- Page 1 USER’S MANUAL FJORDA Smeva BV Address: J.F. Kennedylaan 27 5555 XC Valkenswaard Telephone: 040-2073200 Internet: www.smeva.nl Specifications of the manual: Version: 02-2014...
-
Page 2: Copyright
Copyright. (GB) Imprint This manual is published by Smeva BV Valkenswaard Nederland. No reproduction (including translation) is permitted in whole or in part e.g. photocopy, microfilming or storage in electronic data processing equipment, without the express written consent of the publisher. -
Page 3: Warnings
Warnings!!! STAFF AND SERVICE PERSONNEL HAVE TO READ THIS MANUAL BEFORE USING THE CABINET. All dangerous parts are located outside the service area. Access to this area is only allowed for staff and qualified engineers. Warning Labels: It is not allowed to remove any labels attached to the cabinet for instruction or safety. The following labels are used: Moving parts: Fan assemblies below bottom shelves. - Page 4 Cleaning: Before you start to clean the cabinet make sure that the power supply is switched off. Based on the product order specification a service switch is located behind the kick plate/front panel of each cabinet section. If there is no service switch, switch off the electrical current by using the switch located in the central fuse box in the shop.
-
Page 5: Table Of Contents
Contents. Copyright Warnings!!! Contents 1 Introduction 2 Putting the Cabinet into service 2.1 External Influences 2.2 Load Arrangement and Use 2.3 Control Panel / Thermostat 2.4 Lighting 2.5 Connection of Outlets 3 Cleaning Instructions 4 General Maintenance Instructions. 5 End of lifecycle: Disassembly, Disposal. 6 Minor Malfunction List 6.1 General Failure 6.2 Partial Failure... -
Page 6: Introduction
Smeva is your guarantee of quality and reliability. The Fjorda is a vertical refrigerated display cabinet, characterises by a wide variety of versions. The cabinet is designed to display cold prepacked goods. And is not designed to cool down goods. -
Page 7: Putting The Cabinet Into Service
2 Putting the Cabinet into Service. For correct operation of the cabinet, the following instructions should be followed. 2.1 External Influences. - Avoid placing the cabinet in direct sunlight. Thermal radiation can raise the product temperature to an unacceptable level even when the air temperature display in the cabinet shows the required value. -
Page 8: Load Arrangement And Use
2.2 Load Arrangement. Before start to load the cabinet it must be carefully cleaned and have reached the required temperature. The self-service cabinet is only mentioned for pre-packed goods. - Make sure that the display is loaded in the right way. Because it can affect the air circulation and temperature. - Page 9 - Use of Shelving, Front risers, Price marking rail, Ticket holder, Night blinds. The shelves can be moved in 3 different angles (0° , 7,5° , 15° ). They can also be moved up and down the shelf rail. When (re)moving the shelves the lighting plug must be disconnected in advance. The max load for the shelves is 60Kg/m.
- Page 10 The front riser is a transparent strip at the front of the shelves which keeps the goods in place. If not installed (correctly), goods could fall out of the shelves! The strips have to be put in the slots at the front of the shelves.
-
Page 11: Control Panel / Thermostat
If the Night blinds are closed, the lights will switch off and an energy saving program will set in. See chapter 2.3 Control panel / Thermostat – Night program. When the night blind gets pulled out, this has to be done carefully and in a straight motion. First pull the curtain forwards, then downwards and attach it to the hook. -
Page 12: Lighting
2.5 Connection of Outlets. (if present) The Fjorda with one presentation level can be fitted with wall sockets (4) for connecting equipment such as scales and cash registers. Designed for a maximum load 230 Volt - 16 Ampere. Next to the wall socket there is a plastic cover in which a cross can be cut. -
Page 13: Cleaning Instructions
Technical cleaning and removal of dust in the evaporator coil and air circulation system. Cleaning and inspection of the drainage system. Consult your Smeva dealer regarding maintenance inspections. 5 End of lifecycle, Disassembly, Disposal. By the development and material choice of the cabinet, a 15 year lifecycle is considered, depending on use and circumstances. -
Page 14: Minor Malfunction List
6 Minor Malfunction List. This list has been drawn up on the assumption that the cabinet has been functioning normally and that, while being used normally, malfunctions suddenly occur. 6.1 General Failure. If all of the functions have failed, check the power supply. Further check the fuses in the group box and in particular the group to which the cabinet is connected. -
Page 15: Product Identification
7 Product Identification. To provide you with rapid assistance in the event of questions or defects, your cabinet is equipped with a product identification label. Based on the product order specification, the product identification label is always situated at the bottom left side of the air discharge panel at the back. Should information be required concerning a particular component or if a component is defective, copy the information shown on this label and pass it on to your installer. -
Page 16: Technical Specifications
Each section based on 230VAC – 16 Amp. max, connected as per corresponding circuit diagrams. The junction boxes display the necessary stickers for connecting. All technical specifications can be found in the corresponding datasheet. Which can be requested by your Smeva dealer. _________________________________________________________________15...
