Shelti Wingman NS-Y-AB Assembly Instructions

Thank you for purchasing a Shelti product. All of us at Shelti want you to be completely satisfied with
your Blue Line Air Powered Hockey game, so feel free to contact us for help with the assembly of your
product, Shelti parts, or other information you may require.
Tools Required:
5mm Hex Wrench
12mm Wrench or Socket
13mm Wrench or Socket
Phillips Head Screw Driver
Level
Step #1
• Lift air hockey table out of the box and flip it upside down on a smooth surface.
• Remove the legs from the shipping board and locate the accessory package.
Contents
Wingman Air Hockey Cabinet
Blower Motor
Universal Leg Assembly
Accessory Package
Wingman Assembly Instructions
Accessory Package Contents
Score Post
Score Rod
Red Score Bead
Black Score Bead
Score Post Screw—Flat Phillips Head
4¾" Carriage Leg Bolt
5½" Carriage Leg Bolt
Leg Nut
Leg Wa
sher
3¼" Puck
Mallet
5mm Hex Wrench
Assembly Instructions
Part Number
NS-AHC-0
210-0176-0
NS-ULA-0
NS-ASA-0
210-0218-0
003-0004-0
205-0007-0
003-0002-0
003-0003-0
301-0036-0
301-0073-0
301-0074-0
203-0023-0
303-0035-0
201-0093-0
201-0094-0
205-0068-0
Quantity
1
1
4
1
1
4
2
5
5
4
12
8
20
20
3
2
1
