2800W Electric Silent Shredder

WEESS

1938266001

en - Original Instructions

ASSEMBLY REQUIRED

Minimum Two Persons

Sales & Support: 01793 333212

Before use please read & understand this manual; paying particular attention to the safety instructions before use.

Incorrect use of the product could put the operator or machine in danger.

Whilst every eﬀ ort has been made to ensure the accuracy of information contained in this manual, our policy of continuous improvement

determines the right to make modiﬁ cations without prior warning.

Images are used for illustration purposes only.

Need help?

Do you have a question about the WEESS and is the answer not in the manual?

Questions and answers

Summary of Contents for Webb WEESS

Page 1 2800W Electric Silent Shredder WEESS 1938266001 en - Original Instructions ASSEMBLY REQUIRED Minimum Two Persons Sales & Support: 01793 333212 Before use please read & understand this manual; paying particular attention to the safety instructions before use. Incorrect use of the product could put the operator or machine in danger.
Page 2 INSTRUCTION MANUAL 4 Sep 2020 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
Page 3 CONTENTS INTENDED USE SAFETY INSTRUCTIONS SPECIFICATIONS KNOW YOUR MACHINE ASSEMBLY OPERATION ELECTRICAL CONNECTION MAINTENANCE, CLEANING & STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST DECLARATION OF CONFORMITY WARRANTY INTENDED USE The basic version of the equipment is an electric shredder intended for private use, i.e. for use in home and gardening environments.
Page 4 INSTRUCTION MANUAL SAFETY INSTRUCTIONS Read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. Whenever the machine is in use, safety Read &...
Page 5 GENERAL SAFETY RULES WARNING Before you put the machine into operation, you must read this instruction manual. When using this machine, observe the following safety instructions to remove the risk of personal injury or material damage. Please also observe the special safety instructions in the respective chapters. Where applicable, follow the legal directives or regulations for the prevention of accidents in relation to the use of this machine.
Page 6 INSTRUCTION MANUAL 20. Shut the motor off and wait until the blade comes to a complete stop before cleaning the discharge area. The blade continues to rotate for a few seconds after the stop button is pressed. Never place any part of the body in the shredder area until you are sure the blade has stopped rotating and the electrical plug has been removed from the power source and contact cannot be made between the two.
Page 7 DO NOT MODIFY THE MOTOR To avoid serious injury or death, do not modify the motor in any way. Tampering with the motor settings can cause it to operate at unsafe speeds and lead to premature failure. Never tamper with factory settings of the motor.
Page 8 INSTRUCTION MANUAL SPECIFICATIONS Model No. WEESS Product No. 1938266001 Motor 230-240V~ 50Hz Rated Power 2800W Revolutions Max. (Per Min) 2850 Blade Cylinder Ø 88mm Number of Blades Max Cutting Capacity 45mm Collector Capacity Cable Length Guaranteed Sound Power Level L...
Page 9 KNOW YOUR MACHINE Input Chute 2. Electrical Power Connection Safety Locking Mechanism 4. Blade Adjustment Knob Collector Frame 6. 55L Collector Support Feet 8. Transport Wheels On (O)/ Off (-) Switch 10. Reverse Switch 11. Reset Switch 12. Motor Housing * Image may vary from actual machine...
Page 10 INSTRUCTION MANUAL ASSEMBLY Open the packaging and remove the device carefully. Remove the packaging material as well as the packaging and transport bracing (if fitted). Check that the delivery is complete. Check the device and accessory parts for transport damage. If possible, store the packaging until the warranty period has expired. The device and packaging materials are not toys! Children must not be allowed to play with plastic bags, film and small parts! There is a risk of swallowing and suffocation!
Page 11 If you require assistance with regards to the contents or operation of the machine, please contact us: Tel: 01793 333212 Email: customerservice@webbgardenpower.co.uk Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am - 5:00pm (Closed Bank Holidays) WARNING Stop the motor and unplug the electrical power cable from the power source before any repairs or maintenance operations.
Page 12 INSTRUCTION MANUAL TRANSPORT WHEELS 1. Place Wheel Pin Ø8x70 (A) through Washer (B) and then Transport Wheel (8). 2. Fit this to the outside of the Frame (5) and slide through the fixing hole. 3. When the Wheel Pin Ø8x70 is through the frame, slide a second Washer (B) on the Wheel Pin and secure with a Split Pin (C) being placed through the eyelet at the end of the Wheel Pin and split the two legs of the Split Pin, to secure.
Page 13 COLLECTOR Important: Before you attach the collector, please ensure that the motor is switched off and the blade/tines are not rotating. 1. Turn the machine back onto it’s feet and transport wheels. 2. Place the locking mechanism (3) on the collector (6) into its lowest position (Fig. 6). 3.
Page 14 INSTRUCTION MANUAL POWER CONNECTION WARNING Before operating the machine, ensure that the fastening elements are undamaged. To reduce the risk of injuries, always switch off the motor and pull out the mains plug before working on the machine The product can be connected to any BS three pin socket with 230-240V alternating current. We recommend to always use the appliance via a Residual Current Device (RCD) with a tripping current of max.
Page 15 REVERSE SWITCH Manual change of blade direction (8) POSITION The blades rotate in the forward direction. POSITION The blades rotate in the reverse direction to release jammed material. When you change the direction into (reverse), hold the green power switch to rotate the blades. The shredder automatically stops when you release the power switch.
Page 16 INSTRUCTION MANUAL 3. Turn the adjustment wheel (10) clockwise until you can hear slight grinding sounds. 4. When turning the adjustment wheel (10) clockwise by half a turn, the cylinder blade (10) is positioned closer to the counter blade by 0.50 mm. (The image is used for information reasons only) WARNING If the shredder blade touches the counter blade, it will be trimmed, and small pieces of swarf may fall out...
Page 17 Electrical connection cables must comply with the applicable VDE and DIN provisions. Only use connection cables with the marking „H05VV-F“. The printing of the type designation on the connection cable is mandatory. AC motor The mains voltage must be 230 V~ Extension cables up to 25m long must have a cross-section of 2.5 mm Connections and repairs of electrical equipment may only be carried out by an electrician.
Page 18 INSTRUCTION MANUAL STORAGE & TRANSPORT The following steps should be taken to prepare your machine for storage. CAUTION The motor must have completely cooled down before storing. NOTE: When storing any type of power equipment in an unventilated or material storage shed, Care should be taken to rust-proof the equipment.
Page 19 Notes...
Page 20 PARTS DIAGRAM - WEESS 1938266001...
Page 21 PARTS LIST - WEESS 1938266001 Spare Parts are available from our Spares Team. Please call 01793 333212, option 1 for assistance.
Page 22 INSTRUCTION MANUAL Notes...
Page 23 EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Electric 2800W Silent Shredder Model(s): WEESS Product No.: 1938266001 Type/Serial No. As per rating label on machine Rated Power: 2800W Revolutions Max. (Per Min): 2850...
Page 24 INSTRUCTION MANUAL Notes...
Page 25 Notes...
Page 26 INSTRUCTION MANUAL This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the conditional manufacturer domestic warranty*. Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
Page 27 2. Period of Warranty - valid from 1 January 2020 Webb (excludes Dynamic, Legacy & Heritage), 2 year conditional warranty from the original date of sale to the ﬁ rst domestic user.
Page 28 It is the owner’s responsibility to ensure that their Webb machine is maintained at speciﬁ c intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
Page 29 SERVICE BOOK Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 1st Service This must be stamped by an approved service dealer to qualify for a free second year warranty.
Page 30 Service Record INSTRUCTION MANUAL 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date...
Page 31 Email From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, oﬀ ers or just opinions, which may be used for marketing, research or analysis purposes.
Page 32 Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY...
