Summary of Contents for Enso pearl

  • Page 1 Welcome! EC-200-P Instructions-v1.2.indd 1 EC-200-P Instructions-v1.2.indd 1 21/5/2020 3:04 PM 21/5/2020 3:04 PM...

  • Page 2: Table Of Contents

    Table of Contents Setting the Clock Setting the Alarm Timer Introduction Interval Timing Setting an Interval Timer Repeat Timing Changing the Timer Function Setting the Audio Alert Additional Features EC-200-P Instructions-v1.2.indd 2 EC-200-P Instructions-v1.2.indd 2 21/5/2020 3:04 PM 21/5/2020 3:04 PM...
  • Page 3 Drawn with a single clockwise brushstroke, this Japanese symbol inspired the design of the Enso Pearl. The Enso Ring is slowly brushed around the clock display, abstractly showing the relative amount of elapsed time. This subtle display of time passage frees your mind from the distracting thought of a numerical countdown of time.

  • Page 4: Setting The Clock

    Setting the Clock Press the Button. Adjust the Time. Press to increment time. Hold for fast scrolling Press to decrement time. Press to Toggle 12/24-hour Format and Set Seconds to 0. Press to Finish Setting Clock. EC-200-P Instructions-v1.2.indd 4 EC-200-P Instructions-v1.2.indd 4 21/5/2020 3:04 PM 21/5/2020 3:04 PM...
  • Page 5 Current Time - hr 12/24-hour Format EC-200-P Instructions-v1.2.indd 5 EC-200-P Instructions-v1.2.indd 5 21/5/2020 3:04 PM 21/5/2020 3:04 PM...

  • Page 6: Setting The Alarm

    Setting the Alarm Press the Button. Adjust the Alarm. Press to increment time. Hold for fast scrolling Press to decrement time. Press to Toggle Alarm On or Off. When Alarm sounds, press to turn off. When Alarm sounds, press to Snooze. Snooze Function: Alarm tone will be silenced.
  • Page 7 Alarm Status Indicator Alarm Time EC-200-P Instructions-v1.2.indd 7 EC-200-P Instructions-v1.2.indd 7 21/5/2020 3:04 PM 21/5/2020 3:04 PM...

  • Page 8: Timer Introduction

    Timer Introduction The Enso Pearl has three separate Timers ( ), each of which can be configured with the following timing options: Timing Function Countdown: Interval (Int) Repeat Count-up: Stopwatch Time Format Hr:Min Min:Sec Default Timer Settings Interval (Int) Hr:Min...

  • Page 9: Interval Timing

    Pressing begins the countdown of each Interval one-after-another until the entire timing sequence is complete. Interval Timers in the Enso Pearl can each hold up to 99 Intervals. Example: 3-Interval Timer EC-200-P Instructions-v1.2.indd 9 EC-200-P Instructions-v1.2.indd 9 21/5/2020 3:04 PM...

  • Page 10: Setting An Interval Timer

    Setting an Interval Timer Press the Button. Adjust the Duration of Current Interval. Press to increment time. Hold for fast scrolling Press to decrement time. Press to Edit Next Interval. Repeat to Adjust Time of New Interval. Repeat & to Add More Intervals. Press for Previous Interval.
  • Page 11 Timer # Indicator Current Timer Time Format Duration of Current Interval Interval Number Repeat Indicator EC-200-P Instructions-v1.2.indd 11 EC-200-P Instructions-v1.2.indd 11 21/5/2020 3:04 PM 21/5/2020 3:04 PM...

  • Page 12: Repeat Timing

    Repeat Timing . . . is the repetitive timing of a single time duration. A single timer may be repeated up to 99 times. Press the Button to Use Repeat Timer. Timer is in Repeat mode when is visible. Adjust the Duration of a Single Timer. Press to increment time.

  • Page 13: Changing The Timer Function

    Changing the Timer Function Press , or Button. Press and Hold Button to Change Timer Mode. Timer will cycle through the following configurations for current timer: Stopwatch Function Press on a blank (0) timer to start the Timer counting up in Stopwatch mode.

  • Page 14: Setting The Audio Alert

    Setting the Audio Alert Selected sound settings apply to all Timers & Alarm. Press the Button. Press to Adjust the Volume. Audio alert is muted if level 0 is selected. Press to Change the Tone. Note: During a Timer, the selected Tone will play once at the end of each Interval or Repetition and twice at the end of the full Timer.
  • Page 15 Volume Tone Level Number EC-200-P Instructions-v1.2.indd 15 EC-200-P Instructions-v1.2.indd 15 21/5/2020 3:04 PM 21/5/2020 3:04 PM...

  • Page 16: Additional Features

    Additional Features Backlight Hiding the Numerical Display During a Timer Resetting a Timer Press and hold , or to reset respective timer completely. EC-200-P Instructions-v1.2.indd 16 EC-200-P Instructions-v1.2.indd 16 21/5/2020 3:04 PM 21/5/2020 3:04 PM...
  • Page 17 Changing the Batteries EC-200-P Instructions-v1.2.indd 17 EC-200-P Instructions-v1.2.indd 17 21/5/2020 3:04 PM 21/5/2020 3:04 PM...
  • Page 18 FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See instructions if interference to radio or television reception is suspected.
  • Page 19 EC-200-P Instructions-v1.2.indd 19 EC-200-P Instructions-v1.2.indd 19 21/5/2020 3:04 PM 21/5/2020 3:04 PM...
  • Page 20 Thank you! WG-EC-200-1 EC-200-P Instructions-v1.2.indd 20 EC-200-P Instructions-v1.2.indd 20 21/5/2020 3:04 PM 21/5/2020 3:04 PM...
