Hom comfort HCGB1 Installation And Operating Manual

Gas barrel

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Installation and Operating Manual

French version is available for download from the U.S. Stove website:

http://www.usstove.com/ La version française est disponible pour

téléchargement à partir du site U.S. Stove: http://www. usstove.com/

This unit is not intended to be used as a primary source of heat.

WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing

property damage, personal injury or loss of life.

• Do not store or use gasoline or other flammable vapors and liquids in vicinity of this or any other appliance.

• A propane cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS:

• Shut off gas to the appliance.

• Extinguish any open flame.

• If odor continues, keep away from the appliance and immediately call your gas supplier or fire

department.

Installation and service must be performed by an NFI Certified or other qualified professional installer, service

agency, or gas supplier.

This appliance is designed as an attended appliance.

Adults must be present when the unit is operating.

DO NOT leave this unit burning when unattended. If

this product is left burning unattended, it may cause

damage or serious injury.

IMPORTANT

For safe operation and proper performance of this

product and to comply with certification, listings,

and building code acceptances, use ONLY Peterson

AFD controls, parts, and accessories that have been

specifically listed or certified for use with this burner

system. Use of other controls, parts, or accessories is

prohibited and will void all warranties, certifications,

listings, and building code approvals, and may cause

property damage, personal injury, and loss of life.

CODE AND SUPPLY REQUIREMENTS:

The installation must conform with local codes and

ordinances, or, in the absence of local codes, with

the latest National Fuel Gas Code, ANSI Z223. 1.

HCGB1

WARNING:

For Outdoor Use Only

Improper installation, adjustment, alteration, service,

or maintenance can cause property damage,

personal injury, or loss of life. Read the installation,

operating and maintenance instructions thoroughly

before installing or servicing this equipment.

CARBON MONOXIDE HAZARD

• This appliance can produce carbon monoxide

which has no odor.

• Using it in an enclosed space can kill you.

• Never use this appliance in an enclosed space

such as a camper, tent, car, or home.

INSTALLER & CONSUMER: These instructions MUST be

retained with this appliance for future reference.

Important: Read these instructions carefully before

starting installation of the unit.

WARNING

DANGER

852887-4101F

Table of Contents

Need help?

Do you have a question about the HCGB1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hom comfort HCGB1

Page 1 Installation and Operating Manual HCGB1 WARNING: For Outdoor Use Only French version is available for download from the U.S. Stove website: http://www.usstove.com/ La version française est disponible pour téléchargement à partir du site U.S. Stove: http://www. usstove.com/ This unit is not intended to be used as a primary source of heat. WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. • Do not store or use gasoline or other flammable vapors and liquids in vicinity of this or any other appliance. • A propane cylinder not connected for use shall not be stored in the vicinity of this or any other appliance. WHAT TO DO IF YOU SMELL GAS: • Shut off gas to the appliance. • Extinguish any open flame. • If odor continues, keep away from the appliance and immediately call your gas supplier or fire department. Installation and service must be performed by an NFI Certified or other qualified professional installer, service agency, or gas supplier. WARNING This appliance is designed as an attended appliance. Improper installation, adjustment, alteration, service, Adults must be present when the unit is operating. or maintenance can cause property damage, DO NOT leave this unit burning when unattended. If personal injury, or loss of life. Read the installation, this product is left burning unattended, it may cause operating and maintenance instructions thoroughly damage or serious injury.
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION Congratulations on your purchase of an HomComfort Gas Barrel . Made with pride, your new gas barrel complies with Intertek safety standards and when installed per these instructions and used as intended it will provide warmth and comfort to your outdoor area for many years. Prior to installation and operation ensure that all specifications, dimensions, and minimum clearances stated in this manual are observed. You must read all warnings and safety information, and understand all of the information in this manual.
Page 3: Installation Safety Guidelines
INSTALLATION SAFETY GUIDELINES A. Installation and repair should be done by a qualified professional service technician. The appliance should be inspected before use and at least annually by a qualified service person. More frequent cleaning may be required as necessary. It is imperative that control compartment, burners and circulating air passageways of the appliance are kept clean. B. Carefully inspect for shipping damage. If any parts are damaged, call the dealer. C. WEAR GLOVES AND USE EXTREME CAUTION WHENEVER INSTALLING AND HANDLING THIS PRODUCT AND ITS ACCESSORIES AS CERTAIN COMPONENTS HAVE SHARP EDGES THAT CAN CAUSE PERSONAL INJURY. D. Correct installation and proper placement of the unit and decorative media is crucial to the safe performance of the unit. See installation instructions for further information. E.
Page 4: Safe Use & Maintenance Of Propane Gas Cylinders
SAFE USE & MAINTENANCE OF PROPANE GAS CYLINDERS IMPORTANT FOR YOUR SAFETY READ AND FOLLOW ALL WARNINGS PROVIDED WITH THE PROPANE-GAS CYLINDER. When operating this appliance with a propane-gas cylinder, these instructions and warnings MUST be observed. FAILURE TO DO SO MAY RESULT IN A SERIOUS FIRE OR EXPLOSION. CYLINDER/CONNECTOR REQUIREMENTS a. Propane-gas cylinders, valves, and hoses must be maintained in good condition and must be replaced if there is visible damage to either the cylinder or valve. If the hose is cut or shows excessive abrasion or wear, it must be replaced before using the gas appliance (see e.). b. This unit, when used with a cylinder, should be connected to a standard 5-gallon (20 lb.) propane-gas cylinder equipped with an OPD (Overfill Prevention Device). The OPD has been required on all cylinders sold since October 1 , 1998, to prevent overfilling. c. Cylinder dimensions should be approximately 12” (30.5 mm) in diameter and 18” (45.7 em) high. Cylinders must be constructed and marked in accordance with the Specifications for Propane Gas Cylinders of the U.S. Department of Transportation (D.O.T) or the National Standard of Canada, CAN/CSA-8339, Cylinders, Spheres, and Tubes for Transportation of Dangerous Goods.
Page 5: Specifications And Dimensions
Weight / Pieces L.P. HomComfort Gas Barrel 50,000 21” dia. X 28” h 91lb / 1 pc Follow the recommendations below for decorative media amounts. All decorative media options are purchased separately. Contact your local U. S. Stove dealer when ordering. 18” When using glass media: Gas Barrel Style(s) Recommended Amount of Glass HCGB1 13 lbs 21” 28” MINIMUM CLEARANCES TO COMBUSTIBLES The dimensions shown below are MINIMUM CLEARANCES to maintain when you install the unit. ALL CLEARANCES AND INFORMATION STATED HERE MUST BE MAINTAINED AND FOLLOWED. 72” 24” 24” side clearance...
Page 6: Before You Begin
IMPORTANT SAFETY INFORMATION CAUTION: Installation and maintenance must be done by an NFI Certified or other qualified professional service technician. Read these instructions before installing this unit. Be sure you understand all safety precautions and warnings contained in this manual. A. FOR OUTDOOR USE ONLY. B. When shutting the unit down-be sure to TURN THE CONTROL VALVE FULLY OFF. C. WARNING: CARBON MONOXIDE POISONING MAY LEAD TO DEATH. DO NOT MODIFY THIS unit OR ITS CONTROLS, EXCEPT AS PROVIDED FOR IN THIS MANUAL. Any other change may be dangerous. Improper installation or use of the unit can cause serious injury or death from fire, burns, explosions, or carbon monoxide poisoning.
Page 7: Installation
INSTALLATION A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a propane cylinder with a damage valve connection. The propane cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S Department of Transportation (DOT) or the standard for cylinders, spheres and tubes for transportation of dangerous goods and commission, CAN/CSA-B339. The cylinder must have a listed overfilling prevention device. The cylinder must have a connection device compatible with the connection for the appliance. The cylinder used must include a collar to protect the cylinder valve. Never connect an unregulated propane cylinder to the heater. Attach regulator to cylinder. Complete attachment. Install the cylinder. • Do not store a spare LP-gas clinder under or near this appliance; • Never fill the cylinder beyond 80 percent full; • Place the dust cap on the cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve that is provided with the cylinder valve. Other type of caps or plugs may result in leakage of propane.
Page 8: Before Lighting
OPERATION INSTRUCTIONS WARNING: WARNING: Very hot while in operation! Never lean • CARBON MONOXIDE HAZARD over the gas barrel while in use. Do not touch tile • For outdoor use only. Never use inside house, or of spark guard while the gas barrel is in operation, other unventilated or enclosed area. This gas barrel wait until the gas barrel has cooled down after use. consumes air (oxygen). Do not use in unventilated Failure to comply with these instructions may result in or enclosed areas to avoid endangering your life. serious bodily injury.
Page 9: Operation Checklist
OPERATION INSTRUCTIONS WARNING: FOR YOUR SAFETY Be careful when attempting to manually ignite this gas barrel . Holding in the control knob for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. WHEN THE GAS BARREL IS ON The burner will display tongues of blue and yellow flame. These flames should not be yellow or produce thick black smoke, indicating an obstruction of airflow through the burners. The flame should be blue with straight yellow tops. If excessive yellow flame is detected, turn off the heater and consult the “Troubleshooting” section. RE-LIGHTING 1. Turn the control knob to OFF. 2. Repeat the lighting steps in the “Lighting” section of this manual. WARNING: The gas barrel will be hot after use. Handle with extreme care. SHUT DOWN 1. To extinguish the burner depress the control knob and continue to turn it clockwise to “OFF”. 2. Turn the cylinder valve clockwise to “OFF” and disconnect the regulator when the heater is not in use. OPERATION CHECKLIST For safe and pleasurable heating experience, perform this check before each use.
Page 10: Care And Maintenance
CARE AND MAINTENANCE To enjoy years of outstanding performance from your gas barrel, make sure you perform the following maintenance activities on a regular basis: Keep exterior surfaces clean. 1. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents. 2. While cleaning your unit, be sure to keep the area around the burner dry at all times. Do not submerge the control valve assembly. If the gas control is submerged in water, do NOT use it. It must be replaced. a. Keep the appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
Page 11: Servicing And Cleaning
SERVICING AND CLEANING Each installation site for any unit presents its own unique combustion environment. Specific factors such as weather, wind currents, yard debris, altitude, drafts, the size of the surrounding area, all have an influence on the proper operation of the unit. A normally operating unit will demonstrate the following characteristics: • A lively, realistic yellow flame • Odor-free If the flame is not clean (identifiable by excessive sooting on the decorative media), refer to the information below. Some soot on the media may occur and should not be a concern unless excessive. • Cover your unit whenever it is not in use, and follow the guidelines below at least annually. ANNUAL CLEAN /INSPECTION GUIDELINES The unit and the installation must be inspected annually. Refer to these instructions for details. Performing these procedures will ensure proper operation, appearance, and safety. WEAR GLOVES. If maintenance is required, it must be done by a qualified professional service technician. • Always shut off the gas to the unit while performing service work. • Allow the unit to cool before servicing. • The entire burner system should be inspected regularly: Excessive debris can build up on this unit from leaves, dirt, or other debris. It is critical that all control components, burners, vent openings, and the surrounding area be kept clean and free of all obstructions.
Page 12: Troubleshooting
TROUBLESHOOTING If you have trouble with your unit, please use this list to identify the problem. By trying one or more of the solutions to the probable cause, you should be able to solve the problem. lf this list does not address your present problem, or if you have other technical difficulties with your unit, please contact your local dealer or visit our web site at www.usstove.com Problem Possible Cause Corrective Action Wait until the propane cylinder warms Propane cylinder is frosted over up and becomes unfrosted Burner won’t light Blockage in orifice Clear blockage Control knob is not in “ON” position Turn control knob to “ON” Turn cylinder valve “OFF” and replace Gas pressure is low cylinder Burner flame is low Outdoor temperature is less than 40°F Use a full cylinder and tank is less than 1/4 full Control knob is fully on Check burner and orifices for blockage Dirt or film on reflector and the burner Clean reflector and burner screen screen Carbon build-up / Thick black smoke Remove blockage and clean the Blockage in burner burner inside and outside.
Page 13: Replacement Parts List
REPLACEMENT PARTS LIST • In addition to the Replacement Parts List, reference the identification parts list. • Your gas barrel is packaged onto 1 pallet. • Decorative media is purchased and packaged separately. Various styles are available. • Decorative media and replacement parts can be ordered from your local U. S. Stove dealer. • Select models are illustrated (your model may vary) Item Part No. Description 81257 Burner Ring 81258 Orifice 2.1mm 81259 Main Gas Line 81260 Ignitor Cover 81262 Ignitor Box 81263 Ignitor Knob 81264 Valve Knob 81265 Ignitor 81269 Thermopile 81261 Main Gas Valve 81266 Upper Ring 81267 Lower Ring 81268 LP Gas Hose/Regulator 892729...
Page 14: Year Limited Warranty
1 YEAR LIMITED WARRANTY All components are warranted for a period of 1 year after date of purchase by the original owner against defects in materials and workmanship under normal use. This warranty does not cover normal wear and weathering, assembly and \or maintenance or use in commercial application if model is not designated as a commercial mode. At USSC’s sole discretion, products under warranty will be repaired and \or replaced at no charge to the customer. Any returns sent back to USSC must be sent via prepaid freight and in the original retail packaging. For warranty service contact USSC at the address, Phone number or web site listed in this owner’s manual. Be sure to have your sales receipt, date of purchase and catalogue/model number available when calling. All warranty service will be coordinated by the USSC service center. This warranty is extended only to the original purchaser. Proof of purchase will be required before warranty service is rendered. The sales receipt is the only valid proof of purchase. This warranty only covers failures due to defects in materials or workmanship which occur during normal use. Failures and\or damage which result from accident, negligence, misuse, abuse, neglect, mishandling alteration or modification, failure to maintain,...
Page 15: Service Record
SERVICE RECORD It is recommended that this unit is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider: Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
Page 16 NOTES...
Page 17 This manual will help you obtain efficient, dependable service from your appliance dealer, and enable you to order repair parts correctly. Keep this manual in a safe place for future reference. When writing, always give the full model number which is on the nameplate attached to the heater. When ordering repair parts, always give the following information as shown in this list / Ce guide vous aidera à obtenir un service efficace et fiable auprès du revendeur de l’appareil et vous permettra de commander correctement des pièces de rechange. Veuillez conserver ce manuel dans un endroit sûr à des fins de référence. Lorsque vous nous écrivez, veuillez indiquer le numéro complet du modèle qui figure sur la plaque signalétique de l’appareil de chauffage. Lorsque vous commandez des pièces de rechange, veuillez toujours fournir les renseignements suivants, tels que montrés dans cette nomenclature: 1. The part number / Le numéro de pièce �� 2. The part description / La description de la pièce �� 3. The model number / Le numéro de modèle �� 4. The serial number / Le numéro de série �� United States Stove Company 227 Industrial Park Road P.O. Box 151 South Pittsburg, TN 37380 (800) 750-2723 WWW.USSTOVE.COM...
