving the PANTHER FLF 15000/1800/500 Panther 8x8 CA-7 Starting the Drive Engines ATTENTION ! For further instructions please refer to the chassis operation manual. Tow away adapter ATTENTION ! For towing the panther always use the front or rear tow away adapter respectively as shown in the picture beside.
Page 49 Driving the PANTHER FLF 15000/1800/500 Panther 8x8 CA-7 Alarm Start S395 In order to reduce intervention time, the panther is equipped with an alarm-start-device. It is possible thereby to start the drive engines from outside before entering the cabin. Condition: Battery isolating switch (S31) engaged. Emergency stop switch (S34) in the ON position.
Page 50: Engaging The Pump
Engaging the Pump FLF 15000/1800/500 Panther 8x8 CA-7 Engaging the Pump - The operation of the pump unit is independent of the PAN- THER's drive mode. ◊ Start the drive engines as mentioned in the chassis operation manual. Note: Engaging the pump is controlled electronically. The pump is driven by the right engine which is then no longer used for traction power.
Page 51: Roof Turret Rm 60 C
Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Roof Turret RM 60 C Description of RM 60 C Z120 U38t The electronically controlled RM 60 C turret, mounted on the vehicles roof is designed for water operation as well as for water/ foam operation.
Page 52 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Description of control handle of RM 60 C The turret is remotely controlled from the drivers cabin. This is done by a control handle. The turret follows the movement of this control handle. control handle position LED START - switch...
Page 53 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Roof turret RM 60 C - operation with water - Operate pump in automatic mode (base setting): ◊ The integrated pilot lamp in switch (S54) is off. - Engage the pump: ◊ Please refer to the "Engaging the Pump" chapter. - When the pump is engaged the following program starts: ◊...
Page 54 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Roof turret RM 60 C - operation with foam S14/1 - Operate pump in automatic mode (base setting): ◊ The integrated pilot lamp in switch (S54) is off. - Engage the pump: ◊...
Page 55 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Stopping of turret operation: ◊ Press switch (S18) again - the turret is flushed automatically when continuing water discharge. ◊ Release switch (S50) or press activated switch (S488). ◊ The pump engine will idle. ◊...
Page 56 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Roof turret RM 60 C - emergency operation with water or foam If an electric component for the roof turret control is defective the turret can be controlled manually from vehicle's roof. - Press "STOP"-switch (S47).
Page 57: Bumper Turret Rm 15 C
Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Bumper Turret RM 15 C Description of RM 15 C The electronically controlled RM 15 C turret, which is mounted on the front bumper is designed for water operation as well as for water/foam operation.
Page 58 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Bumper turret RM 15 C - operation with water - Operate pump in automatic mode (base setting): ◊ The integrated pilot lamp in switch (S54) is off. - Engage the pump: ◊ Please refer to the "Engaging the Pump" chapter - When the pump is engaged the following program starts: ◊...
Page 59 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Bumper turret - operation with foam S14/1 - Operate pump in automatic mode (base setting): ◊ The integrated pilot lamp in switch (S54) is off. - Engage the pump: ◊ Please refer to the "Engaging the Pump" chapter. - When the pump is engaged the following program starts: ◊...
Page 60 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Stopping of turret operation: ◊ Press switch (S18) again - the turret is flushed automatically when continuing water discharge. ◊ Release switch (S80) or press an activated switch (S80p). * ◊ The pump engine will idle. ◊...
Page 61 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Bumper turret RM 15 C oscillator operation * The bumper turret is equipped with an oscillating mode, which means the turret moves automatically within a preprogrammed S218 area. S219 - Operate the bumper turret as mentioned in the ◊...
Page 62: Undertruck Nozzles
Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Undertruck Nozzles S14/1 - Operate pump in automatic mode (base setting): ◊ The integrated pilot lamp in switch (S54) is off. - Engage the pump: ◊ Please refer to the "Engaging the Pump" chapter. - When the pump is engaged the following program starts: ◊...
Page 63: Manual Pump Operation
Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Manual Pump Operation S9- S54 S11 ATTENTION ! If the automatic mode fail to work the pump system can be operated manually. Procedure: - Shift pump system to manual mode: ◊ Press switch (S54), the integrated pilot lamp illuminates. - Engage the pump: ◊...
Page 64 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Emergency operation after a complete failure of the electric system * Y126 Y283 The most important valves can be controlled pneumatically in the Y133 cabin. - Engage the pump: ◊ Tilt down switch (S2N). - Open the main air supply valve: ◊...
Page 65 Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Emergency operation after a complete failure of the electric system * Y283 The most important valves can be controlled pneumatically in the cabin. Undertruck nozzles operation - Engage the pump: ◊ Tilt down switch (S2N). - Open the main air supply valve: ◊...
Page 66: Stand-By Operation
Air Crash Mode FLF 15000/1800/500 Panther 8x8 CA-7 Stand-by Operation S9- S54 S11 S9+ This procedure protects the pump system from freezing at ambient temperatures below 0 ° C, and prevents the system from overheat- ing. This also applies when the pump must not be disengaged due to an emergency.
Page 67: Tank Suction Operation
Pump Panel Operation FLF 15000/1800/500 Panther 8x8 CA-7 Tank Suction Operation - Connect pressure hoses to the left and/or right pressure outlets. - Shift pump system to manual mode: ◊ Please refer to the "Manual Pump Operation" chapter. - Engage the pump: ◊...
Page 68: Drafting Operation From Open Water Source
Pump Panel Operation FLF 15000/1800/500 Panther 8x8 CA-7 WRONG Drafting Operation from Open Water Source Air pocket in suction hose - Connect suction- and pressure hoses. ◊ The suction hose with attached strainer should be at least 20 cm under the water surface (Do not place the strainer in sand or mud as dirt reduces the service life of the pump system!).
Page 69 Pump Panel Operation FLF 15000/1800/500 Panther 8x8 CA-7 Drafting operation from open water source - Open the drafting valve: ◊ Press switch (S12). - Connect pressure hoses to the left and/or right pressure outlets. - Shift pump system to manual mode: ◊...
Page 70: Hydrant Operation / Supply Operation
Pump Panel Operation FLF 15000/1800/500 Panther 8x8 CA-7 Hydrant Operation / Supply Operation - Shift pump system to manual mode: ◊ Please refer to the "Manual Pump Operation" chapter. - Connect pressure hoses to the left and/or right pressure outlets. - Connect the supply hoses to the drafting connection (J15) (use a collector piece if required).
Page 71 Pump Panel Operation FLF 15000/1800/500 Panther 8x8 CA-7 CAUTION ! - Before opening a handline discharge valve make sure that the nozzles are held tightly - danger of water hammer effect! - Release pressure before disconnecting a hose! CAUTION ! Do not operate the pump with closed pressure outlets - dangerous increase of temperature will result! Water and foam compounds are conducting electricity!
Page 72: Foam Operation
Pump Panel Operation FLF 15000/1800/500 Panther 8x8 CA-7 Foam Operation S14/1 S14/3 Procedure from foam compound tank - Operate the pump as mentioned in the ◊ "Tank Suction Operation" or ◊ "Drafting Operation from Open Water Source" chapter. - Provide the pressure hoses with foam branch pipes. - Open the foam compound tank suction valve: ◊...
Page 73: Watch Out During Pump Operation
Pump Panel Operation FLF 15000/1800/500 Panther 8x8 CA-7 Watch out during Pump Operation - The operator's stand should be always in reach of machinist. Continuously monitor: ◊ Water- and foam compound tank content ◊ Fuel, coolant temperature and oil pressure ◊...
Page 74: Disengaging The Pump System
Pump Panel Operation FLF 15000/1800/500 Panther 8x8 CA-7 Disengaging the Pump System S9- S11 - Reduce engine speed to idle: ◊ Press switch (S9-) until the pump egine idles. - If open, close the foam compound tank suction valve: ◊ Check, if the pilot lamp in switch (S18) in the cabin or (S6) on an external control panel illuminates, press correspond- ing switch.
Page 75: Handline Operation
Handline Operation FLF 15000/1800/500 Panther 8x8 CA-7 Handline Operation - Connect the pressure hoses to the left and/or right pressure outlets (J11). - Connect the pressure hoses to the left and/or right pressure outlets (J11h). * - Connect branch pipes to the pressure hoses. - Pull out the collapsible hoses completely before opening a discharge valve.
Page 76: Twin Agent Rapid Intervention System
It is strictly advised to use the installed rapid intervention device for fire fighting only. Any other use is strictly prohibited by Rosenbauer. In cases of misuse, Rosenbauer is not liable for any injury or damage. S21 Z102 Z108 hose guide frame...
Page 77 Rapid Intervention System FLF 15000/1800/500 Panther 8x8 CA-7 Twin agent rapid intervention system Operation with water - Operate the pump as mentioned in the ◊ "Manual Pump Operation" or ◊ "Tank Suction Operation" or ◊ "Drafting Operation from Open Water Source" or ◊...
Page 78: Rapid Intervention System
Any other use is strictly prohibited by Rosenbauer. Z105 S117 J99 J167 In cases of misuse, Rosenbauer is not liable for any injury or damage. hose guide frame * foam extension - not shown multi-purpose nozzle...
Page 79 Rapid Intervention System FLF 15000/1800/500 Panther 8x8 CA-7 Rapid intervention system Z102 Operation with water - Operate the pump as mentioned in the ◊ "Manual Pump Operation" or ◊ "Tank Suction Operation" or ◊ "Drafting Operation from Open Water Source" or ◊...
Page 80 Rapid Intervention System FLF 15000/1800/500 Panther 8x8 CA-7 Drainage of the left and right low pressure hose reels S116 Y115 The rapid intervention systems are equipped with a purge valve. The system can be drained with the vehicle's compressed air. For stowage and to protect the system from freezing in adverse conditions, the hoses and the nozzles must be dained carefully after each use.
Page 81: Filling The Water Tank Via The Pump
Filling the Water Tank FLF 15000/1800/500 Panther 8x8 CA-7 Filling the Water Tank via the Pump - Operate the pump as mentioned in the ◊ "Drafting Operation from Open Water Source" or ◊ "Hydrant / Supply Operation" chapter. - Open the water tank pump fill valve: ◊...
Page 82: Filling The Water Tank Via Tank Supply Lines
Filling the Water Tank FLF 15000/1800/500 Panther 8x8 CA-7 Filling the Water Tank via Tank Supply Lines - Connect supply hoses to the left and/or right connections (J30). - Open hydrant valve slowly. - Open left and/or right tank fill valve(s) (J29). - Observe water tank level gauge (P1).
Page 83: Filling The Foam Compound Tank
Filling the Foam Compound Tank FLF 15000/1800/500 Panther 8x8 CA-7 Filling the Foam Compound Tank H108 P2 Filling the foam compound tank with an external foam compound pump - Connect the supply hose (foam compound) to the fill connection (J63) located below the left locker compartment. - Engage the external foam compound pump (please refer to the operation manual of the foam compound pump manufacturer).
Page 84 Filling the Foam Compound Tank FLF 15000/1800/500 Panther 8x8 CA-7 Filling the foam compound tank with the electric foam compound S168 J60 J66 pump - Connect drafting connection (J66) of the foam compound pump to the external foam compound container. - Turn three-way ball valve (J60) to tank fill mode "inside"...
Page 85 Filling the Foam Compound Tank Filling the Foam Compound Tank FLF 15000/1800/500 Panther 8x8 CA-7 Drainage of the foam compound tank / Intertank transfer via the S168 J60 J66 electric foam compound pump - Connect drafting connection (J66) of the foam compound pump to the empty external foam compound container.
Page 86 Filling the Foam Compound Tank FLF 15000/1800/500 Panther 8x8 CA-7 Flushing of the electric foam compound pump S168 J60 J66 - Connect the foam suction hoses to the foam drafting/flushing connection (J66) and put the opposite end into a container with clean water.
Page 87: Light Mast Operation
Light Mast Operation FLF 15000/1800/500 Panther 8x8 CA-7 Light Mast Operation light mast control unit - Place the vehicle at a convenient location: S187d ◊ Apply parking brake. ◊ Ensure that there is free space above the roof (no obstructions). S187u S187p - Engage the light mast control system:...
Page 88: Dry Powder Unit
It is strictly advised to use the installed rapid intervention device for fire fighting only. Any other use is strictly prohibited by Rosenbauer. In cases of misuse, Rosenbauer is not liable for any injury or damage. © 2014 Page - 88 -...
Page 89 Dry Powder Unit FLF 15000/1800/500 Panther 8x8 CA-7 Operation of the dry powder rapid intervention system - Stop the vehicle and apply parking brake. - Open the compartment door completely. - Operate the dry powder unit according to the manufacturer's operation manual.
Page 90: Compressed Air Supply
Pneumatic Installation FLF 15000/1800/500 Panther 8x8 CA-7 Compressed Air Supply In the pump installation, a shut-off-valve (J163) and a pneumatic service unit (Y163) for the pneumatic system are installed. For further information, please refer to the "Service Procedures" maintenance chapter. The shut-off-valve (J163) disconnects the fire fighting pneumatic system from the chassis.
Page 91 Pneumatic Installation FLF 15000/1800/500 Panther 8x8 CA-7 pneumatic solenoids Emergency control of electro pneumatic solenoids Y264 Y283 The pneumatic solenoids are mounted in one group in the pump compartment. Sequence of description from right to left: solenoid for pump drainage solenoid for priming pump solenoid for water drafting valve solenoid for water tank suction valve...
Page 92: Emergency Control Of Pneumatic Actuators
Pneumatic Installation FLF 15000/1800/500 Panther 8x8 CA-7 Emergency Control of Pneumatic Actuators In case compressed air is not available, or a solenoid fails the pneumatic actuators can be operated manually to open or close the valve concerned. Procedure: - Close shut-off-valve (J163). ◊...
Page 93 Pneumatic Installation FLF 15000/1800/500 Panther 8x8 CA-7 Emergency operation of a single pneumatic actuator Z126 Close valve (J168/3) and operate the roof turret valve drive (Z126) by using the emergency tool. Close valve (J168/5) and operate the left regulated discharge valve drive (Z10l) by using the emergency tool.
Page 94: Emergency Adjustment Of The Foam Proportioning Rate
Pneumatic Installation FLF 15000/1800/500 Panther 8x8 CA-7 Emergency Adjustment of the Foam Proportioning Rate If an electric foam proportioning adjustment motor will not open/ control the foam proportioning valve, it can be disconnected and the valve concerned can be controlled manually. Procedure: - Remove bolt (Z78) on top end of defective adjustment motor.
Page 95: Flushing After Foam Operation
Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Flushing after Foam Operation ATTENTION ! To ensure the pump operates without malfunctions, it is important to flush the pump, priming pump, pipes and foam proportioner. Flushing with the internal flushing line - automatic flushing procedure Whenever the pump is operated with clean water as mentioned in the ◊...
Page 96 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Flushing after foam operation ATTENTION ! To ensure the pump operates without malfunctions, it is important to flush the pump, priming pump, pipes and foam proportioner. Flushing with the foam compound drafting/flushing connection - Connect the foam suction hose to the foam drafting/flushing connection (J47) and put the opposite end into a container with clean water.
Page 97: Drainage Of The Pump System / Operation In Cold Climates
Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Drainage of the Pump System / Operation in Cold Climates To protect the fire fighting unit from damage by corrosion and freezing water make sure to drain the entire pump system (espe- cially at temperatures below 0 ° Celsius). - Drain the entire pump system: ◊...
Page 98 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Drainage of the Pump System / Operation in Cold Climates - Remove blind coupling of pressure outlet (J11) or disconnect the pressure hose. ◊ Open the right discharge valve (J10). - Drying the priming pump: ◊...
Page 99: Inspection Procedures
Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Inspection Procedures Inspection procedures may be done by fire brigade personnel familiar with the vehicle and pumping system. These activities must be performed after each operation to ensure optimal reliability of the vehicle. - Check all locks, holding devices and equipment for good condition and safe support.
Page 100 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Inspection procedures - Chassis and superstructure - Check vehicle exterior for dents or damage. - Visually check for missing bolts, loose or damaged hoses and damaged wires. - Inspect wheel hugs, axles, transfer casing, and transmission for signs of lubrication leakage.
Page 101 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Inspection procedures - Chassis and superstructure Wheels and Tyres - Visually inspect each tyre for correct inflation. If the tyre appears to be low in pressure, refer truck to maintenance. Recommended air pressure must be maintained in every tyre. Inflate to correct pressure when tyres are cold.
Page 102 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 The headlights washing agent tank - Inspection procedures - Chassis and superstructure capacity approx. 12 litres - access to the fill cap (87) via maintenance cover In the cabin in the foot-area of the left co-driver. - Observe operation of all gauges.
Page 103: Maintenance Procedures
Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Maintenance Procedures Maintenance procedures may be done by fire brigade personnel familiar with the vehicle and pump system. These activities must be performed after each operation to ensure optimal reliability of the vehicle. - Refill the fuel tank and tanks of fire fighting agents. - If the compartments and driver's cabin require cleaning, do not use a high pressure hose or running water.
Page 104 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Maintenance Procedures - Washing the vehicle At less frequent intervals, after washing and leathering the vehicle thoroughly, apply an approved body polish to impart a brilliant, water-resistant and lasting finish to the paintwork. Never rub the vehicle down with a dry cloth when it is dirty because this causes cracks in the paintwork which progressively destroy it.
Page 105: Service Procedures
Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Service Procedures Service and repair procedures must be done by specialists. These activities must be performed according to manufacturer set intervals. ATTENTION ! Obey all operation and service manuals of chassis, optional equipment and apparatus carried in the vehicle unconditionally. Negligence can cause damage and ultimately, loss of warranty.
Page 106 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Service procedures - Lubrication of pump gearbox Always drain the oil while the housing is warm, as the oil will flow freely and will carry foreign particles with it. For drainage, remove the oil drain plug (82). After reinstalling the drain plug (82), remove the oil level plug (84) and fill with oil.
Page 107 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Service procedures - Lubrication of priming pump All moving parts of the priming pump are oil bath lubricated. The oil has to be changed once a year. Always drain the oil while the priming housing is warm, as the oil will flow freely and will carry foreign particles with it.
Page 108 Interval: yearly Lubricant: grease according DIN 51825-K2K-30 rosenbauer article number: 004824 Note: If maintenance free propeller shafts and intermediate shafts are in use no grease nipples are installed. No further greasing needed. ATTENTION !
Page 109 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Service procedures - Battery Charged batteries lose capacity without a closed circuit. This static-discharge amounts daily to 0.2 - 1% of the capacity, depending on the age of the battery and the temperature. ATTENTION ! Discharged batteries are damaged because they sulphate.
Page 110 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Service procedures - Battery If your vehicle is equipped with a battery charging socket, it is Starting Aid (Jump Starting) possible to charge the batteries by means of a positively polarized plug without dismounting the batteries. ATTENTION ! Precondition: Use only electronically controlled charging units.
Page 111 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Torque list: Service procedures - PP-Water and foam compound tank Screw connections on the PP-tank: Instruction for use - Make sure that the tank is always completely full - avoid driving Maximum permissible torque of the bronze thread inserts with a half-full tank.
Page 112 At the same time apply corrosion protection for any replaced or M 10 10.9 58 Nm repaired part. An approved corrosion preventing plastic paint for cast aluminum-bracket to sub frame this purpose, may be obtained from Rosenbauer International 24 Nm Aktiengesellschaft. silent bloc to cast aluminum-bracket Propeller shaft: 10.9...
Page 113 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Service procedures - Mounting devices for body, water- and foam compound tank - sub frame / chassis The sub frame is fixed to the chassis but bolted flexibly in some areas by means of spring loaded elements. The original pre-adjusted flexible element, see reading (x) must not be changed or bolted to "block"...
Page 114 Maintenance FLF 15000/1800/500 Panther 8x8 CA-7 Service procedures - Maintenance chart OIL CHANGE GREASE- ITEM COMPONENT LUBRICANT VOLUME HOURS/TERM INTERVALL CHECK Pump gearbox Gearboxoil SAE 90 7.2 ltr. 50-100 every two years Priming pump Engine oil SAE 30 1.0 ltr. 25-50 Valve plates V-belt...
Page 115: Problems And Their Solutions
- Engine does not perform Check engine - Discharge valves not fully opened Open discharge valve ATTENTION ! If any assistance is necessary do not hesitate to call your nearest "Rosenbauer" representative or contact the "Rosenbauer" Service Department. © 2014 Page - 115 -...
Page 116: Repetitive Test Cycle For Electrical Components
Repetitive Test Cycle FLF 15000/1800/500 Panther 8x8 CA-7 Repetitive Test Cycle for Electrical Components Repetitive tests are only to be carried out by certified electricians. These tests are to be carried out according to the specifications listed in the component test manual. Electrical systems (230 volts / 400 volts) are to be tested regularly.
Page 117: Hints For Disposal
Environmental Protection FLF 15000/1800/500 Panther 8x8 CA-7 Hints for Disposal For all used parts and materials resulting from repairs and operating this unit, we request for non-polluting disposal. Oil: Please obey current disposal regulations. Foam compound: Obey Safety Data Sheet according to DIN 52900, ÖNORM Z1008. Sacrificial anodes: Disposal at nonferrous metal.
