Summary of Contents for Brinkmann Ranch Fire Pit & Grill
- Page 1 OWNER’S MANUAL ASSEMBLY AND OPERATING INSTRUCTIONS WARNING RETAIN THIS MANUAL FOR READ AND FOLLOW ALL WARNINGS AND FUTURE REFERENCE. INSTRUCTIONS IN THIS MANUAL TO AVOID PERSONAL INJURY OR PROPERTY DAMAGE.
- Page 2 IMPORTANT SAFETY WARNINGS READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR COOKER. • Only use this grill on a hard, level, noncombustible, stable surface (concrete, ground, etc.) capable of supporting the weight of the unit. DO NOT use on wooden or other surfaces that could burn. •...
- Page 3 (Proof of purchase will be required.) PARTS LIST - RANCH FIRE PIT & GRILL: UNLOCK LOCK NOTE: Your Brinkmann Ranch Fire Pit & 1 Crank Shaft 1 Safety Lock with Spacer 1 Safety Lock Bolt 1 Lift Assembly with Safety Pins...
- Page 4 Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard down to protect grill finish and assembly area. Step 1 Place the grill upside down, screw the three legs into leg receptors. Step 2 With the help of a friend, turn the grill upright.
- Page 5 Set screw Safety Lock Nut Safety Pins Pulley Set Screw NOTE: Make sure set screws inside each pulley are clear of center hole before crank shaft is inserted in Step 6. Step 5 Place the cooking grill on flat surface. Insert lift assembly down inside the channels of the cooking grill as illustrated.
- Page 6 Step 9 Lower lift assembly onto grill body. Tighten four Phillips head bolts to secure lift assembly to grill body. YOUR BRINKMANN RANCH FIRE PIT & GRILL IS NOW READY FOR USE. LOCKED UNLOCKED Safety Pin Adjustment Holes...
- Page 7 READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR GRILL. Prior to your first use of the Brinkmann Ranch Fire Pit & Grill, follow the instructions below carefully to cure your grill. Curing your grill will minimize damage to the exterior finish as well as rid the grill of paint odor that can impart unnatural flavors to the first meal prepared on your Brinkmann Ranch Fire Pit &...
-
Page 8: One Year Limited Warranty
The Brinkmann Corporation requires reasonable proof of purchase. Therefore, we strongly recommend that you retain your sales receipt or invoice. To obtain repair or replacement of your Brinkmann Ranch Fire Pit & Grill under the terms of this war- ranty, please call Customer Service Department at 1-800-527-0717 for a Return Authorization Number and further instructions.
