AlarmTab Sensor Manuals

Content

A la rmT ab S en so r Ma n u a ls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Do o r / W ind o w Con t a ct s (ST -T ra n smit t e r) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

I n st a lla t io n In st u rct io n s Fo r Doo r/W ind o w -Co m b in e d -De te ct o r . . . . . . . . . 4

B a t t e rie s & Ba t te ry Re p la ce m en t . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Mo t io n De te ct o r . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 0

BW M-0 1 a n d BW M-0 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1

Re m o te Con t ro l . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2

P a irin g t h e rad io t ra n sm itt e r wit h t h e sire n s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 4

T ro ub le sho o t in g an d Q & A / FA Q A re a . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 9

Need help?

Do you have a question about the AlarmTab Sensor and is the answer not in the manual?

Questions and answers

Summary of Contents for AMG-Sicherheitstechnik AlarmTab Sensor

Page 1: Table Of Contents
AlarmTab Sensor Manuals Content A la rmT ab S en so r Ma n u a ls ............1 Do o r / W ind o w Con t a ct s (ST -T ra n smit t e r) .
Page 2: Door / Window Contacts (St-Transmitter)
Door / Window Contacts (ST-Transmitter) Sensors ordered in sets are shipped already paired. The ST transmitter is used exclusively as a door window contact. Please clean the surfaces with spirit or glass cleaner. The sensors are attached using an adhesive pad. The ST transmitter is turned on by pressing the bottom large button (Nr.
Page 3 The small symbols have the following meaning: Symbol S (In the Picture Nr. 1) = Transmitter mode This is the transmit mode with the lowest standby power consumption. In order to ensure that the battery operates at the usual frequency of use for up to 1 year, the blue display illumination is switched off in S mode after approx.
Page 4: Installation Insturctions For Door/Window-Combined-Detector
Installation Insturctions For Door/Window-Combined-Detector Please keep in mind that you need to reach the bottom of the transmitter to change the battery. Please install the transmitter so that you get with a screwdriver on the lower side. General Information: When mounting the ST transmitters, make sure that they are not mounted on a metal surface.
Page 5 Step 2: Fix the transmitter flush with the window frame When gluing, make sure that the sensor is mounted flush with the edge of the window sash or the door. Attention: the adhesive pad sticks very strong. A once attached adhesive pad can not be detached again.
Page 6 Step 4: Attach the lower magnet Step 5: Perform a function test...
Page 7 Step 6: Attach upper magnet The distance between the two magnetic contacts should be approx. 55 mm. Step 7: Check the position and height of the magnets...
Page 8 Step 8: Bump test window Step 9: Attach the glass breakage sensor Thoroughly clean the window pane before mounting the glass breakage detector with the adhesive pad on the pane. To ensure the maximum sensitivity stick the glass breakage detector on the glass with a distance from the edge, we recommend 5 cm. Connect the cable of the glass breakage detector to the MicroUSB connection of the window / combination detector.
Page 9: Batteries & Battery Replacement
Batteries & Battery Replacement The door-window / combination sensor works with a 3.6V 2700 mAh lithium battery Mignon / AA size. The battery label required is ER14505 to change that battery is that you remove the Phillips screw of the battery cover on the underside of the sensor and pull the cover forward.
Page 10: Mo T Io N De Te Ct O
Motion Detector PIR motion detectors respond to heat differences while checking whether this heat source is moving. In the field of safety technology, motion detectors are responsible for about 90% of the cases of unwanted alarm triggering. The cause are usually unsuitable mounting positions of the motion detectors.
Page 11: Bw M-0 1 A N D Bw
BWM-01 and BWM-02 Sensors ordered in sets are shipped already paired. Please clean the surfaces with spirit or glass cleaner. The sensors are attached using an adhesive pad. To turn on the detector, press and hold the large right button on the front panel for about 4 seconds.
Page 12: Re M O Te Con T Ro
For the motion detector with pet function, the mounting height depends on the size of the pet, in a large dog, the sensor must be mounted higher in order to create more space. Make sure that the sensor is not aligned with furniture, for example, a cat can jump. If you have decided on a mounting location, remove the protective film from the magnet holder and carefully push the sensor into the selected location.
Page 13 Battery Replacement To open the remote, you must remove the key ring and use a small screwdriver or flat object to open the housing at the bottom corner. Now you can remove and replace the CR2032 3V battery. When you have done everything you can reassemble both housing halves. Paring The remote control is paired in by pressing the upper and lower buttons simultaneously for 3 seconds.
Page 14: P A Irin G T H E Rad Io T Ra N Sm Itt E R Wit H T H E Sire N
Pairing the radio transmitter with the sirens Make sure that the radio transmitter is connected to the lower USB socket on the left side of the BTS transmitter and switched on via the large right button. Now you have to train the signal of the radio transmitter in the siren. Open the metal housing with the two screws on the bottom left and right.
Page 15 Alarm speaker General You can use an alarm speaker in many ways. Since the loudspeaker can be controlled at any time via the online portal or Android App, everything is possible, from alerting in the event of a fire, through voice announcements when breaking in, to simple alarm clocks. You can play your own announcements and mp3 files on the included SD card and ensure that your favorite song is played every morning.
Page 16 Pairing and settings On the start page you will see an icon for the quick access in the top right corner. There you can: You turn the individual devices on and off. Please go to the settings in the menu item Smart Home Switches & Sirens Control.
Page 17 The BTS transmitter must now be switched off, for that press the right big key for 3 Seconds. You can turn the transmitter back on as soon as the display disappears. When switched on, the transmitter will be pressed. If necessary, press the right big button for 3 seconds If you now click on "ON"...
Page 18 Quick Access On the start you will see an icon for the quick access in the top right corner. Here you can: Turn individual devices on and off. Applications examples can be taken from the picture below.
Page 19: T Ro Ub Le Sho O T In G An D Q & A / Fa Q A Re
Troubleshooting and Q & A / FAQ Area Further help can be found in our Forum http://forum.amg-sicherheitstechnik.de/ I forgot my master PIN. Go to HELP & MORE under MENU. There you can send the master PIN to the saved e-mail address or phone number.
Page 20 Did you move the recessed lever to the red dot and turn on the BTS transmitter by pressing the large right button? If so, did you also consider the minute delay? SMS and call do not arrive. Please check if there is enough credit left on the SIM card. Depending on the provider, prepaid cards will be deactivated if no credit has been charged for 6 or 12 months.
