Summary of Contents for 2in1 BPtele
- Page 1 CARDIAC DISEASE & STROKE PREVENTION www.2in1.si Data transfer Please download and install the free app into your smartphone BLOOD PRESSURE MONITOR USER’S MANUAL...
- Page 2 Batteries, cuff and accessories are not included. Opening or altering the instrument invalidates the guarantee. The guarantee does not cover damage, accidents or non-compliance with the instruction manual. Please contact your local seller/dealer or www.2in1.si. Customer Name: Address: Address: Telephone:...
-
Page 3: Parr (Pulse Arrhythmia) Technology
Automated Sphygmomanometers. This unit is to be used by adult consumers in a home environment. Do not use this device on infants or neonates. 2in1. BP TELE is protected against manufacturing defects by an established International Warranty Program. For warranty information, you can contact the manufacturer, Rossmax International Ltd. -
Page 4: Atrial Fibrillation Detection (Afib)
diagnosis. Thus PARR is not meant to replace any medical ECG diagnosis by your doctor. PARR provides an early detection of certain pulse arrhythmia, which inevitably need to be presented to your doctor in charge. Remark: [1] Clinical Investigation of PARR - A new Oscillometric Pulse Arrhythmia... -
Page 5: Premature Contraction Detection (Pc)
Note: The presence of a cardiac pacemaker may impair the AFib detection by PARR. PREMATURE CONTRACTION DETECTION (PC) Extra abnormal heartbeats generated in irregular excitation sites of your heart, either in the atria (PAC), the ventricle (PVC) or the cardiac conduction nodes (PNC). These extra beats may disrupt your regular rhythm, they may come in early or cause a signifi- cant pauses regarding your perceivable pulse. -
Page 6: Pulse Arrhythmia Detection (Arr)
PULSE ARRHyTHMIA DETECTION (ARR) Once the occurrence of pulse arrhythmia has been detected in the course of your blood pressure measurement, the icon ARR is displayed. In the case, that the found pulse arrhythmia can be specified by the PARR technology, the ARR icon is accompa- nied by the specifically detected type of arrhythmia, e.g. -
Page 7: Real Fuzzy Measuring Technology
REAL FUzzy MEASURING TECHNOLOGy This unit uses the oscillometric method to detect your blood pressure. Before the cuff starts inflating, the device will establish a baseline cuff pressure equivalent to the air pressure. This unit will automatically determine the appropriate inflation level based on pressure oscillations, followed by cuff deflation. -
Page 8: Blood Pressure Standard
BLOOD PRESSURE STANDARD Refer to the definitions of the World Health Organization, the blood pressure ranges can be classified into 6 grades. (Ref. 1999 WHO-International Society of Hypertension Guidelines for the management of Hypertension). This blood pressure classifica- tion are based on statistical data, and may not be directly appli- cable to any particular patient. -
Page 9: Name/Function Of Each Part
NAME/FUNCTION OF EACH PART 1. Arm Cuff 2. LCD Display 3. Air Tube and Connector 4. Memory Key 5. ON/OFF/START key 6. User-Switching key 7. Battery Cover 8. Data Link Socket 9. AC Adaptor Jack 10. Cuff Holder Design... -
Page 10: Loose Cuff Detection
NAME/FUNCTION OF EACH PART 1. Arrhythmia Detection (ARR) 2. Atrial Fibrillation Detection (AFib) 3. Premature Contraction Detection (PC) 4. Date/Time Indication 5. Weak Battery Mark 6. Movement Mark 7. Loose Cuff Detection 8. Hypertension Risk Indication 9. Morning and Nighttime Mark 10. -
Page 11: Movement Detection
MOVEMENT DETECTION The “Movement Detection” helps reminding the user to remain still and is indicating any adverse body movement during mea- surement. The specified icon appears once a “body movement” has been detected during and after such a measurement. Note: It’s highly recommended that you measure again if the icon appears. - Page 12 ERROR CODES FOR yOUR REFERENCE ee / Measurement error: Make sure the L-plug is securely con- nected to the air socket and calmly measure again. Wrap the cuff correctly around your arm and keep arm steady during measurement. If the error keeps occurring, return the device to your local distributor or service centre.
-
Page 13: Installing Batteries
for the compatible AC adaptors. 4. Use only the authorized AC Adaptor with this blood pressure monitor. Information forthe authorized AC adap- tor, please refer to APPENDIX 1. INSTALLING BATTERIES 1. Press down and lift the battery cover in the direction of the arrow to open the battery compartment. -
Page 14: Applying The Cuff
APPLyING THE CUFF 1. Unwrap the arm cuff, leaving the end of the cuff through the D-ring of the cuff. 2. Put your left arm through the cuff loop. The color strip indica- tion should be positioned closer to you with the tube point- ing in the direction of your arm (Fig. -
Page 15: Measurement Procedures
Center tube over middle of arm MEASUREMENT PROCEDURES Here are a few helpful tips to help you obtain more accurate readings: • Blood pressure changes with every heartbeat and is in con- stant fluctuation throughout the day. • Blood pressure recording can be affected by the position of the user, his or her physiological condition and other factors. - Page 16 are feeling cold or hot, wait a while before taking a measure- ment. • If the monitor is stored at very low temperature (near freez- ing), have it placed at a warm location for at least one hour before using it. Wait 5 minutes before taking the next measurement.
-
Page 17: Recalling Values From Memory
RECALLING VALUES FROM MEMORy 1. The monitor has two memory zones (1 and 2). Each zone can store up to 60 measurements. 2. To read memory values from a selected memory zone, use the User-Switching key to select a memory zone (1 or 2) from which you want to recall values. -
Page 18: Data Transfer Via Bluetooth
Pairing the Blood Pressure Monitor with your smartphone To begin using Bluetooth® for the first time, please visit the website at www.2in1.si for the initial set-up instructions. 1. Download and install the free APP onto your smartphone. 2. To pair this device with your smartphone, turn on the de- vice, Bluetooth®... - Page 19 3. The Bluetooth® symbol ( ) will flash on the display that indi- cates the pairing is proceeding. - If the pairing is successful, the Bluetooth® symbol ( ) will stop flashing and appear on the display, the device will start the measurement automatically.
-
Page 20: Troubleshooting
TROUBLESHOOTING If any abnormality will arise during use, please check the follow- ing points. Symptoms Check Points Correction Have the batteries Replace them with run down? four new batteries. No display when the ON/OFF/ Have the batteries’ Re-insert the START key is polarities been batteries in the pressed... -
Page 21: Cautionary Notes
CAUTIONARy NOTES The unit contains high-precision assemblies. Therefore, avoid extreme temperatures, humidity, and direct sunlight. Avoid dropping or strongly shocking the main unit, and pro- tect it from dust. Clean the blood pressure monitor body and the cuff care- fully with a slightly damp, soft cloth. Do not press. Do not wash the cuff or use chemical cleaner on it. - Page 22 meter may be impaired with the occurrence of pulse ar- rhythmia. 10. To stop operation at any time, press the ON/OFF/START key, and the air in the cuff will be rapidly exhausted. Once the inflation reaches 300 mmHg, the unit will start deflating rapidly for safety reasons.
- Page 23 vascular access or therapy, or an arteriovenous (AV) shunt. 22. Do not apply the cuff on the side, where a mastectomy has been performed in your patient history. 23. Do not place the cuff over wounds as this may cause further injury.
-
Page 24: Specification
SPECIFICATION Measurement Method Oscillometric Measurement Range Pressure: 30~260 mmHg; Pulse: 40~199 beats/minute Pressure Sensor Semi conductor Accuracy Pressure: ± 3 mmHg; Pulse: ± 5% of reading Inflation Pump Driven Deflation Automatic Air Release Valve Memory capacity 60 memories for each zone x 2 zones Auto-shut-off 1 minute after last key... - Page 25 Guidance and manufacturer’s declaration-electromagnetic emissions The 2in1. BP TELE is intended for use in the electromagnetic environment specified below. The customer or the user of the 2in1. BP TELE should assure that it is used in such an environment. Emission test...
- Page 26 Guidance and manufacturer’s declaration-electromagnetic immunity The 2in1. BP TELE is intended for use in the electromagnetic environment specified below. The cus- tomer or the user of the 2in1. BP TELE should assure that is used in such and environment. Immunity test...
- Page 27 The 2in1. BP TELE is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the 2in1. BP TELE can help prevent electro- magnetic interference by maintaining a minimum distance between portable and mobile RF commu- nications equipment (transmitters) and the 2in1.
- Page 28 /2in1smartsolution Rossmax Swiss GmbH, Tramstrasse 16, CH-9442 Berneck, Switzerland Distributed by: VPD, Bled, d.o.o., Pot na Lisice 4, 4260 Bled, Slovenia, EU, www.vpd.si • www.2in1.si...
