- Page 1 ThermoFLUX d.o.o. , Bage br. 3 , 70101 Jajce, Bosnia and Herzegovina, Tel: 030-657-100 Web: www.thermoflux.ba E-mail: tfinfo@thermoflux.ba Wi-Fi module MANUAL...
-
Page 3: Table Of Contents
Content Content Content ..................................3 Notes ..................................... 4 Instructions notes ..............................4 Warning signs ................................4 Wi-Fi modul ................................... 5 Description ................................5 Technical data ................................5 Wi-Fi equipment ............................... 6 Meaning of icons ............................... 6 Connection procedure ..............................7 Connect .................................. -
Page 4: Notes
ThermoFLUX d.o.o. before any copying, storage in data systems and transmission by electronic, mechanical or any other form. ThermoFLUX d.o.o. constantly develops and improves its products, so we reserve the right to make changes to the information and technical details contained in this manual without prior notice. ... -
Page 5: Wi-Fi Modul
The Wi-Fi module case is made of plastic (PVC) with a label with the description of the device, version and on the back there is a label with a QR code for reading the MAC address. The Wi-Fi module has connectors for power supply and for the connection with the boiler or stove. -
Page 6: Wi-Fi Equipment
Wi-Fi equipment SERIAL, 4pin, male-male cable (fig. 2.) SERIAL-DSUB 9-4pin, female-male cable (fig. 4.) Power supply 220/12 V AC/DC, 1000mA (fig. 3.) Velcro (fig. 1.) Figure 1. Figure 2., Figure 3., Figure 4. NOTE The support power supply suplied in the kit comlies with the EN 60950-1 directive, and has the following characteristics: ... -
Page 7: Connection Procedure
Figure 5. SERIAL cable and boiler mainboard connection Figure 6. SERIAL cable and Wi-Fi module connection Supply the Wi-Fi module with the support power supply. The device is powered if the green Power LED is on. Figure 7. Power supply for Wi-Fi module... -
Page 8: User Registration Procedure
User registration procedure Download and install the ''Nina'' app from Google Play or Apple Store. 1. Open the application and proceed with registration (written ''Subscribe'') by entering the following: Email adress; Dedicated password for the application (minimum 8 charecters) ... -
Page 9: Wi-Fi Configuration
Wi-Fi configuration Configuration procedure 1. Supply the Wi-Fi module with the support power supply and connect it to the stove or biomass boiler using serial cable supplied. Verify that the Wi-FI module is connected end powered (green power LED on). -
Page 10: Eu Label
EU LABEL The radio equipment (in this manual) complies with the following directives: RED 2014/53/EU; ROHS 2011/65/EC; WEEE 2012/19/EU. - Page 12 ThermoFLUX d.o.o. Bage br.3, Jajce Bosna i Hercegovina Tel/fax +387-30-657-100 www.thermoflux.ba...
