T20 is a multitask FRS transceiver. Combining the latest technology in radio communication along with a sturdy mechanical
frame, T20 is the ideal and effective solution for the professionals who need to stay in touch with the working team (in
construction sites, buildings, shows, trade fairs or hotels) or for leisure users that just want to keep up with friends and
family.
To help you ward off bodily injury or property loss that may arise from improper operation, please read all the information
carefully before using our products.
RF EXPOSURE
WARNING!
It is up to the user to properly operate this radio transmitter to insure safe operation. Please adhere to the
following:
Do not use the radio with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may
result.
Please contact your local dealer for a replacement antenna.
Device operation up to maximum duty cycle 50% and compliance with the public environment RF Exposure.
This EUT is compliance with SAR for general/uncontrolled exposure limits in IC RSS-102 at operating duty factors of up to
50% and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528 and IEC
62209. This equipment should be installed and operated with a minimum distance of 2.5 cm must be maintained when
held-to-face, and body-worn operations are restricted to the approved original accessories (belt clip), a minimum distance of
0 cm.
Cet EUT est conforme au SAR pour les limites d'exposition contrôlées dans IC RSS-102 à des facteurs de service allant jusqu'à
50% et a été testé conformément aux méthodes et procédures de mesure spécifiées dans IEEE 1528 et IEC 62209. Cet
équipement doit être installé et utilisé avec une distance minimale de 2,5 cm doit être maintenu lorsqu'il est tenu face à face,
ATTENTION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PO Fung Electronic T20

  • Page 1 T20 is a multitask FRS transceiver. Combining the latest technology in radio communication along with a sturdy mechanical frame, T20 is the ideal and effective solution for the professionals who need to stay in touch with the working team (in construction sites, buildings, shows, trade fairs or hotels) or for leisure users that just want to keep up with friends and family.
  • Page 2: Fcc Part 15

    et les opérations portées sur le corps sont limitées aux accessoires d'origine approuvés (clip de ceinture), une distance minimale de 0 cm. ■ Hand-Held Operation (Held-to-Face) This device was evaluated for typical hand-held (held-to-face) operations with a 1 inch spacing from the front of the radio. For hand-held operation, the radio should be held 1 inch from the user's face in order to comply with FCC RF exposure requirements.
  • Page 3: Precautions For Batteries

    not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Avis de conformité...
  • Page 4: Maintenance Instructions

    To protect you against any property loss, bodily injury or even death, be sure to observe the following safety instructions: 1. Do not charge or replace your battery in a location containing fuels, chemicals, explosive atmospheres and other flammable or explosive materials. 2.
  • Page 5: Maintenance

    • Never change or replace anything in your radio except the batteries. ■ Care and Safety Your T20 was designed to fulfill any warranty obligations and to enjoy this product for many years. As for all the electronically devices, we recommend you to follow this few suggestions: •...
  • Page 6: Programming Software (Optional)

    Never allow children to operate the radio without adult supervision and the knowledge of the following guidelines. Programming software (optional) Thanks to Programming software CPS-T20-FRS, it is possible to increase the performance of your radio or to reduce its functionality by disabling some of the default features (CTCSS, DCS, TOT, VOX...) For further information, please consult the Programming software manual.
  • Page 7: Main Features

    • 1 T20 transceiver • 1 Belt clip • 1 1500mAh Li-ion rechargeable battery pack • 1 USB cable • 1 User manual • 1 Wrist-strap Note: The number of the above materials may be depending on the number of packages.
  • Page 8 BATTERY RECHAGRE T20 is equipped for using a 3,7V Li-ion rechargeable battery pack which can be recharged by connecting the USB cable to the radio and to a USB-charger (5V-1A). It takes 5 hours to fully recharge the radio. For maximum battery life, we recommend charging the battery pack when the T20 is off and the battery pack is fully discharged.
  • Page 9: Getting Acquainted

    GETTING ACQUAINTED NOTE: Long press [Channel down] key to enter the monitoring state.
  • Page 10: Power On/Off And Volume Adjustment

    With T20 turned on, long press the LAMP key to lock or unlock the channel selection function. After the channel selection function is locked, channel switching will be prohibited, and pressing the Channel Up (+)/ Down(-) keys will cause a prompt tone to prohibit operation.
  • Page 11 The higher is the level, the louder will be the Squelch. By default, the Squelch level of T20 is set on level 4. Make sure you do not set an excessively high squelch level because in this case you may not be able to receive weaker signals.
  • Page 12: On-Line Service And Support

    CTCSS/DCS tones CTCSS and DCS tones are similar to access codes and enable the radio to communicate only with the users that are tuned on the same channel and have set the same code. For each channel, you can set up to 50 CTCSS tones and 210 DCS codes. The CTCSS/DCS tones are a sort of “access codes”...
  • Page 13: Appendix A. - Technical Specifications

    Appendix A. – Technical Specifications General Part Frequency Range Working temperature -10℃ to +40℃ Operation Voltage DC 3.7 V ±10% Operation Mode Simplex Dimensions 136mm×56mm×28mm (with Antenna) Weight 130g (Battery pack included) Antenna Impedance 50ohm Duty cycle 5/5/90% Transmitter Part RF Output Power 2W (1-7&15-22Channels) /0.5W(8-14Channels) FM Modulation...
  • Page 14: Appendix B. - Frs Frequency Chart (Mhz)

    Appendix B. - FRS Frequency Chart (MHz) Power Power CH.No CH.Freq. CH.No CH.Freq. Output Output 462.5625 High 467.6625 462.5875 High 467.6875 462.6125 High 467.7125 462.6375 High 462.5500 High 462.6625 High 462.5750 High 462.6875 High 462.6000 High 462.7125 High 462.6250 High 467.5625 462.6500 High...
  • Page 15: Appendix C. - Trouble Shooting Guide

    Appendix C. – Trouble shooting guide Phenomena Analysis Solution The battery may be installed improperly. Remove and reattach the battery. The battery power may run out. Recharge or replace the battery. You cannot turn on the radio. The battery may suffer from poor contact caused by Clean the battery contacts or replace the dirty or damaged battery contacts.
  • Page 16 No copy, modification, translation and dissemination of this handbook may be made in any form without the prior written authorization of our department. PO FUNG ELECTRONIC (HK) INTERNATIOANL GROUP COMPANY Address: 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong E-mail: sales@pofungshop.com...
