LTT SLC-M Series User Manual

Smart laser center
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Laser Tools & Technics Corp.
User
Manual
Version 1.1 e
SLC-M Series
Copyright in this manual is owned by LTT, Inc. 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLC-M Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LTT SLC-M Series

  • Page 1 Laser Tools & Technics Corp. User Manual Version 1.1 e SLC-M Series Copyright in this manual is owned by LTT, Inc. 2008...

  • Page 2: Introduction

    Introduction Technical Support Thank you for purchasing the SLC-M series. This product is warranted to be free of manufacturing defects for one year from the date of purchase. Our technical support group is glad to work with you in answering your questions. If you cannot find the...

  • Page 3: Table Of Contents

    2.5.2 Uninstall Driver ......................30 2.5.3 Change USB Cable to Another Port ..............32 2.6 CorelDRAW Setup ....................... 34 2.7 AutoCad Setup ........................36 2.8 LTT Product Tools ........................ 44 2.8.1 Install Procedure ..................... 44 2.8.2 Uninstall Procedure ....................48 2.9 AutoCCD ..........................49 2.9.1 Install Procedure .....................
  • Page 4 3.5.2 Ethernet Settings Upgrade ................. 78 3.6 Basic Operation Flow with CCD ..................79 3.7 AutoCCD ..........................80 3.7.1 Controls ......................... 80 3.7.1.1 Find the CCD IP address ..................81 3.7.2 AutoCCD Monitor ....................... 82 3.7.3 Task Control ......................... 83 3.7.3.1 Drawing File ......................

  • Page 5: Chapter 1 Safety

    Wavelength : 9.3~10.6μm Maximum output power : 30 ~ 100W Visibility : Invisible When operating the SLC-M series, be sure to always comply with the safety regulations as following: Do not attempt to modify or disassemble any component of the machine without ...
  • Page 6 Chapter 1 Safety Do not watch the laser beam directly during operation. Bright light caused by  the lasing process can damage the eye. The side and rear doors are fixed by screws for safety. If you open these doors, ...

  • Page 7: Name Plate And Warning Labels

    Chapter 1 Safety 1.2 Name Plate and Warning Labels The labels as following are affixed to the SLC-M. These labels must never be removed. If they are damaged or tampered for any reason, please request for LTT immediately to replace them.
  • Page 8 Chapter 1 Safety L a s e r To o l s & Te ch n i c s C o r p o r at i o n Model No: SLC-M-C60M Serial No: 9810000 Specification: V60, 220~240V, 15A Manufacture Date: 2008 .12 N o .
  • Page 9 Chapter 1 Safety...

  • Page 10: Safety Protection Device

    Chapter 1 Safety 1.3 Safety Protection Device Interlock  The laser beam will not be emitted if you open the front door. The LED indicator of “DOOR” on control panel will be off. Front door close Front door opens Laser Switch ...
  • Page 11 Chapter 1 Safety Emergency Stop Switch  Pressing the red pushbutton can shut down the main power of system immediately when emergency condition occurs. And turning right the red pushbutton can recover the power (Before recovering power, please clear the trouble in the machine first). ...

  • Page 12: Chapter 2 Installation

    Chapter 2 Installation Chapter 2 Installation 2.1 Unpack and Locate Machine This section explains how to unpack and locate machine. 1. Locate the machine and keep the recommended space for maintenance. 2. Lock the wheels to locate the machine.

  • Page 13: Package Contents List

    Chapter 2 Installation 2.2 Package Contents List This section explains the package contents of the SLC. The package includes the following components. Before using the unit, check that all components have been included in the package. LaserCAM Driver CD-Rom Cotton Swab USB Cable Driver CD-Rom Alcohol Dropper USB Cable...

  • Page 14: Part Names And Functions

    Chapter 2 Installation 2. RS232 to USB transformer 3. RJ45 cable 2.3 Part Names and Functions This section explains the main part names and functions of the SLC-M. 1. Front Door...
  • Page 15 Chapter 2 Installation This door has interlock sensors for safety. If you open this door, the laser will be not emitted. 2. Front Door of chassis Mostly opening this door is for maintaining. Do NOT open this door if it’s not necessary, especially the machine power is on.
  • Page 16 Chapter 2 Installation Mostly opening this door is for maintaining. Do NOT open this door if it’s not necessary, especially the machine power is on. 9. Window Lens This part can protect 1 mirror against dusts or debris. It should be cleaned this lens daily.
  • Page 17 Chapter 2 Installation 13. 5 Mirror This part reflect laser beam to focal lens. Also, it should be cleaned daily. (See chapter 14. Focal Lens This part can focus the laser beam on materials for cutiing. Also, it should be cleaned this lens daily.
  • Page 18 Chapter 2 Installation 19. Emergency Stop Please see section 20. Power Switch This switch can turn on/off the main power of this machine.   21. Laser Switch Please see section 22. LCD Display LCD display shows the operating menu and information from system. If you want to obtain more detail about operating menu, please see section 3.2.2.
  • Page 19 Chapter 2 Installation 24. Electromagnetic Valve Port This part is used for part electromagnetic valve. 25. Air Inlet Port This part is the total air inlet for this machine. 26. USB Port This part can send files from computer to machine through a USB cable. 27.

  • Page 20: Hardware Installation

    Chapter 2 Installation 2.4 Hardware Installation This section explains the installation steps with other hardware. 1. Check environment Power supply  Power supply : 220 VAC Environment  Temperature: 0 ~ 30 ℃, No freezing Relative humidity : 35 ~ 85 % Other : Avoid to dust, dirt, oil, mist, strong vibration, or sudden temperature changes 2.
  • Page 21 Chapter 2 Installation 4. Connect pipes from exhaust port to blower 5. Connect hose from air filter to compressor 6. Connect RS232 cable from PC to machine...
  • Page 22 Chapter 2 Installation 7. Connect RJ45 cable from PC to machine (There is another connection wa You can connect PC to local network area, and connect machine to the sam network area)

  • Page 23: Driver Installation

    Chapter 2 Installation 2.5 Driver Installation 2.5.1 Install Driver This section explains the installation steps for driver on computer. 1. Check computer equipment A High speed computer will calculate image file quicker and take less time to send files to machine. Minimum Recommended ...
  • Page 24 Chapter 2 Installation 4. Click the [Next] button 5. Select [Local printer attached to this computer], uncheck [Automatically detect and install my Plug and Play printer], then click the [Next] button...
  • Page 25 Chapter 2 Installation 6. Select [Use the following port] and [USB00*], click the [Next] button. (The * is depended on the USB port that is connected with SLC-M) 7. Click [Have Disk...]...
  • Page 26 Chapter 2 Installation 8. Click [Browse…] button 9. Select the inf file Browse to the location of inf file. If it is on a CD-ROM, please browse to the CD-ROM. Select the *.inf file which matches with your machine type. 10.
  • Page 27 Chapter 2 Installation 11. Click [Next] button If the [Use Existing Driver] box shows, select [Replace existing driver] and click [Next] button.
  • Page 28 Chapter 2 Installation 12. Click [Next] button If you want this machine to be the default printer, then please select [Yes], or please select [No]. If there are no other drivers installed on your computer, the SLC-M will automatically be set as your default printer. 13.
  • Page 29 Chapter 2 Installation 14. Select [No], and click [Next] 15. Click [Finish] button...
  • Page 30 Chapter 2 Installation When the [Hardware Installation] box shows, please click [Continue Anyway]. Then your new driver installation is complete. 16. Close [Printers and Faxes] window If your driver is now listed on the [Printers and Faxes] window, the installation was successful.

  • Page 31: Uninstall Driver

    Chapter 2 Installation 2.5.2 Uninstall Driver Go to the [Printers and Faxes] window Select the Printer you want to delete and then press the [Delete this Printer] button. Press the [Yes] button and reboot computer. Press right key of mouse on the [Printers and Faxes] window.
  • Page 32 Chapter 2 Installation Switch to [Drivers] tab and choose the Printer you have just deleted. Press [Remove] button. Press [Yes] button. Press [Close] button. Close the [Printers and Faxes] window.

  • Page 33: Change Usb Cable To Another Port

    Chapter 2 Installation 2.5.3 Change USB Cable to Another Port This section explains that the steps when change USB port. Once you contact the USB Cable to computer, we strongly suggest that do not change it to another USB port. If you must change USB cable to another port, you have to also change the printer settings of SLC-M.
  • Page 34 Chapter 2 Installation Switch to [Ports] label. Switch the [USB00*] which is belong to the new port and click [OK]. Done.

  • Page 35: Coreldraw Setup

    Chapter 2 Installation 2.6 CorelDRAW Setup It is strongly recommended to keep the graphic software’s page size the same with driver’s page size before you begin editing files. Here you will learn how to setup your page and learn how to keep those settings that you don’t have to setup again next time.
  • Page 36 Chapter 2 Installation Click [OK] to complete the paper size adjustment. Next time you can select template style while you create new file.

  • Page 37: Autocad Setup

    Chapter 2 Installation 2.7 AutoCad Setup Here you will learn how to setup the page and print setting on AutoCAD. 1. Page And Layout Setup Open the AutoCAD. Type [limits] on the command line then press [Enter] key. Then press [Enter] key to set the bottom left corner to [0,0]. Setting the top right corner according to work area (See Appendix 1).
  • Page 38 Chapter 2 Installation Choose [File] → [Save as]. Then select [Files of type] as [*.dwt]. Set file name as machine type and then press [Save] button to save the Template style. Write down some description for the template and set the measurement unit system you want.
  • Page 39 Installation 2. Print Setting Go to [File] → [Plot]. When the [Plot] window shows, select printer driver and click [Properties] button. Select [Modify Standard Paper Sizes] on the tree-list box. Select the option which starts with [LTT…]. Press [Modify] button.
  • Page 40 Chapter 2 Installation Modify [Top], [Down], [Left] and [Right] to zero, press [Next] button to continue. Press [Next] button to continue. Press [Finish] button to continue.
  • Page 41 Chapter 2 Installation Select [Custom Properties] and click [Custom Properties] button at middle. Modify Laser settings if need. Press [OK] to finish driver setting.
  • Page 42 Chapter 2 Installation Press [OK] to back to print setting. Select [Save changes to the following file] and press [OK] to continue.
  • Page 43 Chapter 2 Installation You will find the printer option that you just created (*.pc3) on [Name] box. Please select the new printer instead of original in the future. Select [Plot style table] to acad.ctb. Press [Edit] button. Press [Yes] button to continue.
  • Page 44 Chapter 2 Installation Use [Shift] key to help selecting all colors in [Plot styles] list. Set the [Linetype] to [solid] and the [Lineweight] to [0.0000 mm] Press [Save & close] button to continue. Please follow the settings below. Switch to [Plot Settings] tab. Select the [Plot scale] to [1:1].

  • Page 45: Ltt Product Tools

    Installation 2.8 LTT Product Tools 2.8.1 Install Procedure LTT Product Tools is the software which can send prn or plt file, update firmware, and change the Ethernet settings. This section explains the installation steps on your computer. Double click [setup.exe], (the file is included in the installation CD)
  • Page 46 Chapter 2 Installation When you see the diagram below, please press the [Accept] key to go on. If not, please go to Step 4. 3. When you see the diagram below, please wait for some minutes. 4. When you see the diagram below, please press the [Next] key to go on.
  • Page 47 Chapter 2 Installation 5. When you see the diagram below, please choose a position to install the software, or use the default value. And press [Next] key to go on.
  • Page 48 Chapter 2 Installation 6. Press [Next] key to go on. 7. Press [Close] key to finish the setup procedure. 8. After the setup procedure, you can open the software from two shortcuts. The first one locates on the [Desktop], and the second one is placed in the [Start Manu].

  • Page 49: Uninstall Procedure

    Chapter 2 Installation 2.8.2 Uninstall Procedure 1. Click [Start] [Settings]  [Control Panel] Double click [Add or Remove Programs] 3. Click [LTT Product Tools]  Press [Remove] key...

  • Page 50: Autoccd

    Chapter 2 Installation Please choose [Yes] Done 2.9 AutoCCD 2.9.1 Install Procedure AutoCCD is the main control program for cutting with CCD camera. This section explains the installation step 1. Before using AutoCCD, it needs to install the CCD control program – [In-sign explore]. (Please use th version may cause unknown problem.) 2.
  • Page 51 Chapter 2 Installation 6. Click [Install Now] button to go on. 7. When you see the below diagram, click [next].
  • Page 52 Chapter 2 Installation choose [I accept the terms in the license agreement], and click [next] 9. Click [Next] to go on...
  • Page 53 Chapter 2 Installation Click [Next] to go on 11. Click [Install] to go on...

  • Page 54: Uninstall Procedure

    Chapter 2 Installation 12. Waiting for install procedure. When seeing blow window. Click [Finish] to finish install procedure for [In 13. After install the [In-Sight Explorer], copy the file [AutoCCD.EXE] from install CD. You can double th 2.9.2 Uninstall Procedure 1.
  • Page 55 Chapter 2 Installation Double click [Add or Remove Programs] 3. Click [Cognex In-Sight Software 4.1.1]  Press [Remove] key Please choose [Yes]...
  • Page 56 Chapter 2 Installation 5. Delete the file [AutoCCD.EXE]...

  • Page 57: Chapter 3 Operation

    Chapter 3 Operation Chapter 3 Operation 3.1 Operator Position This section shows the position when you operate machine. 3.2 Basic Operation Flow without CCD This section explains the basic and common steps to operate SLC-M. If you want to obtain more detail about operation, please see section and 3.4.

  • Page 58: Machine Operation Without Ccd

    Chapter 3 Operation Open a drawing file or draw a new one on CorelDraw or AutoCAD.  Execute the [Print] or [Plot] function.  Modify the settings of driver. (See section 3.4)  Click [OK] to send file.  3. Adjust focal height (if necessary). Put the material on the table.

  • Page 59: Control Panel

    Chapter 3 Operation 3.3.1 Control Panel Cursor Up / Increase Values 12. Move Carriage Left (X-) Escape 13. Move Carriage Right (X+) Cursor Down / Decrease Values 14. Move Carriage Forward (Y-) Enter 15. Move Carriage Back (Y+) Previous File 16.
  • Page 60 Chapter 3 Operation Escape from sub-menu or sub-selection 3. Cursor Down / Decrease Values Move the cursor down or decrease values. 4. Enter Enter into sub-menu or confirm the selection. 5. Previous Select previous file in file list. 6. Next Select next file in file list.
  • Page 61 Chapter 3 Operation 15. Move Carriage Back (Y+) Move the carriage back slowly when press this key shortly. If you want to move the carriage back faster, please press and hold this key. 16. Homing Move the carriage to home and reset the position of home if the carriage loses its...

  • Page 62: Operating Menu

    Chapter 3 Operation 3.3.2 Operating Menu 1. Work Display ■1. WORK DISPLAY 2. FILE MANAGER 3. LASER PARAMETER 4. SYSTEM SETUP ■1/11* PICTURE-2 COPY 3 Time 0:29 / 0:00 Free 63.15MB dpi 0 1/11* PICTURE-2 ■QTY COPY 3 Time 0:29 / 0:00 Free 63.15MB dpi 0 1 /11*...
  • Page 63 Chapter 3 Operation 2. FILE MANAGER 1. WORK DISPLAY ■2. FILE MANAGER 3. LASER PARAMETER 4. SYSTEM SETUP ■1/11* PICTURE-2 Del. the file 134B Delete all files Net Status 1/11* PICTURE-2 ■Del. the file 134B Delete all files Net Status You Sure? ■Yes 1/11*...
  • Page 64 Chapter 3 Operation 3. Laser Parameter 1. WORK DISPLAY 2. FILE MANAGER ■3. LASER PARAMETER 4. SYSTEM SETUP ■Color setup Color control Laser tickle setup Alignment mode ■Setting Pen 1 Blac Power Speed 100% 1000 Color setup ■Color control Laser tickle setup Alignment mode Color Control by file...
  • Page 65 Alignment Mode  This function is used for alignment of laser. It is recommended NOT to use this function unless instructed to by a LTT technician. Tickle output  Indicates the power for laser tickle. Its range is between 0~100%.
  • Page 66 Chapter 3 Operation 4. System Setup 1. WORK DISPLAY 2. FILE MANAGER 3. LASER PARAMETER ■4. SYSTEM SETUP ■Configuration Position setup Status About SLC-M-C60M ■Rule unit: step Sleep mode: 10 min Auto run: Arc comp: Configuration ■Position setup Status About SLC-M-C60M ■Adjust X-Y axis Focus Length Auto Focusing...
  • Page 67 Chapter 3 Operation Configuration Position setup ■Status About SLC-M-C60M ■X loc. 600.000mm Y loc. 500.000mm Z loc. 0.000mm data is OK! Configuration Position setup Status ■About SLC-M-C60M Laser Tools & Technics Corp. SN:9810000 2008/12/5 Ver 8.08 Configuration  Rule unit ...
  • Page 68 Chapter 3 Operation Status  This function can show the position of carriage and table. About SLC-M ####  This function show the firmware version and the machine serial number.

  • Page 69: Print Driver Operation

    Chapter 3 Operation 3.4 Print Driver Operation Because SLC-M is controlled by a standard Windows printer driver, you can create the drawing on your favorite graphics software based on Windows system. When you want to send files to SLC-M, you can easy modify the driver settings just like using a desktop printer.
  • Page 70 Chapter 3 Operation 2. Power This item can control the output power by setting the percentage of maximum power. For example, if the maximum power of Laser generator is 30 Watts, then setting 50% power will generate about 15 Watts of output power. 3.
  • Page 71 Chapter 3 Operation 9. Language This drop-down box allows user to select different languages. 10. Version Clicking this button will show the version of driver. 11. Custom Lang. Clicking this button will pop up a [CUSTOM LANGUAGE] window that can allow user to modify or create custom language.

  • Page 72: Job Tab

    Chapter 3 Operation 3.4.2 Job Tab The Job tab is divided into four sections: Job Mode and Cut & Engrave Setup. 1. Job Mode Normal This mode uses the eight color settings to vector cut graphics drawn in the graphic software. (other mode is not supply for SLC-M at this time) 2.
  • Page 73 Chapter 3 Operation 3. Cut & Engrave Setup The Cut & Engrave Setup section allows the user to enable and disable certain functions of the machine. If the box next to Cut is unchecked the machine will disregard any potions of the graphics that instruct the laser to vector cut. engraving mode is not supply at this time.

  • Page 74: Page Tab

    Chapter 3 Operation 3.4.3 Page Tab The Page Tab is divided into four sections: Page Setup, Job Title, Repetition, and Position Mode. 1. Page Setup The Page Setup section includes the Width and Height information of machine. There are two functions in this section. They are Imperial and Time Estimate. Imperial Checking this box to switch the driver between the metric and imperial systems of measurement.
  • Page 75 Chapter 3 Operation 4. Position Mode Temp Ref. Point If this box is checked, the file will not execute in the position as application software. Otherwise, it will execute in the position where user determine on machine. Relative Point There are nine relative points. They are Top Left, Top Middle, Top Right, Middle Left, Center, Middle Right, Bottom Left, Bottom Middle and Bottom Right.

  • Page 76: Power Scale

    Chapter 3 Operation 3.4.4 Power Scale The Power Scale tab is divided into two sections, Power Scale and Custom Power Scale. 1. Power Scale The Power Scale section is used to adjust the strength of the laser power. While in Rubber mode, the Power Scale function will control the curve of the tapered profile.

  • Page 77: Ltt Product Tools

    3.5 LTT Product Tools 3.5.1 System Upgrade Generally, the file for upgrade will be provided from LTT. The file type is [*.ice]. While upgrade is processing and the power is turned off or the cable is disconnected, the SLC-M may not be upgraded for the moment. If this situation happens, please contact LTT.
  • Page 78 Chapter 3 Operation 4. Then select the [*.ice] file with […] key, then press [Send] key to upgrade the firmware of SLC-M. 5. You will hear two short beeps along with the following display, showing that the upgrade has completed successfully. firmware upgrade complete ! Press...

  • Page 79: Ethernet Settings Upgrade

    Chapter 3 Operation 3.5.2 Ethernet Settings Upgrade 1. Please repest the steps (1)~(4) in section 3.5.1. 2. The computer name will be obtained automatically, and make sure that it is composed of English character and number. If you want to modify for another computer, you can change the computer name manually 3.

  • Page 80: Basic Operation Flow With Ccd

    Chapter 3 Operation 5. You will hear two short beeps along with the following display, showing that the upgrade has completed successfully. firmware upgrade complete ! Press on the Control Panel and you will hear a beep after which SLC-M returns to main menu.

  • Page 81: Autoccd

    Chapter 3 Operation Select printer  Click to start CCD task  3.7 AutoCCD AutoCCD is the main control program for cutting with CCD. It is to find reference marks of work piece, and moving and rotating the drawing to the new locate of work piece.

  • Page 82: Find The Ccd Ip Address

    Chapter 3 Operation 3.7.1.1 Find the CCD IP address 1. When connecting to CCD, it will use DHCP to get an IP address. When CCD connection is all right, In-sight will show the device in [In-Sight Network]. You can press [Ctrl]+[Shift]+[1] to show [In-Sight Network] window 2.

  • Page 83: Autoccd Monitor

    Chapter 3 Operation 3.7.2 AutoCCD Monitor This area can show the image from CCD on time or last time. If the [Show Sheet] is selected, it can show the location of reference mark or temporary retrain the pattern.

  • Page 84: Task Control

    Chapter 3 Operation 3.7.3 Task Control 1. File location: load the drawing file. (See 3.7.3.1 for more detail) 2. Printer: Select the working machine. 3. Mark Distance: The distance between reference mark and working picture. (See 3.7.3.2 for more detail) 4.

  • Page 85: Two Point Setting

    Chapter 3 Operation For example, the values of dX and dY in below drawing are -6 and -6 3.7.3.3 Two Point Setting Two Point Setting is the distance between two reference marks. If the top left one is the origin of the coordinates, the coordinate of the bottom right one is the setting.

  • Page 86: Ccd Setting Control

    Chapter 3 Operation For example, two point setting of above picture is dX= 6 , dY= 4 3.7.4 CCD Setting Control 1. CCD shift: The CCD-shaft is the distance between laser focus and the center of CCD camera. (See 3.7.4.1 for more detail) 2.

  • Page 87: Ccd Shift

    Chapter 3 Operation 3.7.4.1 CCD shift Before measure the CCD shift, please prepare a black paper. 1. Put the black paper on the honeycomb table. 2. Drawing a cross mark. The center of the mark is on (200,200).(Please use CoreDRAW to output the drawing, AutoCAD may cause the calculation of CCD shift is wrong) 3.

  • Page 88: Communication Setting

    Chapter 3 Operation ○ 7 9. Moving Top: Move the carriage to Top. The distance is setting in ○ 7 10. Moving Right: Move the carriage to right. The distance is setting in ○ 7 11. Moving bottom: Move the carriage to bottom. The distance is setting in 3.7.5 Communication Setting Communication Setting is setup the communication port of RS232.

  • Page 89: Load A Job

    2. Click the CCD device in [In-Sight Sensors]. (You can click Shift + Ctrl + 1 show this window) 3. Click [File] -> [Open Job] to load job 4. Load the job [LTT-01.job] which is included in Install CD. (Please use this job to modify to a new job)

  • Page 90: Pattern Training

    Chapter 3 Operation 3.8.2 Pattern Training Pattern Training is to locate the reference mark. When train the pattern, please make sure there is no any back ground to influence the training. 1. Using online mode or live mode to find a reference mark. 2.
  • Page 91 Chapter 3 Operation 4. Use the red frame to bound the reference mark. Double click to complete. 5. Double click [Model Settings] to define the center of the reference mark. 5. Use the red cross to locate the center of the reference mark. Double click to complete.
  • Page 92 Chapter 3 Operation 7. Click [OK] putton to complete. 8. You can see the resoult by click [Patterns] to move the frame on it. To close the sheet can see it more clear.

  • Page 93: Units Transform

    Chapter 3 Operation 3.8.3 Units Transform In this section, we will teach you how to calculate the units transform between pixel and mm. This parameter will vary with working distance. 1. Please put the work-piece on the honeycomb table 2. Move the carriage to see the frame of the work-piece. 3.

  • Page 94: Save As A New Job

    Chapter 3 Operation 7. Use the value of two pattern real distance to divide by the value of units transform. measure distance  Unit transform pixel distance 8. Key-in the value from step 7 to the D5 in the sheet of the job 3.8.4 Save as a New Job After modify the job, we suggest you to save the modified job as a new job.

  • Page 95: Set The Default Job

    Chapter 3 Operation 3. Key-in the file name you want in the file name diagram and click [Save] 3.8.5 Set the Default Job When AutoCCD connects to the CCD, it will use the present job in In-sight explorer. If In-Sight Explorer does not be executed, AutoCCD will load the default job. This section will explain how to setup a job to be the default job.
  • Page 96 Chapter 3 Operation 4. Select the job you want to be set as the default job. Then, press [OK]. The setting will take effect after CCD restarted.

  • Page 97: Chapter 4 Maintenance

    Chapter 4 Maintenance Chapter 4 Maintenance 4.1 Daily Cleaning 1. Preparation Ensure that the system is turned off and the AC power cable  unplugged. Prepare for cotton swab, cotton cloth, and alcohol.  2. Clean machine Remove all loose dirt and debris from inside of the machine. ...
  • Page 98 Chapter 4 Maintenance Clean 5 mirror and focal lens with cotton swab and alcohol.  Clean 5 mirror with cotton swab and alcohol Loosen these two screws by hand, and take off the cover.
  • Page 99 Chapter 4 Maintenance Pull out the focal lens, clean it (both sides of lens), and push it back.
  • Page 100 Chapter 4 Maintenance Assemble the cover and screws back. Clean CCD lens cover with cotton swab and alcohol.  Loosen these two screws, and take off the LED light.
  • Page 101 Chapter 4 Maintenance Clean CCD lens cover with cotton swab and alcohol Assemble the LED, and screws back...

  • Page 102: Weekly Cleaning

    Chapter 4 Maintenance 4.2 Weekly Cleaning 1. Preparation Ensure that the system is turned off and the AC power cable  unplugged. Prepare for compressive air which is waterless and oil free, dry  brush, cotton swab and alcohol. 2. Clean machine Clean all electric components with compressive air and dry brush.
  • Page 103 Chapter 4 Maintenance Clean the mirror. Assemble the cover and screws back.

  • Page 104: Chapter 5 Trouble Shooting

    Realign by adjusting mirrors. The setting of laser power is too Increase the setting. low. (See section 3.4.2.) Laser generator has Please contact LTT. breakdown. (See Introduction) Cutting or engraving Focal length is not suitable. Adjust focal length. quality is bad.

  • Page 105: Appendices

    Appendices Appendices Appendix 1 Specifications This section describes the specification of the SLC-M series. Model SLC-M Work area 600 (L) × 500 (W) mm Focal lens 50 (H) mm Movement Max. speed 300 mm/sec (11.8"/sec) Resolution(DPI) 1000, 500, 333, 250, 200, 160...

  • Page 106: Appendix 2 Dimensions

    Appendices Appendix 2 Dimensions This section describes the dimensions of SLC-M series.  SLC-M series Unit:mm...

  • Page 107: Appendix 3 Suggested Power And Speed Settings

    Appendices Appendix 3 Suggested Power and Speed Settings The below settings are only intended to be starting points. Many variables can affect actual settings. Different manufacturers have different formulations, laser tubes differ in actual power output, natural materials vary greatly, and the user desired results will drastically affect actual settings.
