- Page 1 INSTALLATION GUIDE WALL MOUNT BRACKET FOR AES BATTERY: 42-48-6650, 12-48-6650, 12-36-6700 1. Safety 1.1 Warnings, Cautions, Notes and Symbols 2. Installation 2.1 Tools and Hardware 2.2 Wall Mount Overview 2.3 Installing the Bracket 2.4 Mounting the Battery to the Bracket 885-0016 REV A discoverbattery.com...
- Page 2 Analyzing and reducing hazards involved in performing electrical work • Installing and configuring batteries No responsibility is assumed by Discover Battery for any consequences arising out of the use of this material. Read AES Battery Manual and Safety instructions before installing the battery. discoverbattery.com...
- Page 3 1. Safety 1.1 Warnings, Cautions, Notes and Symbols ▲ WARNING Important information regarding possible personal injury. ▲ CAUTION Important information regarding possible equipment damage. ▲ NOTE Additional information concerning important procedures and features of the battery. 2. Installation ▲ WARNING Heavy Equipment The AES battery weights more than 90 kg (200 lbs).
- Page 4 2.2 Wall Mount Overview Each battery requires a seperate bracket. Attach the bracket to the wall before attaching the AES battery to the wall mount. Each bracket requires a minimum of four 1/4 inch diameter lag bolts or other fasteners. Fasteners must be strong enough to support 227 kg (500 lbs).
- Page 5 2.3 Installing the Bracket To install the Bracket: 1. Locate the wall studs. 2. If necessary install a 3/4 inch (minimum) plywood panel or appropriate additional support panel to the wall studs. Use hardware sized to support a minimum of 227 kg (500 lbs) when installing additional support panels to the wall. The additional support must span across at least three wall studs.
- Page 6 2. Lower the AES Battery flange onto the bracket. 3. Secure the top of the AES Battery to the two PEM studs with M8 nuts (included). Torque nuts to 1.4 - 1.5 N-m (12.4 - 13.3 in-lbs). Discover AES Mounting Plate discoverbattery.com...
