SANISMART PLUS
Automatic Sewage (Toilet) & waste water collection tank and electrically operated macerator pump system.
INSTALLATION AND SERVICING INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS PRIOR TO PROCEEDING WITH ANY WORK
A permit may be required. Check with the plumbing, drainage and/or electrical inspectors before installation.
Local regulations may stipulate additional installation requirements.
You must consult with your local plumbing and drainage inspector for a permit approval.
AFTER INSTALLATION, THE INSTALLER MUST HAND THIS MANUAL TO THE OWNER
FOR THE PROPER OPERATION AND MAINTENANCE OF THE SANISMART PLUS UNIT
Failure to do so will result in the installer being made liable under the current legislation for any future claims
resulting from any malfunction of unit, damage to property or person, incorrect operation or servicing.
Congratulations on your purchase of Sanismart Plus wastewater package pump. For this product to meet
its expected lifetime please ensure it is installed by a qualified technician and follow the maintenance
schedule as detailed in section 12, "Care & Servicing of Unit". Please keep a record of by whom and when
the maintenance was completed, that need to be provided to us when asked for.
PAGE INDEX
Section
2. Shower/Bath waste connection height..........4
3. Product overview.....................................4
4. Applications............................................5
5. Pump hydraulic capability..........................5
6. Features & Benefit........................................6
7. Warning: for your safety.................................6
8. List of fittings supplied..............................6
Limitations: We reserve the right to change these instructions and improve the product without prior notice.
AUCKLAND
PH 09 622 9100
G:\INSTRUCT\Sanismart Plus\Sanismart Plus Instructions.docx 9/9/2020 Page 1
Page no
Section
9. Protection against flooding.........................7
10. General installation & electrical data............9
11. Pump Operational Logic...............................10
12. Care & servicing of unit...........................10
13. Warranty & Limitations ................................11
14. Fault Finding chart .......................................12
15 Spare parts drawing & list..............................14
WELLINGTON
PH 027 543 8634
Page no
CHRISTCHURCH
PH 027 532 9754
Advertisement
Table of Contents
Summary of Contents for Wallace Pumps SANISMART PLUS
-
Page 1: Table Of Contents
Congratulations on your purchase of Sanismart Plus wastewater package pump. For this product to meet its expected lifetime please ensure it is installed by a qualified technician and follow the maintenance schedule as detailed in section 12, “Care &... -
Page 2: Dimensions, General View & Connections
G:\INSTRUCT\Sanismart Plus\Sanismart Plus Instructions.docx 9/9/2020 Page 2 1. DIMENSIONS, GENERAL VIEW & CONNECTIONS Dimensions: - SANISMART PLUS DIMENSIONS General view & connections: - Cut-away view through the cover showing the dry mounted pump motor unit & circuit board, in a separate chamber provided in the collection tank. - Page 3 G:\INSTRUCT\Sanismart Plus\Sanismart Plus Instructions.docx 9/9/2020 Page 3 NOTE: - The SANISMART PLUS pump unit MUST be installed in dry weatherproof, non-floodable location with easy access for operation, maintenance and repairs. Any damage to pump unit or any other item due to non-compliance of this clause or any other instructions in this manual is not covered under warranty.
-
Page 4: Shower/Bath Waste Connection Height
Refer schematic drawing below. When pump & shower and/or bath are in same room, the advised minimum height of the shower tray waste discharge point is 180 mm above the SANISMART PLUS floor level. The final height is determined by starting from the SANISMART PLUS Bottom inlet connection centreline and work back to the shower tray discharge point at the minimum pipe fall rate as per building &... -
Page 5: Applications
-This graph below is based on a flow of 35 litres /min. If flows exceed 35 L/min please contact Wallace Pumps for assessment. -Measure the overall height of the delivery pipework (from the bottom of the tank to the highest point in the delivery line, also referred to as Static Head). -
Page 6: Features & Benefit
Flexible arrangement to suit site conditions 7. WARNING: FOR YOUR SAFETY 230V, 50Hz, 1Ph power supply to Sanismart Plus pump must be through a residual current device (RCD) as per current regulations. This power supply must have isolator and suitable overload/surge protection. -
Page 7: Protection Against Flooding
To avoid such overflow & damage to any property or person and for health and safety reasons, following steps must be followed. Wallace pumps is in no way liable for any damages that may occurred due... - Page 8 A: - Installer must provide an overflow relief pipe plumbed & delivered to a safe and visible area. B: - Wallace pumps offers an “Alarm system with water supply shut off via solenoid valve/s to amenities producing waste water”. With our experience & feedback, installation of such system can help avoiding flooding, though it is not guaranteed.
-
Page 9: General Installation & Electrical Data
7. It is important from a health and safety reason and for the protection of property, that an overflow relief pipe is plumbed and delivered to a safe and visible area in the event that the discharge flows into the SANISMART PLUS exceed the pump hydraulic performance capability or caused by a mechanical failure or a pipe blockage. -
Page 10: Pump Operational Logic
To Re-set the alarm mode, Press the reset button on top of the main lid to re-start operating normally. 12. CARE AND SERVICING OF YOUR UNIT Protect the Sanismart Plus unit from weather or flooding or frost. Any damage to unit due to no protection is not covered under warranty. -
Page 11: Warranty & Limitations
OR splashing of water due to washing, cleaning of surface area where unit is installed OR due to any other reason, is NOT COVERED UNDER WARRANTY. 230V, 50Hz, 1Ph power supply to Sanismart Plus pump must be through a residual current device (RCD) as per current regulations. This power supply must have isolator and suitable overload/surge protection. -
Page 12: Fault Finding Chart
G:\INSTRUCT\Sanismart Plus\Sanismart Plus Instructions.docx 9/9/2020 Page 12 14. Fault Finding Chart NOTE:- Within the warranty period, any work not described in this manual must be carried out by Wallace Pumps Service Agents, otherwise your warranty and the product's durability period will be invalidated. - Page 13 G:\INSTRUCT\Sanismart Plus\Sanismart Plus Instructions.docx 9/9/2020 Page 13 Pump runs and Solid object is in the tank or in the pump Clear the obstruction. makes a rattling and will not pass through the delivery. noise. Unit smells. -Inadequate water leading to clogged -Flush unit out with a bleach solution and up/dirty unit.
-
Page 14: Spare Parts Drawing & List
G:\INSTRUCT\Sanismart Plus\Sanismart Plus Instructions.docx 9/9/2020 Page 14 15. Spare Parts drawing & list Pump unit Description Final delivery Elbow with NRV Lid over inside tank with Pump Motor unit Inside tank to house Pump Motor unit Rubber gasket seal Outside main collection tank.
