Summary of Contents for Magic Control Technology IPE605-TX
- Page 1 HDMI V IP E IDEO ALL OVER XTENDER USER MANUAL IPE605-TX IPE605-RX IPE605 Rev. 02 June. 14 2019...
-
Page 2: Table Of Contents
ABLE OF CONTENTS ! ..................................3 ELCOME 1.1.............................. 3 ACKAGE ONTENTS 1.2................................4 EATURES 1.3..............................5 PECIFICATIONS 1.4............................7 ARDWARE EATURES ..............................8 ONNECT ERIPHERALS 2.1............................. 8 ARDWARE NSTALLATION 2.1.1..............................8 OINT OINT 2.1.2............................. -
Page 3: Welcome
Shopping center and Conference center. 1.1. ACKAGE ONTENTS IPE605-TX HDMI Video Wall over IP Extender Transmitter x 1 IPE605-RX HDMI Video Wall over IP Extender Receiver x 1 5V/2A Universal Power Adapter x 2 1-meter HDMI Cable x 1 (Optional) ... -
Page 4: Features
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 1.2. EATURES Extend high definition video signal over ethernet(100Mbps/1Gbps) Point to point up to 330feet (100 meters) over cat5e/cat6 Ethernet cable, supports Ethernet topology (must support IGMP snooping). Specifically designed a 10 positions rotary switch for 10 Tx-Rx pairing ... -
Page 5: Specifications
IP E IDEO ALL OVER XTENDER ANUAL 1.3. PECIFICATIONS Technical Model Name IPE605 Transmitter (Tx) IPE605-TX Receiver (Rx) IPE605-RX HDMI Compliance HDMI v1.3 HDCP Compliance HDCP 1.2 Video Impedance 100 Ω HDMI Audio Formats Stereo digital audio Input Resolution Range:... - Page 6 HDMI V IP E IDEO ALL OVER XTENDER ANUAL Mechanical Enclosure type Aluminum Enclosure Color Black Enclosure Dimensions 87.20 x 88.00 x 27.00 mm (W x D x H) Enclosure Dimensions with 112.00 x 88.00 x27.00 mm bracket (W x D x H) Product Weight 120g Product Weight with bracket...
-
Page 7: Ardware Eatures
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 1.4. ARDWARE EATURES IPE605-TX Front View Rear View Reset ① HDMI Input Port with Lock ② Upper amber LED: Product Status indicator ③ Bottom green LED: Power ON indicator ④... -
Page 8: Connect Peripherals
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 2. C ONNECT ERIPHERALS 2.1. ARDWARE NSTALLATION 2.1.1. OINT OINT Direct connect from Transmitter IPE605-TX to Receiver IPE-605RX unit. Transmitter IPE-605TX unit to network switch to Receiver IPE-605RX unit. -
Page 9: Point - To - Multipoint
XTENDER ANUAL 2.1.2. OINT MULTIPOINT Transmitter IPE605-TX unit to Gigabit Ethernet hub (must support IGMP snooping) to many Receiver IPE605-RX units. Transmitter IPE605-TX unit to network topology (must support IGMP snooping) to many Receiver IPE605-RX units. Notes: Your Gigabit Ethernet hub must support IGMP snooping. Refer to your gigabit ethernet hub... -
Page 10: Multipoint - To -Multipoint
XTENDER ANUAL 2.1.3. ULTIPOINT ULTIPOINT Many Transmitter IPE605-TX units to Gigabit Ethernet hub (must support IGMP snooping) to many Receiver IPE605-RX units Many Transmitter IPE605-TX units to network topology (must support IGMP snooping) to many Receiver IPE605-RX units. Notes: Your Gigabit Ethernet hub must support IGMP snooping. Refer to your gigabit ethernet hub... -
Page 11: Assembly Diagram
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 2.2. SSEMBLY DIAGRAM CAUTION! Use only the bundled power adapter. Using other power adapters may damage your device. MPORTANT! Use the correct adapter plug for your area/region. The adapter is for dry and indoor used only. -
Page 12: Easily Build A Matrix Display
3.1. No any software need. 3.2. Use the HDMI cable to connect the HDMI Input port on the IPE605-TX, then put the other end to connect the HDMI Output port on your video source device. 3.3. Use the HDMI cable to connect the HDMI Output port on the IPE605-RX, then put the other end to connect the HDMI Input port on your video display device. -
Page 13: Easily Build A Matrix Display For Example
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 4. E ASILY BUILD A MATRIX DISPLAY FOR EXAMPLE ① How to set up the 2x2 video wall ② How to deploy the 2x2 video wall ④ Select the RX Display ID ③... -
Page 14: Introduction Management Ui
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 5. I NTRODUCTION ANAGEMENT The management UI includes four pages as below: Device page: Display fully detailed information of Receivers and Transmitters Walls page: The management UI provides three video wall types for easy creation of video walls. ... -
Page 15: Advance Set Up Hdmi V Ideo Wall Over Ip Extender - Management Ui
Connecting the IPE605-TX and IPE605-RX device LAN port via Cat5e/6 ethernet cable to the same local area network environment through a Router and/or Gigabit Ethernet hub. Ensure your computer that the management UI has been installed on is connected to the same local area network. - Page 16 HDMI V IP E IDEO ALL OVER XTENDER ANUAL Dwnload the management UI from the website and will see an icon “MctHoIP.exe” in the folder of the Management UI. Once Launched, the “MctHoIP.exe” to set the variety of functions associated to the HDMI over Gigabit Ethernet Management.
-
Page 17: Management Ui - Device Page
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 7. M UI - D ANAGEMENT EVICE The page will display fully detailed Device name, MAC address, Device ID and State of all Receivers and Transmitters. You could click the Edit icon to edit Device name when select a Receiver or Transmitter device. - Page 18 HDMI V IP E IDEO ALL OVER XTENDER ANUAL On the selected Receiver or Transmitter, click the right mouse button and “Device setting” menu will pop up. There are some features “Reboot”, “Reset to default”, “Audio On/Off”, “Show ID” and “Upgrade firmware”...
- Page 19 HDMI V IP E IDEO ALL OVER XTENDER ANUAL “Reboot”: the selected device will reboot. “Reset to default”: the selected device will restore to the default factory setting. “Audio On/Off”: set the selected device HDMI digital audio output ON or OFF, the default setting for HDMI digital audio output is “ON”.
-
Page 20: Management Ui - Walls Page
HDMI V IP E IDEO ALL OVER XTENDER ANUAL UI – W 8. M ANAGEMENT ALLS The Management UI provides three video wall types for easy creation of video walls. “Create new video wall” for easy matrix setup 1x1, 1x4, 2x2, 3x3 … … 5x5 video wall “Create mirror wall”... -
Page 21: Create New Video Wall
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 8.1. REATE NEW IDEO Select “Create new wall “ in “Walls” page for easy matrix setup 1x1, 1x4, 2x2, 3x3 … … 5x5 video wall. Please follow the steps to create a new video wall 1. - Page 22 HDMI V IP E IDEO ALL OVER XTENDER ANUAL Click “Show all receivers ID” you can easily identify the display is connected to which receiver.
- Page 23 HDMI V IP E IDEO ALL OVER XTENDER ANUAL ET THE POSITION OF EVERY ISPLAY Click “Show all receivers ID”, every display screen will show receivers ID. You could refer receivers ID to drag the receiver devices from the list and drop to corresponds with the proper location within your video wall configuration.
- Page 24 HDMI V IP E IDEO ALL OVER XTENDER ANUAL EZEL CORRECTION If the displays in your video wall configuration have large bezels, seamless look by specifying the bezel compensation. The bezel correction can compensate for this effect by cutting out the video “behind” the bezel, causing a round object to actually appear round.
- Page 25 HDMI V IP E IDEO ALL OVER XTENDER ANUAL “Save”. The create video wall configuration “Wall0 3x4” will be listed in “Management” page. You can select or switch your video source (Transmitter) for each created video wall configuration. You can drag the Transmitters from the listed and drop to each created video walls configuration.
-
Page 26: Create All Mirror Wall
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 8.2. REATE ALL MIRROR WALL Select “Create mirror wall “ in “Walls” page for quickly set up many remote receivers while receiving a single transmitter source video. Please follow the steps to create a new mirror wall 1. - Page 27 HDMI V IP E IDEO ALL OVER XTENDER ANUAL “Save” your wall. The create video wall configuration “Wall5 Mirror” will be listed in “Management” page. You can select or switch your video source (Transmitter) for each created video wall configuration. You can drag the Transmitters from the listed and drop to each created video walls configuration.
- Page 28 HDMI V IP E IDEO ALL OVER XTENDER ANUAL All of remote receivers while receiving a single transmitter source video...
-
Page 29: Create Customize Video Wall
HDMI V IP E IDEO ALL OVER XTENDER ANUAL 8.3. REATE CUSTOMIZE IDEO Select “Create customize wall” in “Walls” page for quickly set up a customized video wall, you can use same size or different size of monitor to create a video wall and put the monitor on the video wall any position for artistic video wall. - Page 30 HDMI V IP E IDEO ALL OVER XTENDER ANUAL ILL IN THE VALUES ACCORDING TO THE ACTUAL WIDTH AND HEIGHT OF THE WALL Customize video wall size, enter the following measurements in millimeters (mm) didn’t including monitor bezel. Please fill in the values according to the actual width (mm) and height (mm) of the video wall, then click “OK”...
- Page 31 HDMI V IP E IDEO ALL OVER XTENDER ANUAL ET THE POSITION OF EVERY ISPLAY Click “Show all receivers ID”, every display screen will show receivers ID. Y You could refer receivers ID to drag the receiver devices from the list and drop to corresponds with the proper location within your video wall configuration.
- Page 32 HDMI V IP E IDEO ALL OVER XTENDER ANUAL Please click “Save” to create a customize video wall. The created video wall configuration “wall4 Customize” will be listed in “Management” page. You can select or switch your video source (Transmitter) for each created video wall configuration. You can drag the Transmitters from the listed and drop to each created video walls configuration.
-
Page 33: Management Ui - Management Page
HDMI V IP E IDEO ALL OVER XTENDER ANUAL UI – M 9. M ANAGEMENT ANAGEMENT You can select or switch your video source (Transmitter) for each created video wall configuration. You can drag the Transmitters from the listed and drop to each created video walls configuration. - Page 34 HDMI V IP E IDEO ALL OVER XTENDER ANUAL Adjust or edit video walls configuration: You can adjust or edit for each video walls configuration by double click each video walls configuration. Delete a video wall configuration: You can delete a video wall configuration by clicking select a video wall next press “Delete Selected wall”...
-
Page 35: About Page
HDMI V IP E IDEO ALL OVER XTENDER ANUAL BOUT To check the current driver version.
