- Page 1 Carrera Crosscity-E Rear Motor Drive System Owner’s Manual...
-
Page 2: Table Of Contents
Contents Safety information ................. 2 Riding the E-Bike ................5 Product characteristics ............... 6 Product specification ..............6 Display .................... 7 Battery ..................... 7 Battery charger ................8 Charging the battery ..............9 Fitting the battery ........................11 Removing the battery ......................11 Assistance levels and speed .......... -
Page 3: Safety Information
Safety information WARNING There is an increased risk of injury – even fatal – if you do not follow instructions. WARNING There is a risk of serious injury – even fatal – if you do not follow instructions. Managing the battery How safe maintenance is ensured ... - Page 4 Managing the battery WARNING Do not subject the battery or the charger to physical shocks, e.g., by dropping. There is a danger of personal injury or property damage Fluid that leaks from the battery pack may cause skin irritation or burns. In the event of accidental contact, rinse with water.
- Page 5 WARNING Please ensure that all carrier screws are fastened before riding； Please note that the maximum load on the carrier is 25 kg, cargo weight must not exceed 25 kg； Please do not replace or modify the carrier；...
-
Page 6: Riding The E-Bike
Riding the E-Bike Note: If the battery is not used for 24 hours or longer, it will automatically go into sleep mode. Press the power button on the battery for three seconds Press 2 sec. The handlebar display goes through a self-check routine, where all LEDs flash. -
Page 7: Product Characteristics
Product characteristics Battery Display Motor Product specification Operating temperature range during discharge -20°C to 60°C Operating temperature range during charge 0°C to 45°C Storage temperature (battery) -20°C to 45°C Humidity (storage) up to 80% Charging voltage 100V to 240VAC Charging time approx. -
Page 8: Display
Display ASSIST MODE BUTTON HIGH POWER ON/ OFF (press & hold for 2 seconds) BATTERY STATUS For WALK assistance press and hold the button Assistance will stop as soon as you release the button Battery level display and on/off ‘Power’ button Battery Battery release key Charging port... -
Page 9: Battery Charger
If the E-Bike not in use, remove the battery and store it at a temperature between 0°C and 40°C in a dry environment. Do not store the battery with low capacity for a longer period. For storage, the battery should have a capacity of at least 40%. ... -
Page 10: Charging The Battery
Charging the battery The charger LED changes from red to green when the battery is fully charged WARNING Do not subject the battery or the charger to physical shocks, e.g., by dropping. Rinse in the event of accidental contact with water. If fluid gets in your eyes, seek medical advice. - Page 11 Battery power remaining indication Press the ‘Power’ button for 2 seconds; the LED will indicate the amount of charge remaining in the battery Remaining total capacity < 20% >20% & <40% >40% & <60% >80%...
-
Page 12: Fitting The Battery
Fitting the battery 1. Push the battery into the end of the frame with the charging port on the left side 2. Turn the key 180° Removing the battery Unlock with the key & slide out the battery... -
Page 13: Assistance Levels And Speed
Assistance levels and speed 15.5 12.5 Miles per hour Range Factors which affect the range The above figures are based on a speed of 20 km/h on a level road at 15°C–20°C. The range is influenced by many factors: Type, condition and air ... - Page 14 Battery contact protection When the Crosscity-e is folded there are two bladed battery contacts exposed at the front of the rear section of the main frame tube. Stored inside central frame folding catch plastic battery contact protector. When the bike is folded always slide this protector over the two bladed contacts.
-
Page 15: Removing The Rear Wheel (To Repair A Puncture)
Removing the rear wheel (to repair a puncture) Unplug the two parts of the cable connector. You will need to ‘wiggle’ these parts to overcome the grip of the waterproof seal of this connector. Release the two ‘arms’ of the rear V brake by pulling on the rear brake cable ‘noodle’... -
Page 16: Ec Declaration Of Conformity
Having repaired puncture, refit the rear wheel. Take care to ensure the motor cable is pointing directly downwards to align the anti-rotation toothed washers on the wheel axle with the dropout slots. Firmly tighten both wheel nuts to 40 +/-5 Nm ... - Page 17 A copy of the Technical file for this equipment is available from:- the EU address above. Description of Equipment Battle E-Bike Halfords Carrera Crosscity 250 W Rear Motor Drive System, 8.7Ah Li-Ion Battery & Battery Charger The following harmonized standards have been used:- EN 15194:2009 + A1:2011 Cycles –...
-
Page 18: Halfords E-Bike Specific Warranty Conditions
Halfords e-bike specific warranty conditions Your Carrera Crosscity e-bike is guaranteed against manufacturing defects arising from faulty workmanship or materials for 2 years from the original date of sale. Providing that the cycle: Has been properly cared for, regularly serviced and maintained. - Page 19 Please recycle your spent batteries. Batteries should not be disposed of in unsorted municipal waste, but separately collected to facilitate the correct treatment and recycling of the substances they contain. The recycling of batteries ensures the recovery of these valuable materials and prevents any potentially harmful effects upon both the environment and human health.
Need help?
Do you have a question about the Crosscity-E and is the answer not in the manual?
Questions and answers
Seems like a silly question, but should the battery be on or off when charging?
The battery should be switched on when charging the Carrera Crosscity-E.
This answer is automatically generated
Bike is less than 2 years old and now sensors have failed for the third time. Am I missing something.
Common reasons for sensor failure on a Carrera Crosscity-E bike include:
1. Bad or loose connections in the wiring, especially where cables pass into the rear wheel spindle and hub.
2. Chafed or damaged cables that may cause intermittent signal loss.
3. A faulty controller, which may overheat or fail to send proper signals to the motor.
4. Moisture or water exposure despite the bike being designed as waterproof.
5. Use of non-genuine parts or improper handling, such as connecting components with wet hands or using metal objects near terminals.
This answer is automatically generated
gears not changing, chain on bottom for
If the gears are not changing on a Carrera Crosscity-E bicycle and the chain is on the bottom, a possible cause could be improper use of gears or mechanical issues such as misalignment, cable tension problems, or derailleur malfunction. The context emphasizes the need to use gears properly, especially when approaching hills, and warns against riding in high gear at low cadence. This suggests that incorrect gear use or excessive strain on the drivetrain could contribute to gear shifting issues.
This answer is automatically generated
Is the battery 2 or 3 pin
The Carrera Crosscity E-Bike uses a 2-pin battery, as indicated by the compatibility details of the Carrera Crosscity E-Bike Charger (2Pin Battery).
This answer is automatically generated
We collected from Halfords 2 new carrera crosscity folding ebike batteries today 06.8.25. Checked with multimeter when home, one was 25.3v second one was 25.9v. Tried to fully charge them as required.Charger turned green after only 2.5 hrs and 2hrs 1st one went to 32.8v second one to 34.9v. What is happening please.
Do I switch on carrera crosscity folding ebike battery for charging please
How do I discharge the battery if i am unable to ride the bike
is the headset bearing replaceble or adjustable. ours seems to be very worn and is loose
I need a replacement key F359. Although the 5 lights are red the assisted power is not working. I may need a new battery even though the bike hasn't been used that much
