INSTALLATION GUIDE
符合中国《电器电子产品有害物质限制使用管理办法》标示
有毒有害物质或元素
表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
但所有部件都符合欧盟 RoHS 要求。
USB-C 3.1
Side Panel
HDMI
VDG
*Be careful when handling the tempered glass panel.
I/O panel
Front panel
Tempered glass side panels
Vertical and horizontal graphics card Installation
Top panel
Detachable dust filter
PSU mounting plate
3.5"/2.5" drive bays
2.5" drive bays
PWM fans (Pre-installed 120mm*3)
ARGB & PWM fans (Pre-installed 120mm*2)
Remove the panels
Top Panel
Front Panel
Advertisement
Table of Contents
Summary of Contents for AORUS C700 GLASS
- Page 1 I/O panel Front panel Tempered glass side panels Vertical and horizontal graphics card Installation Top panel Detachable dust filter PSU mounting plate 3.5”/2.5” drive bays 2.5” drive bays PWM fans (Pre-installed 120mm*3) ARGB & PWM fans (Pre-installed 120mm*2) INSTALLATION GUIDE Remove the panels USB-C 3.1 Side Panel...
- Page 2 RGB FUSION 2.0 With 16.7M customizable color options and numerous lighting effects, you can choose lighting effects or synchronize with other AORUS devices Please use the included hub (refer the below image) to connect the ARGB and PWM fans. Users can control the RGB & Fan speed on the top I/O panel.
