Summary of Contents for Homebrace MyEcc Pupil

  • Page 1 Image by: Operating Manual MyEcc Pupil...
  • Page 2: Table Of Contents

    05 Mandatory review of the mounted system by the installer ���������������������������������������������������������������������������������������������5 06 MyEcc Pupil/Control disposal �������������������������������������������������������������������������������������������������������������������������������������6 07 The following monitoring mechanisms are actively monitored ��������������������������������������������������������������������������������������6 08 MyEcc Pupil requires the following interfaces with the wheelchair ��������������������������������������������������������������������������������6 09 Connections ����������������������������������������������������������������������������������������������������������������������������������������������������������������6 10 Operating/storage environment ������������������������������������������������������������������������������������������������������������������������������������6 11 Power requirements �����������������������������������������������������������������������������������������������������������������������������������������������������7...
  • Page 3 Eye controlled wheelchair technology for indoor and outdoor use MyEcc Pupil is a more advanced version of the tried and trusted MyEcc designed for eye-cont- rolled wheelchair operation with or without a display in the field of vision� The lightweight plastic headset with an attached sensor tracks the user’s eye movement and the MyEcc Pupil Control...
  • Page 4: Warnings

    Non-observance releases the manufacturer from any liability� MyEcc Pupil Control is only meant to be an interface between power chair and MyEcc Pupil� Any other use is improper and will result in loss of warranty and liability� The same applies to any alterations and modifications�...
  • Page 5: Important Safety Instructions

    Control control box� The assistance of an accompanying person and compliance with all safety instructions are mandatory� If the above criteria are not met or met only in part, outdoor use of MyEcc Pupil is strictly prohibited� 04 Maintenance and cleaning The product does not require regular maintenance�...
  • Page 6: Myecc Pupil/Control Disposal

    Konrad-Hornschuch-Str. 67 | Halle 24, C1 | 73660 Urbach +49 7181 255700 | info@homebrace.com www.homebrace.com 06 MyEcc Pupil/Control disposal MyEcc Pupil and MyEcc Pupil Control are composed of recyclable materials� The individual components should be sorted by material type first: • Iron/aluminum • Plastic • Electronic parts...
  • Page 7: Power Requirements

    14 Installation on the wheelchair 14-01 Technical requirements A MyEcc Pupil Display with at least a Core i5 Processor and 4 GB of RAM is required for calibration and installation� You will need Windows 10 with all the latest updates (as of 9/1/2019)�...
  • Page 8: Installing The Software

    MyEcc Pupil folder using the USB stick supplied with the pack� Start App Pupil capture� If asked, please issue all the approval options, including for public and private networks� This is necessary for communication between MyEcc Pupil and MyEcc Pupil Control� Run all the routines� Screenshot after running the routines Now restart the computer�...
  • Page 9: Startup

    15 Startup Calibration is required beforehand in order to use MyEcc Pupil to control the wheelchair by eye movement� (for further details, see item 15�2)� The control always needs to be unlocked before starting to drive (see item 15�3)�...
  • Page 10 HomeBrace Germany UG (haftungsbeschränkt) Konrad-Hornschuch-Str. 67 | Halle 24, C1 | 73660 Urbach +49 7181 255700 | info@homebrace.com www.homebrace.com General Please keep the settings� Backend Manager Please keep the settings� Local USB Source Please keep the settings� The correct settings are 60 Hz and Auto mode�...
  • Page 11 Window button The window button is necessary for communication between MyEcc Pupil and MyEcc Pupil Control� Please keep the settings as changing them may- cause malfunctions� You can use Detect eye 0 and Detect eye 1 to choose between the left eye and right eye for control, depending on the headset model�...
  • Page 12: Calibration

    15-02 Calibration Calibration is required before using MyEcc Pupil for control� In the menu, activate the Calibrate button� Calibrate Ready appears� Start looking around and focusing in all directions� A sound and a blue dot indicate the first calibration run� A green dot appears, the sound changes and the second stage of calibration starts�...
  • Page 13: Parameter Settings

    Only adjustable here; describes the number of pictures (in this example, every 6th) used by the camera for control� Higher values give more precise controls but also demand the most from the MyEcc Pupil Display� LEFT=0 Camera position at left eye activated(=1) | deactivated (=0)
  • Page 14: Important For Users

    FUNCTION7=7 FUNCTION8=8 Tip: If using MyEcc Pupil from a reclining position, operation is easier if functions 1 and 3 swap places, i.e. looking down will drive the chair forward and looking up will drive it back. 16 Important for users...
  • Page 15: Troubleshooting

    HomeBrace Germany UG (haftungsbeschränkt) Konrad-Hornschuch-Str. 67 | Halle 24, C1 | 73660 Urbach +49 7181 255700 | info@homebrace.com www.homebrace.com 16-02 Troubleshooting A “Joystick in center position” error message can have the following causes: If you operate the joystick before or immediately after switching on the control system, a “Joystick displaced” message appears in the display�...
  • Page 16: Contact

    HomeBrace Germany UG (haftungsbeschränkt) Konrad-Hornschuch-Str. 67 | Halle 24, C1 | 73660 Urbach +49 7181 255700 | info@homebrace.com www.homebrace.com 17 Contact HomeBrace Germany UG (haftungsbeschränkt) Konrad-Hornschuch-Str� 67 Halle 24, C1 73660 Urbach +49 7181 255700 info@homebrace�com www�homebrace�com Edition English 11/2020 ©...
