- Page 1 FF-700/600 User’s Guide 2020...
-
Page 2: Table Of Contents
Contents 1. Fantom Electric Bike Main Parts Diagram ..................3 2.Fantom Electronic Control System Diagram ..................4 3.Riding Safely ............................5 4.Safe Use of Fantom Electric Bikes ....................... 5 4.1.Electric Bike ..........................6 4.2.Lithium-Ion Battery ........................6 4.3.Controller ............................7 4.4.Motor ............................ -
Page 3: Fantom Electric Bike Main Parts Diagram
FF-700/600 APOLLO KAMARO RINGO FF-700 FF-700 FF-700 TORPIDO DELTA BLUE MOON FF-600 FF-600 FF-600 1. Fantom Electric Bike Main Parts Diagram... -
Page 4: Fantom Electronic Control System Diagram
2.Fantom Electronic Control System Diagram Speed up to 15.5 mph Throttle Range from 25 to 55 miles Cruise control Hydraulic brake with two clamps and electric sensor... -
Page 5: Riding Safely
✓ Do not allow children to play with the product. ✓ Use only batteries and chargers provided by Fantom. Use of other batteries may cause injury and risk of fire. ✓ Do not dispose the batteries into a fire. -
Page 6: Electric Bike
✓ The charger might get hot. Do not place the charger on floor coverings such as carpets, rugs etc. ✓ Do not immerse the battery or charger in water. Do not use it during rain. ✓ Do not charge the battery for more than 24 hours without a break. ✓... -
Page 7: Controller
✓ The battery can self-discharge even when not being used. Due to that, it is recommended to check the battery level at least once a month. 4.3.Controller ✓ Make sure to protect the controller against rain and water as it can damage the component. -
Page 8: How To Start Riding
5.How to Start Riding... -
Page 9: Fantom Electric Bike Characteristics
6.Fantom Electric Bike Characteristics Operating temperature range during -20°C to 60°C discharging Operating temperature range during 0°C to 45°C charging Storage temperature (battery) -20°C to 45°C Humidity (storage) Up to 80% Charging voltage 100V to 240VAC Charging time Around 6 hours... -
Page 10: Lithium-Ion Battery
This process is called battery formation. ✓ Although the Fantom bicycle is water resistant, do not use high pressure washers as this may damage the drive or power system of the bicycle. Heavy, torrential rain can cause similar damage. -
Page 11: Basic Information
7.1.Basic Information ➢ The battery is equipped with original Lithium-ion cells type: Samsung 18650 35E and LG 18650 E26. ➢ Branded battery cells’ life is over 1000 charging and discharging cycles. ➢ Batteries provided are equipped with: ✓ BMS (Battery Management System). BMS systems are applied to enable each battery cell to function as long as possible, be reliable and stable and to offer high performance and the highest level of security. -
Page 12: Correct Use And Storage
✓ It is recommended that you always discharge the battery completely and then fully charge it. 7.3.Battery charger ✓ Use only Fantom’s batteries and chargers in the bicycle. Use of other batteries may cause injury and risk of fire. We do not accept any liability or warranty for other batteries. -
Page 13: Safe Assembly And Disassembly Onto Bike
7.4.Safe Assembly and Disassembly onto Bike ➢ Battery Assembly ✓ Slide the battery downwards into the bottom slot following the rail. ✓ Lock the battery lock with the key. ➢ Battery Disassembly ✓ Open the battery lock with the key. ✓... -
Page 14: Charging The Battery
7.5.Charging the Battery ➢ Charging the Battery ➢ Alternative Charging... - Page 15 ➢ Battery Charge Indicator ✓ After pressing the control button, the control diodes will light up showing the approximate value of the battery charge. ✓ When only red light is showing, it is necessary to charge the battery as soon as possible.
-
Page 16: Display
8.Display... -
Page 17: Turning The Bike On/Off
9.Turning the Bike On/Off 10.Choosing Riding Mode 1. Riding bike in WALK mode ✓ WALK mode can only be turned on when the bike is not moving. ✓ Do not activate this mode during the ride. ✓ Speed of bike does not exceed 4 mph. ✓... -
Page 18: Basic Display Controls
11.Basic Display Controls 11.1.Screen Brightness ✓ Press the ∧ ∨ buttons on the control switch simultaneously and hold for 2 seconds to swap between settings P01 to P20. ✓ Choose the correct setting and wait 5 seconds for the program to load. -
Page 19: Assistance Mode (Pas) Display
11.2.Assistance Mode (PAS) Display 11.3.Route Information Settings ➢ Reset ODO Distance... -
Page 20: Battery Range
12.Battery Range Battery range shown below for fully charged Lithium-ion battery. Battery range shown below when using assistance mode. The above data is based on a speed of 12.4 mph on a level road at 15°C - 20°C. ➢ Factors affecting range of the distance: ✓... -
Page 21: Smart Lighting System
13.Smart Lighting System Smart lighting - the intelligent lighting system has turn signals (left, right), emergency light, stop light, front and rear lights. Everything works thanks to the SMART switch with LED.
