SIENA RECLINING ARMCHAIR - SRCH
ASSEMBLY INSTRUCTIONS
COMPONENTS
Seat Back
Quantity: 1
5
Front Seat Rail
Quantity: 1
HARDWARE
A
Steel Rod
Quantity: 1
E
Washers 10mm x 2mm
Quantity: 2
FINISHING ITEMS
MediumGrit Sandpaper
NOTE: If the furniture is going to be placed on a concrete or tile patio, it should first be rinsed well
to remove the sawdust that may cause some staining.
NOTE: A hammer (not provided) will be needed for the assembly of this chair.
15 Kingbrook Parkway, Suite 100 Simpsonville, KY 40067 p. 877.866.3331
Seat
Quantity: 1
6
Rear Seat Rail
Quantity: 1
B
Washer2 10mm x 1mm
Quantity: 2
Right Leg Assembly
Quantity: 1
C
Polyethylene Blocks
Quantity: 2
f. 502.719.8888 oxfordgarden.com
Ver. 06.30.20
Left Leg Assembly
Quantity: 1
D
Dowels
Quantity: 8
