Alfa Laval Arctigo HRCD
Instruction manual
ORIGINAL INSTRUCTIONS
AHE00062EN 1904
• Product description
• Product labels
• Unpacking & lifting
• Installation
• Maintenance
• Spare parts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Arctigo HRCD 06-I and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alfa Laval Arctigo HRCD 06-I

Summary of Contents for Alfa Laval Arctigo HRCD 06-I

  • Page 1 Alfa Laval Arctigo HRCD Instruction manual • Product description • Product labels • Unpacking & lifting • Installation • Maintenance • Spare parts ORIGINAL INSTRUCTIONS AHE00062EN 1904...

  • Page 2: Table Of Contents

    Coil heater replacement for units with Cu tubing..............12 Coil heater replacement for units with SS tubing ..............13 Spare parts..........................14 AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 3: Important Information

    Important information Disclaimer This Instruction Manual applies to all Alfa Laval Arctigo HRCD air cooler products and is supplied in combination with the Alfa Laval Air Cooler Product Manual AHE00042. Both manuals must be carefully examined and instructions should be followed up at all times. Alfa Laval does not accept liability for any damage resulting from non-compliance to the instructions as given in the manuals and order-related documents.

  • Page 4: Product Description Arctigo Hrcd

    Banana ripening cooler airbag/side curtain system Maximum number of pallets in ripening room Number of pallet layers AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 5: Product Labels

    Date on which the coil has TO AVOID INJURIES OR DAMAGE been pressure tested in the factory AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.
  • Page 6 BAUTEILE IN BETRIEB. VOR ARBEITSBEGINN SPANNUNG UNTERBRECHEN ÉLÉMENTS INTERNES A DÉMARRAGE AUTOMATIQUE. COUPER L’ALIMENTATION ÉLECTRIQUE AVANT INTERVENTION AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 7: Unpacking And Lifting

    Installation"After having secured the cooler, the forks may be lowered and the remaining packag- ing materials shall be removed. AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 8: Installation

    3 x 6 = 18 24-III 4 x 6 = 24 30-III 5 x 6 = 30 6000 AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 9: Mounting Bracket

    Tighten drain connection by hand only. Units are designed such that drains can be con- nected in parallel. AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 10: Electrical Installation

    Electrical options Standard electrical connections 1-5 fan motors 3 phase AC 6x 1.5 mm2 AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 11: Maintenance

    Restore electrical connections when the new fan has been mounted. AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 12: Driptrays

    Mount new element in reverse order and restore electrical connec- tions. AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 13: Coil Heater Replacement For Units With Ss Tubing

    Pull the heater out from the coil. Mount new element in reverse order and restore electri- cal connections. AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB. Alfa Laval reserves the right to change specification without prior notification.

  • Page 14: Spare Parts

    Complete fan Lights cover (bulbs available on request) Electrical defrost element Spare parts can be selected and ordered in the online eBusiness tool Alfa Laval Anytime. If required please contact your local Alfa Laval representative for assistance. Alfa Laval Anytime AHE00062EN 1904 Alfa Laval is a trademark registered and owned by Alfa Laval Corporate AB.
