Model: TK-C4000
Date of Purchase: ___________________
Serial #: TK________________________
INSTALLATION, OPERATOR &
MAINTENANCE MANUAL
Table of Contents
...................................................................................................................................... 2
............................................................................................................................................. 2
..................................................................................................................................................... 5
.................................................................................................................................... 15
.......................................................................................................................................... 15
.......................................................................................................................................... 21
........................................................................................................................................................... 21
SnowClear Installation, Operator & Maintenance Manual
.................................................................................................................................... 8
.............................................................................................................................. 20
Earth & Life Communication
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for ELCOM SnowClear TK-C4000
-
Page 1: Table Of Contents
Earth & Life Communication Model: TK-C4000 Date of Purchase: ___________________ Serial #: TK________________________ INSTALLATION, OPERATOR & MAINTENANCE MANUAL Table of Contents Important Instructions ............................2 Safety Instructions ............................. 2 Specifications ..............................5 Installation Instructions ............................ 8 Operating Instructions ............................ 15 Wiring Instructions ............................ -
Page 2: Important Instructions
CTIONS IMPORTANT INSTRU About This Manual Read all instructions before using this SnowClear Overhead Melter. This manual contains information on the installation, operation and maintenance of the SnowClear Overhead Melter. Before initial operation, read this manual carefully and in its entirety. Equipment owner/operator must ensure that this manual is readily available to the licensed and qualified electrician who is installing the unit. - Page 3 Replace Safety Labels Replace missing or damaged safety labels so that operators are aware of hazards. Replacement signs are available from Trecan Combustion Limited. Maintain the Equipment Ensure that the SnowClear Overhead Melter is maintained as instructed in this manual and is kept in proper working condition.
- Page 4 Outdoor Use Only Only install and use this product outdoors. Extremely hot when in use. Allow hot surfaces to cool before working on or around them. Do not block or cover this product. Also keep flammable materials away from the product to prevent fires. Avoid Hot Surfaces Avoid skin contact with hot surfaces to prevent burns.
-
Page 5: Specifications
SPECIFICATIONS The SnowClear Overhead Melter is a far-infrared, snow melting system. The far-infrared rays radiate from above and accelerate the vibration of snow (water) molecules and the ground below to produce heat energy that melts the snow. Name SnowClear Overhead Melter Model TK-C4000 Power Supply... - Page 6 Heating Element/Halogen Lamp Voltage 208-240VAC Power Consumption 1000 W +7% Rated Life Approximately 3000 hours • The life of the heating element varies depending on the conditions and environment, but the estimated life span is 3000 hours. • Use in a horizontal lighting direction only. •...
- Page 7 Terminal Block and Wiring Guidelines M4 screw/ring terminal Main Unit with Mounting Bracket SnowClear Installation, Operator & Maintenance Manual...
-
Page 8: Installation Instructions
Installation Instructions INSTALLATION INSTRUCTIONS This unit should only be installed by a licensed and qualified electrician in accordance with the relevant electrical code for your area. This unit must be properly installed before it is used. This product does not have an ON/OFF switch and is designed to operate with a snow sensor and controller to switch on when the sensor detects falling snow, and switch off when it... - Page 9 Installation Guidelines Installation Location 1. An outdoor area free from obstructions. 2. If installing under a roof or overhang, ensure there is 3m (10 feet) or more of clearance. 3. Choose an area where there is vehicle height clearance if required. 4.
- Page 10 Installation Height Install the unit 2.5m to 3m (8.2 to 10 feet) above the ground. Installation Angle Adjust the unit in the vertical inclination angle between 0° and 20°. If the unit is to be installed on an incline, ensure that it is installed horizontally without tilting. Correct Incorrect SnowClear Installation, Operator &...
- Page 11 Mount bracket to wall/ceiling/pole between 2.5-3m (8.2-10 feet) above the ground The SnowClear Overhead Melter comes with a standard mounting bracket. This adjustable bracket allows a direct ceiling, wall, or pole mount, and allows the angle of the unit to be adjusted. The bracket needs to be installed onto a secure frame, wall, ceiling, or pole.
- Page 12 Pole Installation Secure the bracket with two U-bolts onto the pole, using the four inner screw holes. The recommended pole sizes are 114mm (4.5 in) for a round steel pole or 102-127 mm (4-5 in) for a squared steel pole. U bolt Note: U bolts are not included.
- Page 13 Ceiling Installation Use the two holes, one below and the one on the right side of the main unit bracket to join to the holding bracket. 4 sets of M8 bolts & nuts are included. M12 anchor bolt M8 bolts & nuts Note: When installing the unit on a wooden or thin ceiling.
- Page 14 Pole Installation-Angled For angled wall installation, move the main unit upwards to 20 degrees. Power Cable Wiring Guide Ensure the electrical cable dose not touch the unit. Bend the electrical cable down to prevent water entering the unit. Secure the cable on the bracket. Correct Incorrect SnowClear Installation, Operator &...
-
Page 15: Operating Instructions
OPERATING INSTRUCTIONS The unit must be properly installed before it is used. For outdoor use only. The unit does not have an ON/OFF switch as it is designed to operate with a snow sensor and controller. It will switch on when the sensor detects falling snow and switches off when it detects that it has stopped snowing. - Page 16 One SnowClear Overhead Melter Unit Two SnowClear Overhead Melter Units SnowClear Installation, Operator & Maintenance Manual...
- Page 17 Three to Six SnowClear Overhead Melter Units SnowClear Installation, Operator & Maintenance Manual...
- Page 18 Seven to Twelve SnowClear Overhead Melter Units SnowClear Installation, Operator & Maintenance Manual...
- Page 19 Connecting to power supply To prevent electric shock, proper grounding is required. Failure to do this may result in electric shock, burns, death and/or damage to the unit. Power cable size 10 gauge is recommended. If the cable is not the correct size, it may result in short circuiting, causing a fire or electrical shock.
-
Page 20: Maintenance Instructions
Maintenance Instructions MAINTENANCE INSTRUCTIONS Disconnect the power supply at the circuit breaker panel and ensure the heating elements are cool before performing cleaning, minor servicing or maintenance. These tasks should only be performed by a licensed and qualified electrician. Snow melting efficiency may decrease if the reflectors become dirty due to the build-up of contaminants from the environment. -
Page 21: Replacement Parts
Replacement Parts Please contact Trecan Combustion Limited- Parts Sales Department by one of the following methods for replacement parts: Mail: Trecan Combustion Limited 4049 St. Margaret’s Bay Road Hubley, Nova Scotia B3Z 1C2 Canada Phone: (902) 876-0457 Press 3 for Parts Sales Email: parts@trecan.com 1 Year Limited Warranty... - Page 22 This limited warranty is not transferable. • This limited warranty is only available in North America. This product is made in Japan by: ELCOM Co.,Ltd. MC Bldg. 10-1 Kita 10 Nishi 1, Kita-ku, Sapporo City 001-0010, Japan Assembled in Canada by: Trecan Combustion Limited 4049 St.
