Summary of Contents for Skynet SoonMark M8
- Page 1 User Manual of Thermal Label Printer Brand: SoonMark Model: M8...
-
Page 2: Table Of Contents
Table of Content Kindly follow this user guide instruction: Clicking at each topic below will bring you to the relevant page directly. Page No. 1. Equipment checklist 2. The different parts of the printer 3. Getting the printer ready 4. The driver installation 5. -
Page 3: Equipment Checklist
1. Equipment checklist. 1) Adapter + Power Jack Adapter 2) USB Printer Cable 3) Operation Manual 4) Driver Disk 5) Power Cord 2) USB Printer Cable 3) Operation Manual 1) Adapter + Power Jack Adapter 5) Power Cord 4) Driver Disk... - Page 4 1. Equipment checklist. Insert the label roll using the ‘Roll Mount’. Label Spindle Core Adapter Label Roll Roll Mount Core Adapter will be placed at both sides to secure the label roll while printing. Notes: Make sure all pieces of equipment are assembled and in good condition.
-
Page 5: The Different Parts Of The Printer
2. The different parts of the printer. The Front view Clear Window is to view Feed the label roll Button inside the is used for printer. calibration process. The Open button for the Top Cover The Back view Power Switch I - On O - Off SD Card... -
Page 6: Getting The Printer Ready
3. Getting the printer ready. Step 1 Please connect the ‘USB’ to the PC/Laptop and plugin the ‘Power Cord’ into the socket. Step 2 The ‘USB Printer Cable’ and ‘Power Jack Adapter’ need to connect with the printer. Then, turn on the switch button, and it will beep once. -
Page 7: The Driver Installation
4. The driver installation. Step 1 Click here: skynet.com.my/soonmarkprinter and select the ‘Driver’ as shown. Step 2 This driver will download as a zip file. Kindly save this zip file at any folder inside your PC/Laptop. Step 3 To unzip the file, right-click at the zip file and choose... - Page 8 Step 4 After unzipping the file, double click at ‘Driver (for Win7 Win8 Win10)’ to install the printer driver. Step 5 Kindly tick ‘I accept the terms in the license agreement’ and click on the ‘Next’ button.
- Page 9 Step 6 Click the ‘Next’ button. Then, click at the ‘Finish’ button.
- Page 10 Step 7 This ‘Shield icon’ will blink at the PC/Laptop taskbar. Kindly click at the icon to continue the installation. Then, click on the ‘Next’ button.
- Page 11 Step 8 Click on the ‘Next’ button. • Use the default name or rename the file for easier reference. • Rename the Printer as ‘SMK-M8’. ➢ SMK referring to SoonMark. ➢ M8 referring the Model’s name. • Once done, click on the ‘Next’ button.
- Page 12 Step 9 Click on the ‘Finish’ button. The driver has been installed successfully! Click ‘Close’.
-
Page 13: Setting The Printing Preferences
5. Setting the printing preferences. Step 1 Go to the Windows ‘Setting' and click on the ‘Devices’. Step 2 • Click at the ‘Printer & Scanners’. • Select the printer that has already been renamed as ‘SMK-M8’. • Click on the ‘Manage’ button. - Page 14 Step 3 Click at the ‘Printing preferences’. Idle Step 4 • Select the size ‘4 x 6’ (4.00 in x 6.00 in) for the A6 sticker. • Click on the ‘Apply’ button to apply the changes and then click ‘OK’.
-
Page 15: Inserting The New Label Roll
6. Inserting the new label roll. Below is the step on how to insert a new roll. Step 1 Open the top cover. Put your finger behind the triangle at both sides and pull forwards. Front facing Step 2 Insert the label roll using the ‘Roll Mount’ with the label facing up. -
Page 16: Paper Calibration
7. Paper calibration. The process is for the printer to detect the paper size of the new label roll. Step 1 • Insert the new label roll. • The ‘USB Printer Cable’ and ‘Power Jack Adapter’ need to connect with the printer. •... -
Page 17: Printing The Eawb
8. Printing the eAWB. Once everything is complete, the last process is to print your eAWB. Step 1 Select the ‘SMK-M8’ printer. Step 2 Select ‘Fit to Paper’ for ‘Scale’ and click ‘Print’. - Page 18 Thank You...
