INSTALLATION AND
OPERATION MANUAL
D-2 Power
Vent
For Sizes 182, 260, 330,
400, Types H and WH –
Boilers & Water Heaters
WARNING: If these instructions are not followed exactly, a fire or explosion may
result causing property damage, personal injury or death
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
liquids or other combustible materials in the vicinity of this or any other appliance. To
do so may result in an explosion or fire.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
This manual should be maintained in legible condition and kept adjacent to the heater or in another safe place for
future reference.
.
Effective: 11-30-2020
Replaces: 06-01-2017
P/N 241086 Rev. 11
Advertisement
Table of Contents
Summary of Contents for Rheem Raypak D-2 182
- Page 1 INSTALLATION AND OPERATION MANUAL D-2 Power Vent For Sizes 182, 260, 330, 400, Types H and WH – Boilers & Water Heaters WARNING: If these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or death FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids or other combustible materials in the vicinity of this or any other appliance.
- Page 2 Revision 11 reflects the following changes: Obsolete models 181, 261, 331 and 401 removed from text, figures and table throughout. Text added to "General Specifications" on page 4. Dimension table moved to page 5. Figures 1 and 2 revised on page 5. "Venting" text revised on page 7. Figure 4 revised on page 8.
-
Page 3: Table Of Contents
CONTENTS 1. WARNINGS ............3 182-260 WH1 (Atmospheric)........9 Pay Attention to these Terms ........3 182-260 H4/W1 (Atmospheric)......10 330-400 H4/WH1 (Atmospheric) ......11 2. RECEIVING EQUIPMENT ........4 8. SEQUENCE OF OPERATION ......12 3. GENERAL SPECIFICATIONS ......4 9. -
Page 4: Receiving Equipment
2. RECEIVING EQUIPMENT NOTE: The D-2 Power Vent comes factory-wired for 120V, but can be field-converted for 240V operation. On receiving your equipment, check the carton visually for See wiring diagrams from page 9. external damage. If the carton is damaged, make a note on the Bill of Lading when signing for the equipment. - Page 5 9. Re-mount the jacket top to its original position and TABS TABS screw in the four screws holding it down to the appliance. REAR 10. If the appliance is a 182 or 330, remove the tabs underneath the power vent using a 5/16" nut driver and relocate them closer to the center of the Power Vent as shown in Figure 1.
- Page 6 Figure 3. Minimum Clearances from Vent/Air Inlet Terminations – Indoor and Outdoor Installations U.S. Installations Canadian Installations Clearance above grade, veranda, porch, 1 ft (30 cm) 1 ft (30 cm) deck, or balcony 4 ft (1.2 m) below or to side Clearance to window or door that may be of opening;...
-
Page 7: Wiring (Iid Ignition)
For appliances installed in extreme cold climate, it is 5. WIRING (IID IGNITION) recommended that: WARNING: Disconnect all electrical power to the 1. The vent be installed with a slight upward slope of not unit before servicing to avoid potential shock injury or more than 1/4"... - Page 8 CAT III VENT, 4", RAYPAK DISCHARGE STAINLESS ELBOW (SUPPLIED VENT ADAPTER FIELD-SUPPLIED WITH D-2) FIELD-SUPPLIED 12" MIN. (30.5 cm) SCREENED FACE LEFT SIDE Note: The 90° elbow must be used as the termination cap. Figure 4. Through-the-Wall Vent The D-2 Power Vent assembly includes a wire harness, shown in Figure 5, which provides quick connections with the respective controls in the heater control box.
-
Page 9: Wiring Diagrams
WIRING DIAGRAMS 182-260 WH1 Note: Use the wiring diagram provided with the heater. -
Page 10: 182-260 H4/W1 (Atmospheric)
182-260 H4/W1... -
Page 11: 330-400 H4/Wh1 (Atmospheric)
330-400 H4/WH1 Note: Use the wiring diagram provided with the heater. -
Page 12: Sequence Of Operation
8. SEQUENCE OF 10. DRAFT PROVING SWITCH OPERATION The draft proving switch insures that the blower is operating. The switch is in the limit circuit and does not On call for heat, the D-2 Power Vent fan (and appliance allow the ignition module to operate unless it is closed. pump) start. -
Page 13: Illustrated Parts List
11. ILLUSTRATED PARTS LIST CAT III VENT, 4" STAINLESS FIELD-SUPPLIED 4" GASKET-TO-GASKET VENT ADAPTER, FIELD-SUPPLIED Call Out Description 182-260 330-400 Relay 008784F 008784F Blower 008156F 008156F 15 Blower Cooling Fan 011549F 011549F 17 Gasket 016000F 016000F NO Pressure Switch 008062F 008135F Elbow 4"-90°... - Page 14 NOTES...
- Page 15 NOTES...
- Page 16 ISO 9001 REGISTERED QUALITY MANAGEMENT SYSTEM Raypak, Inc., 2151 Eastman Avenue, Oxnard, CA 93030 (805) 278-5300 Fax (805) 278-5468 www.raypak.com...
