Vjoy MX10 User Manual

User Manual
Model: MX10
Thanks for purchasing the OBD hud. It can work on most gasoline cars after 2008. In case it
can't work on your car, please contact with us according to the user manual end page
information.

Specification:

Product name: Mirror HUD
Item number: MX10
Unit size:13.1*8*6cm
Connection: OBD2 cable
Speed unit: KMH (this version can not display MPH)
Cable length: 1.8M
Display Content: Speed, Oil consumption, RPM, Voltage, Clock, Coolant temperature.
Special Feature: Mirror lift automatically: Open and Close according to Car's ACC ON / OFF.

Package List:

1 X HUD Main Host
1 X 16-pin OBD cable
1 X Tool
1 X Non-slip mat
1 X Manuel
4 X cable fixer

Operation:

The hud only has one button. But it can be press in single time,
long press in , up press or down press.
Long press in: the device can be ON or OFF.
Of course, the device can be on/ off automatically also
when detect ACC is ON or OFF.)
Up press or down press: the screen angle will adjust.
Single press in: the interface function on the right side will switch between: time clock, RPM,
voltage, and water temperature.
