Baby Trend RESPIRO Installation Tip

RESPIRO INSTALLATION TIP
™
• To partially zip the Sleep
Surfaces together, insert the
zipper pull into the zipper
insertion and close only 2
inches (Fig 3c).
• Expand the second side of the
Respiro™ Frame completely.
Place one hand on the corner
of the Respiro™ Mattress and
your other hand on the trigger
handle (Fig 3d). Always grasp
the trigger handle from the
outer edge. Do not engage the
trigger handle from the inner
mechanism (Fig 3e).
• Close the zipper completely.
Place the zipper pull flat on the
zipper to lock into position
(Fig 2c).
DO NOT RETURN YOUR PRODUCT TO
THE STORE. PLEASE CONTACT BABY
TREND FOR REPLACEMENT PARTS,
®
SERVICE AND REPAIR.
NO DEVUELVA SU PRODUCTO A LA
TIENDA. POR FAVOR CONTACTE A BABY
TREND PARA PIEZAS DE REPUESTO,
®
SERVICIO Y REPARACION.
NE PAS RETOURNER VOTRE PRODUIT
AU MAGASIN. VEUILLEZ CONTACTER
BABY TREND POUR DES PIÈCES DE
®
RECHANGE, ENTRETIEN ET RÉPARATION.
4
Copyright © 2017, Baby Trend Inc., All Rights Reserved. Todos los derechos reservados. Tous droits réservés.
1) •
Fig. 3c
Fig. 3d
Fig. 3e
CM01XXXA_USA_Insert80817
RESPIRO INSTALLATION TIP
™
After following (Fig. 1a) through
(Fig. 1b) of The Respiro™ Crib
Mattress instruction manual,
use these alternative steps for
a fast and easy installation.
Glide the Sleep Surface tubing
•
completely through the tracks.
Carefully flip the Frame over
•
and repeat for the other Sleep
Surface (Fig 1c).
IMPORTANT:
Be sure that
the tubing goes all the way
through the tracks. Tug the
Sleep Surfaces firmly on the
opposing side to ensure that
the Sleep Surfaces are set in
correctly (Fig 1d).
Copyright © 2017, Baby Trend Inc., All Rights Reserved. Todos los derechos reservados. Tous droits réservés.
Fig. 1c
Closed Track
Fig. 1d
1
