Summary of Contents for AIR GUARD AG-1600
- Page 1 AG-1600 Antibacterial Vaporizer USER MANUAL - ENGLISH...
-
Page 3: Safety Information
If the machine fails to work, unplug the machine and stop operation immediately. Contact your local dealer for advice . Before transporting the machine, make sure the fluid tank is completely drained. Do not drink Air Guard solution. Store it securely. In case of eye contact, immediately look for medical advice. -
Page 4: Unpacking And Inspection
If any parts appear damaged or mishandled from shipping, notify the shipper immediately and retain the packing material for inspection. What are included: 1 x AG-1600 Antibacterial Vaporizer 1 x Wireless Remote Control 1 x Power Cord 1 x User Manual... -
Page 5: Product Overview
2 meters for the output direction of the machine. Step 2: Fill the fluid tank with Air Guard fluid. Step 3: Connect the machine to suitably rated power supply. To determine the power requirement for the machine refer to the label on the back of the machine. -
Page 6: Timer Mode
The date format is YYYY/MM/DD. The time format is HH:MM:SS. The AG-1600 has a built-in clock and calendar. It is important to have an accurate clock setting to ensure proper operation of the schedule application. To adjust the date and/or time displayed, on the main menu page (Date/Time page), press and hold the MENU button for 3 seconds to enter the date/time setting mode. -
Page 7: Schedule Mode
Together the three different settings provide for an extremely flexible fogging cycle, for example: If you wish the AG-1600 to fog for 5 minutes every 30 minutes, three times, set the Waiting Time to 30:00 , the Fogging Time to 05:00, and the Cycle Duration to 3. - Page 8 Once you have finished your selection press the STOP button once to confirm and save the settings. *Start Time – is the time of day the AG-1600 will begin to fog. This setting is displayed in 24 hour time and can be adjusted between 00:00 and 23:59 by using the ▲ (UP/TIMER) and ▼...
-
Page 9: Wireless Remote Control Operation
NOTE: At the end of a scheduled cycle, the AG-1600 will automatically go into stand-by mode in three minutes, shutting down the heater and display to conserve power. Wireless Remote setting: The AG-1600 wireless remote function can be turned off if necessary. On extremely rare occasions the AG-1600 may encounter wireless interference that will require the built-in wireless function to be switched off. -
Page 10: Service And Maintenance
Regularly fill distilled water to fluid tank and run the machine to clean the system. After ․ cleaning, refill Air Guard fluids into fluid tank and make sure machine can produce fog properly. It is recommended to run the machine on a monthly basis in order to achieve best ․... -
Page 11: Technical Specifications
6 minutes (approx.) - Maximum Fluid consumption 40 ml/min - Fluid tank capacity 2.4L (0.63gal) - Compatible fluid Air Guard Antibacterial Solution - Ambient temp. range 0 °C - 40 °C (32 °F-104 °F) - Output height 2 meters height - Control... - Page 12 M22 Moisture Co., Ltd. Tel : +886 3 2227470 Fax : +886 3 2227469 www.airguard.com.tw e-mail : sales@airguard.com.tw C08AG1601...
