Trader PMBUSW Instructions

Home Automation made simple.
1
Wiring configuration
Choose the configuration that
best suits your installation.
See options A, B, C overleaf.
3
Download the Zimi App
Available free from the
App store or Google Play.
5
Setup the device
Zimi will guide you through
the network setup process.
Add device with connected
load first.
Powermesh status indicator
BLUE
WHITE
WHITE
PULSING
BLUE/WHITE Direct connection. This identifies the device when changing
PULSING
RED
Need some help?
WARNING - Read before installing
Powermesh devices must only be connected with the
Active and Neutral from the same RCD.
SURGE PROTECTION It is strongly recommended to have a surge protection device
installed at the main switchboard. Products that are damaged by power surges are not
covered by warranty.
MULTI-WAY SWITCHING The Powermesh Multi Purpose Switch SHOULD NOT
be wired with normal switches for multi-way switching. Please follow the
wiring instructions.
FACTORY RESET If you are having problems with your device, please RESET it.
Remove the face plate and depress the RESET button until the indicator changes colour.
Allow at least a minute for the device to be ready.
Specifications
Part No:
PMBUSW
Multi Purpose Switch, 1 Button, 3 Wire
Rated Load
Maximum Load 10AX 240V ~ / 2400W
Line Voltage Frequency
50Hz Nominal
Get connected now
in just a few steps.
Ready to join a network. This device is working ready to be
setup. Please choose 'Add device' in Zimi.
Connected to network. This device is working and connected
to a Powermesh network. To setup the device again,
press & hold the RESET button until the logo turns blue.
Automatic schedule. The schedule is about to be activated.
Change or disable device schedules in Zimi.
its settings in Zimi.
Device failure. Try updating the firmware. If unsuccessful,
please contact your installer or supplier.
Please visit www.zimi.life for support.
2
Install the product
This MUST be installed by a
licensed electrician to local
wiring regulations.
4
Connect the device
With Bluetooth on, hold Zimi in
close proximity to the device.
See below for status indicator.
6
Network transfer
Easily handover the
completed network setup
to your customer using the
Mesh & Go feature.
Compatible load types
LED
Incandescent
Fluorescent
CFLs
Electronic
transformers
Standard iron core &
toroidal transformers
Exhaust fans /
small motors
