- Page 1 POWER TOOL INSTRUCTION & USER MANUAL JCB-20OS Original Instructions JCB-20OS-EN Iss: 02/2020...
- Page 2 Directive 2012/19/EU. It will then be recycled or dismantled in order to reduce the impact on the environment. Electric and electronic equipment can be hazardous for the environment and for human health since they contain hazardous substances. JCB-20OS Instruction & User Manual...
- Page 3 The month and year of manufacture can be found within the product serial number e.g. MMYYPPPAXXXXX. Where production month (MM) and production year (YY) are included. JCB-20OS Designation of the tool (20 - 20Vdc, OS - Orbital Sander) JCB-20OS Instruction & User Manual...
-
Page 4: Table Of Contents
ON/OFF SWITCH Changing a Sanding Sheet Dust Suction and Dust Extractor Pipe Sanding Surfaces and Grade of Sandpaper BATTERY AND CHARGER OPERATING INSTRUCTIONS 17 Overload Protection MAINTENANCE Transport and Storage WARRANTY STATEMENT GENERAL CERTIFICATE OF CONFORMITY JCB-20OS Instruction & User Manual... -
Page 5: General Power Tool Safety Warnings
Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. JCB-20OS Instruction & User Manual... -
Page 6: Power Tool Use And Care
Use of any other accessories, or storing power tools. Such battery packs may create a risk of injury and fire. preventive safety measures reduce the risk of starting the power tool accidentally. JCB-20OS Instruction & User Manual... -
Page 7: Service
This will ensure that the safety of the power tool is maintained. Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers. JCB-20OS Instruction & User Manual... -
Page 8: Safety Warnings Common For Sanding
Wear eye protection. Wear goggles to prevent eyes from exposure to flying power tool. Incorrectly sized accessories particles. cannot be adequately guarded or controlled. JCB-20OS Instruction & User Manual... -
Page 9: Kickback And Related Warnings
Abrasive wheels may also break under these conditions. Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below. JCB-20OS Instruction & User Manual... -
Page 10: Charger Safety
CHARGER SAFETY JCB chargers are designed to WARNING! operate on standard household supply voltages. Check the rating Read all safety warnings, instructions plate of the charger matches your and specifications provided with the local supply voltage. (Note: the dual charger. Failure to follow all instructions... -
Page 11: Component List
COMPONENT LIST Standard JCB-18VFC charger illustrated, additional chargers available. Battery size shown for illustrative purposes only ABRASIVE SHEET (SANDPAPER) BATTERY PACK* - refer to page 12 for further SANDING DISC information. ON/ OFF SWITCH BATTERY TEST BUTTON AND CHARGE INDICATOR*... -
Page 12: Tool Technical Data
Input Data Output Data JCB-20VFC AC 120 V, 60Hz, 70W 14.4 -20V d.c. 2.4A JCB-20VSFC AC 120 V, 60Hz, 105W 14.4 -20V d.c. 4.0A JCB-20DC AC 120 V, 60Hz, 200W 20.5V d.c. 2 x 3.5A JCB-20OS Instruction & User Manual... -
Page 13: Noise Information
(such as assessment of exposure. the times when the tool is switched off or running idle). JCB-20OS Instruction & User Manual... -
Page 14: Vibration Information
C or less. ° exposure. Plan your work schedule to spread any high vibration power tool use across a number THIS POWER TOOL MAY CAUSE of days. HAND-ARM VIBRATION SYNDROME (HAVS) IF USAGE IS NOT ADEQUATELY MANAGED. JCB-20OS Instruction & User Manual... -
Page 15: Operating Instructions
NOTE Ensure the hook and loop surfaces of the sanding pad tool plate, and chosen sheet are as clean as possible, and free from any large debris prior to mounting the sheet. JCB-20OS Instruction & User Manual... -
Page 16: Sanding Surfaces And Grade Of Sandpaper
The correct grade for your application will in lengthwise and crosswise directions over depend on sanding speed, material and pres- the workpiece. sure applied. Always test on a scrap piece of material if possible. JCB-20OS Instruction & User Manual... -
Page 17: Battery And Charger Operating Instructions
Make sure the ON/OFF Switch slider (3) is Battery Charge Level not set to the ON position (I) when inserting or removing the battery. Use only JCB Green batteries: JCB-20-15LI, JCB-20-20LI, JCB- Battery Charge Status 20-30LI, JCB-20-40LI and JCB-20-50LI. -
Page 18: Overload Protection
(O) position and wait one or two seconds Brush inspection for the electronics to reset, then restart the Brush inspection and replacement should power tool. only be performed by an authorised JCB service centre. WARNING! Power tool lubrication Do not hold the work piece with your JCB power tools are properly lubricated in hands. - Page 19 Ensure that the power tool is not at risk of tipping over or exposed to excessive vibration and shocks during transport, especially if the tool will be transported by car or other vehicle. JCB-20OS Instruction & User Manual...
- Page 20 JCB-20OS Instruction & User Manual...
-
Page 21: Warranty Statement
In the unlikely event your JCB Power Tool is subject to a manufacturing fault within the warranty period, please contact the seller/retailer where the item was purchased. JCB Power Tools used for Hire Fleets or as part of B2B and Service Contracts are not covered by these terms and conditions. - Page 22 JCB-20OS Instruction & User Manual...
-
Page 23: General Certificate Of Conformity
IEC 55014-2:2015 IEC 55014-1:2017 IDENTIFICATION DETAILS OF IMPORTER/US DOMESTIC MANUFACTURER CERTIFYING PRODUCT COMPLIANCE: Name: JCB Tools (Yellow and Black Tools Limited) Address: 55 Romsey Industrial Estate Romsey, SO51 0HR Tel no: +44 1794 834250 CONTACT INFORMATION OF INDIVIDUAL MAINTAINING RECORDS OF TEST RESULTS: Name: Tim Burgoyne, QA Technical Manager &...
