maile M-2028 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
MAILE
Infrared Thermometer
User Manual
Model:M-2028
Before the use, please carefully read the User Manual.
Refer to the qualification certificate or the packing box
for the production date.
Jiangxi Maile Medical
Device Co.,Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the M-2028 and is the answer not in the manual?

Questions and answers

Summary of Contents for maile M-2028

  • Page 1 Jiangxi Maile Medical MAILE Device Co.,Ltd. Infrared Thermometer User Manual Model:M-2028 Before the use, please carefully read the User Manual. Refer to the qualification certificate or the packing box for the production date.
  • Page 2 1. Product Name Infrared thermometer 2. Model M-2028 3. Structure and Components The Infrared thermometer mainly consists of infrared sensor, LCD display screen, operation buttons, plastic shell, measurement button, battery bunker, circuit component and other parts. LCD screen Page down, Memor y inquir y...
  • Page 3 6. Safety Characteristics 6.1 Classified by electric shock protection type: Int- ernal power class 6.2 Classified by electric shock protection degree: BF application part 6.3 Classified by protection degree of liquid inlet: ordinary equipment 6.4 Classified by the safety when it is mixed with in- flammable anesthetizing gas mixing with air or mixed with anesthetizing gas mixing with : not applicable.
  • Page 4 ±0.2V, low voltage sign will be displayed on the screen. 7.7 LCD display screen with backlight is able to be used in darkness. 7.8 The infrared forehead thermometer is able to me- morize 32 measurement values obtained recently. (When the infrared forehead thermometer is off, shortly press “+”...
  • Page 5 9.12 If there is a problem, please contact with the distributor but not repair it by yourself. 9.13 Do not measure the body temperature when the environment temperature changes a lot. 9.14 The protective glass outside the crystal frame work is quite significant, which is easy to be bro- ken.
  • Page 6 10.2 Before using the forehead thermometer, please get the batteries into it. Here below is the way to install the batteries: 10.2.1 Open the battery cover and put the batteries into the slot, with the anode and cathode correctly placed. 10.2.2 If the infrared forehead thermometer is used for the first time or a new battery is just put into it, heat it by waiting for 10 minutes.
  • Page 7 Note: a. Before measurement, please make sure that there is no sweat, hair, cosmetics and hat covering on the forehead. b. In one day, human's temperature would change from time to time, which also influences by other external factors, like age, gender and skin color etc.
  • Page 8 38℃ (100.4oF). 10.4.4 Set temperature deviation - F3 Press the button “set” for 3 seconds, F1 is disp- layed on the screen; shortly press the button “set” for 2 times, F3 is displayed on the screen. Under F3, the temperature increases 0.1℃/0.1oF if the button “+”...
  • Page 9 by 0.3 ~ 0.5 ℃. 10.5.2 Clinical deviation Deviation from Clinical deviation Part clinical standard / ℃ / ℃ 0~1 years old Forehead 0.0227 0.0356 1~5 years old Forehead 0.0133 0.0640 Over 5 years old Forehead 0.0038 0.0396 >Clinical deviation: ≤ ±0.2℃, deviation from clinical standard: ≤±0.2℃ 10.5.3 Clinical repeatability Clinical repeatability / ℃...
  • Page 10 disposing the wastes, abandonment and residues. 12. Product Care The thermometer is provided with a calibration mo- de (object mode / body mode), which can be used to calibrate the thermometer. During the service life, there is no need to calibrate the thermometer. If the service life is due and the thermometer is still being used, it is necessary to send it back to the manufac- turer for a calibration.
  • Page 11 ■Atmospheric pressure: 70kPa ~ 106kPa. ■At a well-ventilated place where there is no corrosive air, exterior. ■The transportation requirements shall follow th e ones set in the order contract. However, please make sure that during the transportation, there is no severe shock, vibration and rainfall. The thermometer is not resistant to high temperature, high humidity, severe crash impact.

  • Page 12: Manufacturer's Contact Information

    20. Production Certificate Number of Medical Equipment Jiangxi Food and Drug Administration firearms production No. 20200360 21. Registered / Manufacturer Name Jiangxi Maile Medical Device Co.,Ltd. 22. Registered / Manufacturer Address Floor 1-3, No.141 Changan Road, Wengang Town, Jinxian County, Nanchang City, Jiangxi Province, China 23.
  • Page 13 Portable and mobile RF communication equip- ment might influence the performance of infrared forehead thermometer (M-2028), so please avoid the strong electromagnetic interference at the time of use, like mobile phone or micro oven.

  • Page 14: Warranty Registration Card

    When requiring to maintain the equipment, please show the Remark warranty card or the electronic warranty card. Jiangxi Maile Medical Device Co.,Ltd. Address: Floor 1-3, No.141 Changan Road, Wengang Town, Jinxian County, Nanchang City, Jiangxi Province, China Phone：+86 791 8558 6555 Postcode: 331722 http://www.maile.co...
