Summary of Contents for MicroP HALLEY Series
- Page 1 OPERATION MANUAL HALLEY series Technology makes Halley more brilliant High-speed Air Turbine Handpiece A001/A002/A003/A004/A005/A006/A007/A008/A009/A010/A011/A012/A013/ A014/A015/A016/A017/A018/A019/A020/A021/A022/A023/A024/A025/A026/ A027/A028/A029/A030/A031/A032/A033/A034/A035/A036/A037/A038/A039...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction......................................3 1.1. Safety Information....................................4 2. Product Description....................................6 2.1. Symbol.........................................9 2.2. Spare Parts & Consumables................................10 2.3. Troubleshooting....................................2.3.1. Replacing O-rings................................... 2.3.2. Replacing the Bulb..................................2.4. Specifications....................................3. Operation......................................3.1. Connection/Disconnection of the Coupling............................. 3.2. Insertiion/Removal of the Bur................................18 3.3. - Page 3 3.4.2. Preparation Before Cleaning................................21 3.4.3. Manual Cleaning ....................................23 3.4.4. Automated Cleaning..................................25 3.4.5. Manual Disinfection..................................26 3.4.6. Automated Disinfection.................................26 3.4.7. Drying Check Before Lubrication..............................27 3.4.8. Manual Lubrication..................................28 3.4.9. Machine Lubrication..................................31 3.4.10. Inspection.....................................31 3.4.11. Packaging......................................32 3.4.12. Sterilization....................................32 3.4.13. Drying After Sterilization................................33 3.4.14. Storage......................................33 3.4.15.
-
Page 4: Introduction
1.Introduction The dental handpieces are intended to be used by licensed dental professionals for dental Intend Use treatment such as removing carious material and excess filling material, preparing cavity and crown, finishing tooth preparations and restorations. Contraindications None known. Limitations for Use The following conditions need to be evaluated on-site by a qualified dentist before use. -
Page 5: Safety Information
1.1 Safety Information Class Degree of risk Hazard that could result in serious injury or damage to the device if the safety instructions are not WARNING correctly followed Hazard that could result in light or moderate injury or damage to the device if the safety instructions are CAUTION not correctly followed CAUTION... - Page 6 WARNING • Always inspect for bent or damaged burs before each use. A bent bur may whip severely and could be propelled with great force causing injury. DO NOT use excessive force on any bur or blade. • DO NOT attempt to straighten a bent bur. •...
-
Page 7: Product Description
2. Product Description TORQUE The reference number and head size can be found on the sleeve of the handpiece. A015 M4/B2/KaVo/NSK-QDJ/Sirona with/without light REF: A001/A002/A003/A004/A005/A006/A013/A014/A015/A016/A017/ A018/A019/ A020/A021/A022/A023/A024/A031/A032/A033/A034/A035/A036/A037/A038/A039 ① Push button ② Spray ports ③ Light eye (No light eye in non fiber-optic handpiece) ④... - Page 8 NSK-PTL-CL/NSK-FM-CL with/without light REF: A007/A008/A009/A010/A011/A012 ① Push button ② Spray ports ③ Light eye (No light eye in non fiber-optic handpiece) ④ Grip profile ⑤ Sleeve ⑥ O-rings ⑦ Cleaning wire...
- Page 9 W&H with/without light REF: A025/A026/A027/A028/A029/A030 ① Push button ② Spray ports ③ Light eye (No light eye in non fiber-optic handpiece) ④ Grip profile ⑤ Sleeve ⑥ LED bulb ⑦ Cleaning wire...
-
Page 10: Symbol
2.1 Symbol Sterilizable in a steam sterilizer Manufacturer (autoclave) at the temperature specified Date of manufacture Reference number Serial Number Washer-disinfector for thermal disinfection Do not dispose of with domestic waste Prescription use only Consult instructions for use... -
Page 11: Spare Parts & Consumables
2.2 Spare Parts & Consumables Use only original MicroP parts or parts approved by MicroP. Tip Nozzle Spray Nozzle REF. Handpiece REF. REF. Handpiece REF. AHLN002 A001/A002/A003/A031/A032/A033 AHLN001 A001 - A039 (All) AHLN003 A004/A005/A006 LED Bulb AHLN004 A007/A008/A009/A010/A011/A012 REF. Handpiece REF. -
Page 12: Troubleshooting
2.3 Troubleshooting 2.3.1 Replacing O-rings Replace the O-rings if water is present in the exhaust air line. This is an indication of possible water leakage within the coupling. ALWAYS change the complete set of O-rings. 1) Loosen and remove the Sleeve at the rear of the handpiece. 2) Gently remove each O-ring by hand. -
Page 13: Replacing The Bulb
2.3.2 Replacing the Bulb For W&H with light models REF: A025/A026/A027 1) Unscrew the Sleeve. 2) Remove the defective bulb with thumb and forefinger or tweezers. 3) Push bulb carefully into the lamp holder. 4) Screw the Sleeve lightly again. -
Page 14: Specifications
2.4 Specifications Model Mini Standard Torque Rotation Speed 330,000~390,000 rpm 310,000~370,000 rpm Bur Type EN ISO 1797 Ø1.59 ~ 1.60 mm Standard Bur Max. Bur Length 21 mm Max. Working Part Diameter Ø2 mm Recommended Drive Air Pressure 0.28 MPa Operating Drive Air Pressure Range 0.25~0.3 MPa Max. -
Page 15: Operation
3. Operation 3.1 Connection/Disconnection of the coupling For NSK-PTL-CL/NSK-FM-CL/W&H connections REF: A007/A008/A009/A010/A011/A012/A025/A026/A027/A028/A029/A030 CONNECTION 1) Insert the handpiece into the Coupling. 2) Make sure the handpiece is firmly connected to the Coupling. DISCONNECTION Slide back the connector ring, and the handpiece pops out. CAUTION •... - Page 16 For NSK-QDJ connections REF: A004/A005/A006 CONNECTION 1) Slide back the connector ring and insert the handpiece into the Coupling. 2) Release the connector ring. Make sure the handpiece is firmly connected to the Coupling. DISCONNECTION Slide back the connector ring, and the handpiece pops out. CAUTION •...
- Page 17 For KaVo/Sirona/Star connections REF: A013/A014/A015/A016/A017/A018/A019/A020/A021/A022/A023/ A024/ A034/A035/A036/A037/A038/A039 CONNECTION 1) Insert the handpiece into the Coupling. 2) Make sure the handpiece is firmly connected to the Coupling. DISCONNECTION Remove the Coupling by exerting axial direction. kaVo Sirona CAUTION Star • DO NOT slide back the connector ring while the handpiece is under air pressure.
- Page 18 For M4/B2 connections REF: A001/A002/A003/A031/A032/A033 CONNECTION 1) Insert the handpiece with BC/RM connection into the apertures of the turbine hose. 2) Firmly screw the union nut on. 3) Check for leaks at the handpiece. DISCONNECTION Unscrew the union nut and remove the handpiece from the turbine hose.
-
Page 19: Insertiion/Removal Of The Bur
3.2 Insertion/Removal of the Bur To insert the rotary instrument Insert STEP 1 Insert the bur. STEP 2 Press the Push Button. STEP 3 Insert the bur fully into the deepest end, and then release the Push Button. STEP 4 Ensure that the rotary instrument is firmly secured by gently push the bur. To remove the rotary instrument STEP 5 Press the Push Button and remove the bur. -
Page 20: Check Before Treatment
2) Please check the bur is firmly tightened by gently pulling it. 3) Run the handpiece for 5 seconds and check whether any obvious abnormal vibration, noise and overheating exist. If any abnormalities are found, please do NOT use the handpiece for any treatment and contact MicroP for repair immediately. CAUTION •... -
Page 21: Reprocessing & Maintenance Acording To En Iso 17664:2017
3.4 Reprocessing & Maintenance According to EN ISO 17664:2017 Limitations and Restrictions on Processing The product lifetime and the ability for successful operation are mainly determined by mechanical stress during use and the heat and chemical influences due to reprocessing. Reprocessing limitation: approximately 250 times maximum. -
Page 22: Preparation Before Cleaning
3.4.2 Preparation Before Cleaning DANGER The handpieces should be cleaned, disinfected, lubricated and sterilized immediately after treatment. If the handpieces are not properly maintained, it may go overheating and cause burns or mulfunction of the device. ① ② ③ For your safety, please always wear Immediately wipe the handpiece with Remove the bur from the chuck system puncture-resistant and protective... - Page 23 ④ ⑤ After each treatment of patient, Disconnect the handpiece from the tube. run the handpiece for at least 20 seconds air and/or water. SAFE TRANSPORT - Please use closed instrument tray in the process of transportation to other places. CAUTION •...
-
Page 24: Manual Cleaning
3.4.3 Manual Cleaning Please clean the handpiece manually as follows: 1) Rinse under demineralized water (<38° C) with the aid of brush. 2) Remove any liquid residues, debris from clean head holes with cleaning brush. 3) Rotate the handpiece and immerse half of the handpiece head in the cup of water. 4) Rotate then stop intermittently the handpiece 3 times for 2 to 3 seconds each time. - Page 25 Cleaning spray ports Please clean the ports when spray ports are clogged or spray does not exit evenly from the ports. CAUTION • DO NOT forcibly insert the wire into the port. Resultant port damage could cause the spray to be directed away from the bur, and the colling efficiency reduces.
-
Page 26: Automated Cleaning
3.4.4 Automated Cleaning This mark denotes that the product can be automated cleaned and disinfected via a Thermo Washer Disinfector. Automated cleaning with alkaline detergents with a pH-value of max.10 and operating with program "Vario-TD" is recommended. Please use a handpiece holder when washing the handpiece; otherwise any medical agent remains inside the handpiece, it may corrode or clog the air or water pipe, resulting in a malfuction of the handpiece. -
Page 27: Manual Disinfection
3.4.5 Manual Disinfection Manual Disinfection is not aplicable. Please refer to the instructions of 3.4.6 Automated Disinfection for automated disinfection of handpieces. 3.4.6 Automated Disinfection Automated disinfection using a Thermal Washer Disinfector in accordance with EN ISO 15883-1 under 90 to 95°C, and holding time ≥... -
Page 28: Drying Check Before Lubrication
3.4.7 Drying Check Before Lubrication Please check the handpiece is completely dry after disinfection. Use compressed air (Max. 3 bar) to blow dry the handpiece internal until there is no liquid coming out, and make sure that the handpiece is completely dry before lubrication. CAUTION •... -
Page 29: Manual Lubrication
3.4.8 Manual Lubrication Internal Lubrication Clean, disinfect, lubricate and sterilize the handpieces after the treatment of each patient. After cleaning and disinfection, maintain the product as follows. Lack of maintenance could cause premature failure or overheating of the handpiece. Supply oil spray or lubrication oil after each use and before autoclaving. 1) Remove the bur from the handpiece 2) Insert the Spray Nozzle into the spray port nozzle on the can. - Page 30 Spray Nozzle Spray Nozzle Spray Nozzle A001/A002/A003 A013/A014/A015/ A007/A008/A009/ A004/A005/A006 A019/A020/A021/ A025/A026/A027/ A034/A035/A036/ A031/A032/A033 A016/A017/A018 A010/A011/A012 A022/A023/A024 A028/A029/A030 A037/A038/A039...
- Page 31 Chuck Lubrication Clean the Push Button chuck once a week. 1) Mount the Tip Nozzle into the spray port nozzle on the can. Tip Nozzle 2) Lubricate the chuck directly through the bur insertion hole. CAUTION • If the chuck is not regularly cleaned, the chuck grip may be weakened and the bur may be accidentally released while in operation.
-
Page 32: Machine Lubrication
3.4.9 Machine Lubrication Manual Machine Manual with oil spray or oil machine like the following pictures. When using the oil machine, please observe the following note: Manually maintain high-speed handpieces with oil spray immediately after use. CAUTION • Measures to maintain/lubricate the transfer instrument must be made AFTER each cleaning and disinfecting process and before each sterilization. -
Page 33: Packaging
3.4.11 Packaging The handpiece must be individually sealed in a sterilization bag. A standard sterilization pouch according to ISO 11607-1 must be used. Ensure that the pouch is large enough to contain the handpiece without stressing the seals. 3.4.12 Sterilization Sterilization is required before first use and after each use. -
Page 34: Drying After Sterilization
3.4.13 Drying After Sterilization Please dry the handpiece for at least 30 minutes using the sterilization dry cycle and allow the handpiece to cool to room temperature in pouch prior to use. If moisture is present, increase your sterilization dry cycle appropriately. CAUTION •... -
Page 35: Periodical Maintenance Checks
3.6 Periodical Maintenance Checks Please perform periodical maintenance checks monthly referring to the checkpoints below. If any abnormalities are found, please do NOT use the handpiece and contact MicroP for repair immediately. Checkpoints Details Appearance Check the handpiece head and body to see if there is any crush or damages. -
Page 36: Disposing Products
4. Disposing Products Disposal of the Medical Devices In order to avoid the health risks of operators handling the disposal of medical devices, as well as the risks of environmental contamination, please do not dispose of the medical devices with domestic waste. Please follow your country-specific laws, directives, and guidelines for the disposal of used medical devices and make sure that they are disinfected or sterilized before disposal. - Page 37 A001/A002/A003 For M4 Fixed Connection A004/A005/A006 For NSK® QD-J® Coupling NSK® QD-J® is registered trademarks of Nakanishi Inc. A007/A008/A009/A010/A011/A012 For NSK® Phatelus/Mach® Coupling NSK Phatelus/Mach® are registered trademarks of Nakanishi Inc. A013/A014/A015/A016/A017/A018 For KaVo® MUTIflex® ,MUTIflex LUX® Coupling KaVo® and MUTIflex® are registered trademarks of Kaltenbach & Voigt GmbH & Co. A019/A020/A021/A022/A023/A024 For Dentsply Sirona®...
- Page 38 MicroP Technology (Taiwan), Inc. No. 50, Zhongxiao 2nd St., East Dist., Chiayi City 600, Taiwan (R.O.C.) 202007HS-US-V.7 Tel +886-5-2768238 Fax +886-5-2768272...
