Controlled Access 6500 Series Service & Installation Manual

Turnstile control head
Hide thumbs

Advertisement

Quick Links

Download this manual
6500 Series Turnstile Control Head
Note: Successful turnstile installation depends on reading this manual.
Important Note: Please keep this service manual after installation. If an installation is done by a
construction company or outside installer, please pass this book along to the end user. This book
is required for maintenance, troubleshooting, and repairs.
Toll Free Phone: (800) 942-0829 | Fax: (800) 942-0828 / Phone: (330) 273-6185 | Fax: (330) 273-4468
6500 Series Control Head Service & Installation Manual
Service & Installation Manual
Security Begins With Controlled Access
1636 W. 130th Street, Brunswick, OH 44212
The 6500 series control head is
certified to conform to the following
standards: UL Standard 326,
UL Subject 2593 and
CSA Standard C22.2 #247

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Controlled Access 6500 Series

  • Page 1 6500 Series Control Head Service & Installation Manual 6500 Series Turnstile Control Head Service & Installation Manual Note: Successful turnstile installation depends on reading this manual. Important Note: Please keep this service manual after installation. If an installation is done by a construction company or outside installer, please pass this book along to the end user.

  • Page 2: Important Electrical Information

    6500 Series Control Head Service & Installation Manual Important Electrical Information Installation of the control head mechanism into the turnstile requires a grounding-type outlet receptacle installed inside of the frame or cabinet through the provided conduit access points. To reduce the risk of electric shock, this equipment has a grounding type plug that has a third (grounding) pin.
  • Page 3 Normally open contact closure Security Pros and Engineers (Form C relay, closed for duration) For two decades, Controlled Access has been the globally trusted name in The 6500 series control head is pedestrian control equipment. Made in Ohio and shipped worldwide, we are...
  • Page 4 Full Height Turnstile Rotor Alignment Mounting a new 6500 series control head is very simple. Unbolt the existing control head from whatever turnstile it is installed in and mount the new one in its place. The control head is backwards compatible with nearly every turnstile we have ever made on its own.
  • Page 5 Waist High Installation: New waist high turnstiles already have the 6500 series control head mounted in place. However, should the need to replace the control head ever arise, follow these steps: •...
  • Page 6 6500 Series Control Head Service & Installation Manual 6500 Series Control Head Information All of our turnstiles and ADA gates operate with a mechanism called the 6500 series control head. This sturdy and easy to maintain drive for the turnstile has replaced all previous model control heads.
  • Page 7 6500 Series Control Head Service & Installation Manual Security Begins With Controlled Access 1636 W. 130th Street, Brunswick, OH 44212 Toll Free Phone: (800) 942-0829 | Fax: (800) 942-0828 / Phone: (330) 273-6185 | Fax: (330) 273-4468...
  • Page 8 Phone: (800)942-0839 Controlled Access, Inc. Complete control heads are Fax: (800) 942-0828 1636 W. 130th St. available upon request. Web: www.controlledaccess.com Brunswick, OH 44212 Contact us for pricing details. Email: sales@controlledaccess.com Control Head Castings Control Head Bearings Locking Bar Assemblies...
  • Page 9 6500 Series Control Head Configuration Information The 6500 series can be configured in a number of different ways. All turnstiles operating with the 6500 series control head self center and hydraulically shock to the home position to prevent damage or injury.
  • Page 10 6500 Series Control Head Locking Bar Information Any number of configurations is possible on the 6500 series control head. In the case of an electronic two way head, two independent locking mechanisms are in place. The following diagram indicates which direction unlocks from which locking mechanism.
  • Page 11 6500 Series Control Head Service & Installation Manual Power Failure State Configuration (Fail Lock / Fail Open) Each direction on a control head can be independently configured to open or lock upon power failure. The fail status configuration is based on the pivot point used on the locking bar as well as the linkage and solenoid spring used.
  • Page 12 6500 Series Control Head Shock Adjustment and Replacement The 6500 series control head utilizes a hydraulic shock for controlling the speed of the rotation. Set properly, the shock will allow a turnstile or gate to self-center while rotating smoothly without slamming.
  • Page 13 6500 Series Control Head Service & Installation Manual 6500 Series Control Head Electrical Information Each electronic control head comes with a power supply, a programmable logic controller (PLC), limit switches (or proximity sensors) and solenoids. For safety purposes, it is recommended that you read all literature on the electrical components before attempting to install the control head into a turnstile.
  • Page 14 6500 Series Control Head Service & Installation Manual...
  • Page 15 6500 Series Control Head Service & Installation Manual 6500 Series Control Head Wiring Legend Since each control head comes pre-wired, only access control and fire alarm should need to be connected to the board. If you are unable to fit wires for access control on the 24VDC+ input on the board, the voltage can be picked up directly from the power supply or from the relay commons (C3 &...
  • Page 16 DM, TM, T/C, CTC, TRM, and RLY are all possible selections to load. Again, we are only using DM (device mode) with the 6500 series control head. Should you find that you accidently have loaded any other selected device type, simply press to scroll until you have once again loaded the DM type.
  • Page 17 6500 Series Control Head Service & Installation Manual In addition to the device mode window, system mode can be accessed as well. Although under normal circumstances you should never encounter this window, if by accident you should happen to come across it, simply press the up or down arrow until the window reads “run”. Press and hold button for 3 seconds, and the display will return to device mode.
  • Page 18 While working within device mode, two primary values should be considered. On the top of the display, the selected device is shown. The 6500 series control head settings can be adjusted with devices 0 – 7. Pressing the up or down arrows allow you to select which device you wish to modify. Pressing and holding the key for 3 seconds loads the modification window.
  • Page 19 Revision 1.20 introduced the revision number system as well as directional override inputs. If previous installations desire to add this feature, the logic controller can be shipped back to Controlled Access, Inc. for a software upgrade or a replacement controller can be purchased.
  • Page 20 6500 Series Control Head Service & Installation Manual 6500 Series Full Height Control Head Limit Switches Direction 1 is canceled by limit switch 1 and direction 2 is canceled by limit switch 2. As the unit rotates, both limit switches are triggered. However, only the limit switch designated for that direction is utilized to relock the unit.

  • Page 21: Maintenance And Cleaning

    6500 Series Control Head Service & Installation Manual Maintenance & Cleaning To ensure long life on any turnstile, the following maintenance is recommended. Note: These figures are assuming a maximum of 75000 passages per year. Turnstiles with heavier traffic should be maintained more frequently.
  • Page 22 6500 Series Control Head Service & Installation Manual 6500 Series Control Head Testing Security Begins With Controlled Access 1636 W. 130th Street, Brunswick, OH 44212 Toll Free Phone: (800) 942-0829 | Fax: (800) 942-0828 / Phone: (330) 273-6185 | Fax: (330) 273-4468...
  • Page 23 6500 Series Control Head Service & Installation Manual 6500 Series Control Head w/ Keyence KV-16DR Controller Troubleshooting Symptoms Causes Solutions Verify outlet receptacle installed Power supply is not receiving in mainframe / cabinet is operating correctly and that the input voltage.
  • Page 24 6500 Series Control Head Service & Installation Manual 6500 Series Control Head w/ Keyence KV-16DR Controller Troubleshooting Symptoms Causes Solutions Access control device output Wire access control to 000/002 connected to override inputs. with one-shot timer enabled. This can be avoided by enabling the one-shot timers built into the logic controller program.
  • Page 25 6500 Series Control Head Service & Installation Manual 6500 Series Control Head w/ Keyence KV-16DR Controller Troubleshooting Symptoms Causes Solutions Remove locking bar assembly from control head (easiest way on Mechanical bind between locking Unit remains locked after access non-keylock models is to punch...
  • Page 26 6500 Series Control Head Service & Installation Manual Proper Turnstile Usage The 6500 series turnstile control head is easy to use. There are a few things that users should be trained on and informed of. In the case of an electronic turnstile, approach the unit and swipe the card. Do not push on the •...

  • Page 27: Installation

    96M1274 ■ Precautions for UL Standards The MS2 Series meets the following UL standards and has obtained UL and C-UL certification. • Applicable standard UL508 Industrial Control Equipment UL60950-1 Information Technology Equipment - Safety CAN/CSA C22.2 No. 14-M95 Industrial Control Equipment CAN/CSA C22.2 No.
  • Page 28 Method of Operation Dimensions The display mode changes each time when the MODE switch is pressed. MS2-H50/H75/H100 MS2-H300 (10) (12) 131.5 Output current display . 8 . 0 . 7 Displays the output current down to 0.1 A. ▼ 35.9 35.9 Displays the load factor down to 1%.
  • Page 29 PLC Specifications Performance specifications General specifications DC type Arithmetic operation AC type Stored program method KV-10DT(P)/DR KV-16DT(P)/DR Model control method KV-10AT(P)/AR KV-16AT(P)/AR KV-24DT(P)/DR KV-40DT(P)/DR KV-24AT(P)/AR KV-40AT(P)/AR I/O control method Refresh method Programming 24 VDC (+10%, -20%) Rated voltage 100 to 240 VAC (±10%) Ladder diagram and expanded ladder diagram language KV-10AT(P)/AR: 0.4 A...
  • Page 30 Input specifications of base unit Output specifications of basic unit Model KV-10xx KV-16xx KV-24xx KV-40xx Model KV-10xT(P) KV-16xT(P) KV-24xT(P) KV-40xT(P) KV-10xR KV-16xR KV-24xR KV-40xR No. of inputs No. of outputs Input common COM is connected internally. Output common 1 common Each common terminal is independent.
